Connecting a fuel line to an auto gas tank can be a tricky process. It is important to know the size of the fuel pipe or flexible line, as well as the fittings on the tank and pump. The most common size of the fuel pipe is 1/4 inside diameter, but some pumps may require a 5/16 or 5/8 flexible fuel line. There are also various fuel line connectors and fitting kits available on the market that can make the process easier, but it is crucial to ensure that they fit your vehicle's specific make and model.
Explore related products
What You'll Learn
- Fuel line connectors are available at AutoZone for easy installation
- The most common fuel pipe size is 1/4 inside diameter
- A 5/16 ID flexible fuel line can be adapted to the pump
- Auto Dynasty Fuel Tank Gas Cell 6AN to 10AN Fittings are available on Amazon
- The braided cover on the Auto Dynasty hose increases resistance to internal pressure
Fuel line connectors are available at AutoZone for easy installation
The most common size fuel pipe or flexible line is 1/4" inside diameter. The fitting on the side of the tank is a 1/4" compression fitting with 1/4" British Standard Pipe threads. If you have a Facet pump, or any of the other readily available pumps, they will have a barb that accepts a 1/4" or 5/16" flexible fuel line.
You can get the fittings from Moss or Victoria British. The easiest way to make the connection at the fuel tank is to get a nipple (Moss P/N 376-415) and a mating nut (Moss P/N 376-405) and some brake or fuel line that is 5/16" outside diameter. Solder a short length (about 2") into the nipple, and you will have a fitting that will screw onto the fitting on the side of the tank.
AutoZone offers a range of fuel line connectors and fittings for cars, trucks, and SUVs, with prices starting at $3.99 for in-store pickup.
Chevy Fuel Line: Understanding the 1985 Model's Unique Design
You may want to see also
Explore related products
The most common fuel pipe size is 1/4 inside diameter
When adding a fuel line connection to an auto gas tank, it is important to consider the size of the fuel pipe. The most common size for a fuel pipe or flexible line is 1/4" inside diameter. This measurement refers to the internal diameter of the hose, which is a standard way of sizing fuel hoses. The 1/4" size is also common for the fitting on the side of the tank, which is typically a compression fitting with 1/4" British Standard Pipe (BSP) threads.
While 1/4" is the most common size, there are other sizes available for fuel pipes and fittings. For example, some fuel pumps will have a barb that accepts a 1/4" or 5/16" flexible fuel line. It is also possible to find fuel systems with hose sizes of 6mm, 10mm, 12mm, or 15mm from the tank to the pump, depending on the application and the size of the engine.
When working with fuel systems, it is important to consider the pressure and flow rate of the fuel. The size of the fuel line can impact the pressure drop, with larger lines resulting in lower pressure drops. For example, switching from a 3/8" line to a 1/2" line can reduce the pressure drop by a factor of ten. Additionally, the viscosity and surface tension of the fuel can affect the flow rate, with lower viscosity and surface tension allowing for easier flow through the pipe.
To ensure the fuel system functions properly, it is recommended to consider the addition of a regulator in the return line if the car does not run well after the fuel system is installed. This will allow the fuel system to pressurise and improve the car's performance.
Jeep Cherokee Fuel Filter: Where is it?
You may want to see also
Explore related products
A 5/16 ID flexible fuel line can be adapted to the pump
A 5/16" ID flexible fuel line can be adapted to the pump. This is a common size for fuel pipes or flexible lines, with the most common size being 1/4". The 5/16" flexible fuel line can be adapted to the pump by cutting one end off and connecting it to the pump with a short piece of the same size and type of fuel line.
The 5/16" ID flexible fuel line is suitable for low-pressure applications and can handle up to 60 PSI. It is also suitable for vacuuming due to its rigidity. The hose is thick-walled, flexible, yet sturdy, and can resist kinking. It is important to note that the actual ID and OD of the fuel line may vary slightly depending on the supplier, so it is crucial to verify that the inner diameters match to prevent leakage or damage under pressure.
Adapter fittings, also known as standard fittings or union fittings, are commonly used to connect fuel lines to fuel pumps. These fittings have straight threads and use O-ring seals. The O-ring size is typically defined by the "AS" standard, and dash numbers are assigned based on the size. For example, -906 is for -6AN ports, and -908 is for -8AN ports.
When using adapter fittings, special port machining is required to "capture" and properly compress the O-ring. This ensures a reliable seal and prevents leakage. It is also important to use compatible fittings and verify that the inner diameters match to avoid issues with mismatched lines coming apart under pressure.
Some customers have reported issues with fittings that don't fit snugly and leak, so it is important to ensure accurate measurements and compatibility when selecting the appropriate fittings for your fuel line and pump.
Using an AC Fuel Line Disconnect Tool: A Step-by-Step Guide
You may want to see also
Explore related products
Auto Dynasty Fuel Tank Gas Cell 6AN to 10AN Fittings are available on Amazon
If you're looking to add a fuel line connection to your auto gas tank, you might want to consider the Auto Dynasty Fuel Tank Gas Cell 6AN to 10AN Fittings, which are available on Amazon. This kit includes a 12-inch nylon braided return hose feed line and is designed to adapt to your existing fuel system.
The braided cover on the hose provides increased resistance to internal pressure and helps retain its form. It comes with a 10AN to 6AN adapter fitting, allowing you to run 3/8" feed and return lines for your fuel system. The inner hose is made of CPE synthetic material, providing maximum resistance to heat, corrosion, and abrasion. The operating temperature range of this hose is impressive, withstanding temperatures from −40 degrees Fahrenheit to +350 degrees Fahrenheit.
The kit includes a range of adapters to suit your needs:
- 2 x 90-degree 6AN fuel hose fitting adapter
- 2 x 45-degree 6AN fuel hose fitting adapter
- 2 x Straight 6AN fuel hose fitting adapter
- 2 x 6AN to 1AN fuel tank fitting adapter
The fittings are made of high-quality, lightweight T-6061 aluminum material, ensuring durability and ease of installation. It is recommended to have a professional installer set up the fuel line, as instructions are not included with the kit.
Reviews of the product on Amazon are generally positive, with customers praising the good quality of the fuel line and the nice appearance of the fittings. However, it is noted that care should be taken when assembling the fittings to avoid stripping them, and they may not be suitable for high-flow or pressure fuel systems.
Fuel Lines for EFI: Material and Size Choices
You may want to see also
Explore related products
The braided cover on the Auto Dynasty hose increases resistance to internal pressure
The Auto Dynasty hose is a steel braided hose kit that can be used to decorate your engine bay or replace old, dirty rubber hoses and lines. The braided cover on the Auto Dynasty hose increases resistance to internal pressure, providing remarkably higher resistance to extreme heat, abrasion, and corrosion compared to rubber hoses. It is designed for direct installation or replacement, offering the highest safety in most fuelled vehicles.
The kit includes a 3-foot vacuum line, a 3-foot fuel line, a 12-foot heater hose, and a 4.5-foot radiator hose, all with polished hose ends. To install the kit, simply disconnect one end of the rubber hose you want to replace and slide the steel braided hose kit over it. Cut the steel braided hose to the desired length, and then reconnect it using the polished hose ends.
While the Auto Dynasty hose offers increased resistance and safety features, some customers have reported issues with the product. There have been complaints about the material thickness and ease of tearing, particularly regarding the mesh material tearing during installation. Some have also mentioned that the clamp covers are too small and need to be stretched to fit over the clamps.
To avoid these issues, it is recommended to engage a professional installer for this product. Additionally, it is important to note that this is a "`dress-up`" kit, and installing it may require breaking the coolant lines and flushing the cooling system.
Fuel Line Size Guide for SSR Pit Bikes
You may want to see also
Frequently asked questions
You can purchase a fuel line repair kit and fix only the part that is damaged. You can also buy fuel line connectors that are designed for easy installation and a precise fit for your vehicle.
The most common size fuel pipe or flexible line is 1/4" inside diameter. However, you can also get fuel lines that are 5/16" outside diameter.
You can purchase fuel line connectors and fittings from local auto parts stores, as well as online retailers such as Amazon and AutoZone.
