When installing brake and fuel lines, it is important to consider the placement of the lines in relation to the frame and the heat generated by the exhaust. One method is to run the fuel line on the passenger side outside the frame rail, away from the exhaust heat, while keeping the brake lines in the stock location on the driver's side. To secure the fuel lines, some people use rubber-insulated straps, while others prefer plain metal straps.
| Characteristics | Values |
|---|---|
| Fuel line placement | Passenger side, outside frame rail |
| Fuel line mounts | Drilled and tapped into the frame |
| Brake line placement | Driver's side |
| Return line | Required |
| Clips | Original style |
| Retainers | Separate |
| Strap type | Rubber-insulated or plain metal |
Explore related products
What You'll Learn
Running fuel and brake lines with stainless fittings
Planning:
Before you begin, it's important to decide on the routing of your fuel and brake lines. For an 85 Chevy, you may want to consider running the fuel line on the passenger side, away from the exhaust heat, while the brake lines run on the driver's side. This ensures that the fuel lines are not exposed to excessive heat, reducing the risk of leaks or damage.
Materials and Tools:
- Stainless Steel Tubing: Use high-quality stainless steel tubing that meets SAE J1677 and ASTM A249 specifications. Summit Racing offers stainless steel tubing with a standard 0.028-inch wall thickness, adding molybdenum for enhanced corrosion resistance.
- Fittings: Choose fittings that are compatible with your vehicle's fuel and brake systems. Pre-bent brake line kits are available for specific Chevy models, ensuring a proper fit.
- Flaring Tool: You will need a professional-grade flaring tool designed specifically for stainless steel. A mechanical flaring tool can create double flares in the tubing, ensuring secure connections.
Installation:
- Secure the Fuel Lines: When installing the fuel lines, consider using rubber-insulated straps to hold them in place. This provides added protection and insulation from heat.
- Flaring the Ends: Before connecting the lines, use your flaring tool to flare the ends of the stainless steel tubing. This step is crucial for creating a tight seal and preventing leaks.
- Connect the Lines: With the lines securely flared, you can now connect them to the appropriate fittings. Ensure that all connections are tight and secure to prevent leaks.
Final Checks:
Once you've installed the fuel and brake lines with stainless fittings, it's important to perform a thorough inspection:
- Check for Leaks: Inspect all connections for any signs of leaks. Use appropriate fluids to test the lines and ensure that there are no drips or leaks.
- Test Drive: After confirming that the lines are secure and leak-free, take your vehicle for a test drive to ensure that the brake and fuel systems are functioning correctly.
Remember, working on fuel and brake systems can be complex and requires mechanical knowledge. If you're unsure about any steps or encounter difficulties, it's always best to consult a professional mechanic or a specialist in custom automotive plumbing.
