Straightening a micro vinyl fuel line can be done in several ways. One method involves using a straightening tool, such as a bar stock with a U-shaped welded end, to stretch and straighten the tube. Another approach is to anchor one end of the tubing to a fixed object, like a building column, and then attach the other end to a come-along or similar device, pulling it taut to remove any bends. For shorter pieces, straightening by hand is an option, though it may require a few attempts.
Characteristics and Values
| Characteristics | Values |
|---|---|
| Method | Using a straightening tool, a grooved block, or by hand |
| Tool Description | 1/2" X 36" bar stock with a U welded on one end with holes for tubing |
| Tool Usage | One end is vice-gripped to the floor grating, the other end is inserted into the hole in the tab, then the bar stock end is put into a grating hole and used as a lever to stretch the tube |
| Cutting | Both ends must be cut off with a tubing cutter after straightening |
| Material | Vinyl |
| Resistance | High resistance to oil, grease, and fuels |
| Other Resistances | Weathering, tearing, ozone radiation, and surface abrasion |
| Color | Transparent red |
| Max Working Temperature | 175°F |
