Fuel Pressure: Blue Spring Upgrade Benefits

The blue spring mod or blue spring upgrade is an updated fuel pressure regulator spring released and recommended by Ford Motor Company. The blue spring is slightly stiffer than the factory-installed spring and may be made of a more suitable material that resists deformation over time. It is said to increase fuel pressure by approximately 10%. The blue spring upgrade is a low-cost modification that can help prevent damage to injectors and even extend their life.

The blue spring upgrade increases fuel pressure by 10%

The blue spring upgrade is an updated fuel pressure regulator spring released and recommended by Ford Motor Company. The blue spring mod increases fuel pressure by around 10%. The name comes from the blue colour of the upgraded spring, which allows technicians to easily recognise that the upgraded part has been installed. The blue spring is slightly longer and stiffer than the factory-installed spring and may be made from a more suitable material that resists deformation over time.

The blue spring upgrade is important because rapid injector wear and even failure can result from low fuel pressure and/or fuel starvation. This is because low fuel pressure can cause the plunger in the injector to run dry, and the low tolerances in the machining of the injector components make them susceptible to even small dimensional changes. Therefore, constant lubrication is necessary for a long, reliable service life. A minimum fuel pressure of 45 psi is necessary at all times, including wide-open-throttle and full-load conditions, to maximise engine performance and ensure proper injector operation.

Users have reported that the blue spring upgrade has made a big change in how their trucks run, with significantly more responsive throttles. However, one user has reported that after installing the blue spring kit, their cruising EGTs increased by 75-100 degrees. Another user has reported that their new spring was not keeping up with their injectors, with fuel pressure dropping below 50 psi at about 60% throttle.

There are alternative options to the blue spring upgrade, such as the EightySixd Fuel Pressure Spring, which is said to outperform the blue spring upgrade. The EightySixd spring raises fuel pressure to about 70-80 psi at idle and 50-55 psi at WOT, compared to the blue spring's 60-65 psi at idle and 45-50 psi at WOT.

The blue spring upgrade improves throttle response

The blue spring upgrade is a simple modification that can significantly improve the throttle response of your Ford 6.0L Power Stroke engine. This upgrade involves replacing the stock fuel pressure regulator spring with an updated blue spring, which is slightly stiffer and made of a more durable material.

The benefits of the blue spring upgrade are twofold. Firstly, it increases fuel pressure by approximately 10%, ensuring that your engine consistently receives the fuel pressure it needs to perform at its best. This is especially noticeable when you floor the throttle, as the engine now has access to a more ample fuel supply, resulting in a more immediate and powerful response. Secondly, the blue spring upgrade helps protect your injectors. Low fuel pressure can lead to rapid injector wear and even failure, as it causes the injector plunger to run dry. By maintaining adequate fuel pressure, the blue spring upgrade extends the lifespan of your injectors, saving you money on costly repairs or replacements.

In addition to improved throttle response and injector protection, some users have also reported increased fuel efficiency after performing the blue spring upgrade. While not a guaranteed outcome, it is certainly an added benefit that some drivers have experienced.

The blue spring upgrade is relatively straightforward to install and can be completed in a few hours by anyone with basic mechanical skills. The process involves removing the fuel filter cap and element, draining the fuel filter housing, and then carefully removing the old spring and installing the new one. It is important to follow the correct procedure and take the necessary precautions when working with fuel system components.

Overall, the blue spring upgrade is a highly recommended modification for any Ford 6.0L Power Stroke owner seeking improved throttle response, enhanced injector protection, and potentially better fuel efficiency. It is a cost-effective upgrade that can make a noticeable difference in the performance and reliability of your vehicle.

The blue spring upgrade is recommended by Ford Motor Company

The blue spring upgrade is an updated fuel pressure regulator spring that is blue in colour, allowing technicians to easily identify if the upgrade has been installed. This spring is slightly stiffer than the factory-installed variation and may be made from a more suitable material that resists deformation over time.

By installing the blue spring upgrade, fuel pressure can be increased by approximately 10%, ensuring that the engine always has sufficient fuel pressure. A minimum fuel pressure of 45 psi is necessary to maximise engine performance and prevent damage to the injectors.

The blue spring upgrade is a relatively simple modification that can be performed by following these steps:

• Disconnect both negative battery cables.
• Remove the air filter assembly and cold-side intercooler tube to access the fuel filter housing.
• Drain the fuel filter housing.
• Remove the fuel pressure regulator cover and retrieve the spring, spring seat, and cover gasket.
• Install the new components in reverse order, coating the cover gasket and spring seat o-ring with clean motor oil.
• Reinstall the fuel regulator cover, being cautious not to pinch the gasket.
• Install a new fuel filter element and fuel filter cap o-ring, also coated in clean motor oil.
• Reconnect both negative battery cables.
• Cycle the key into the "run" position three times for at least 10 seconds per cycle to fill the fuel filter housing and prime the fuel system.
• Start the engine and verify that there are no leaks. You may also wish to test the fuel pressure.

The blue spring upgrade is an inexpensive and effective way to improve the performance and longevity of your Ford vehicle's fuel system, especially if you have made any aftermarket performance upgrades. It is always recommended to follow the vehicle manufacturer's recommendations for maintenance and upgrades to ensure optimal performance and longevity.

The blue spring upgrade is necessary to prevent injector wear and failure

The blue spring upgrade is an essential modification to prevent injector wear and failure. The upgrade is a simple, low-cost solution that significantly improves the longevity of injectors in Ford's 6.0L Power Stroke engine.

The blue spring upgrade is an updated fuel pressure regulator spring, designed to maintain adequate fuel pressure and prevent issues such as injector wear and failure. The spring is slightly stiffer than the factory-installed variation and is said to increase fuel pressure by approximately 10%. This increase in fuel pressure ensures a constant lubrication of injector components, which is crucial for their long-term reliability.

Low fuel pressure can lead to rapid injector wear and even failure. The blue spring upgrade helps to mitigate this issue by providing the necessary fuel pressure to the injectors, even during wide-open-throttle and full-load conditions. Without this upgrade, injectors may not receive sufficient fuel pressure, leading to potential damage and reduced engine performance.

The blue spring upgrade is a recommended modification by Ford Motor Company for their 6.0L Power Stroke engine, found in various Ford Super Duty trucks and Excursion models from 2003 to 2007. It is a simple upgrade that can be performed by carefully removing the fuel pressure regulator cover, retrieving the old spring, and installing the new blue spring, along with a new cover gasket and spring seat.

In addition to preventing injector wear and failure, the blue spring upgrade also offers improved throttle response and a smoother power delivery. This modification is beneficial for both stock and modified trucks, as it ensures optimal fuel pressure for proper injector operation, leading to enhanced engine performance and improved driveability.

The blue spring upgrade is a low-cost modification

The blue spring upgrade kit, released and recommended by Ford Motor Company, includes an updated fuel pressure regulator spring that is blue in colour, making it easily identifiable by technicians. This new spring is slightly stiffer than the factory-installed spring and may be made from a more durable material that resists deformation over time. It is designed to increase fuel pressure by approximately 10%, ensuring that the engine maintains a minimum fuel pressure of 45 psi, which is necessary for optimal injector operation and engine performance.

The installation process for the blue spring upgrade is relatively straightforward and can be completed in a few hours. It involves removing the air filter assembly, cold-side intercooler tube, and fuel filter cap; draining the fuel filter housing; and then removing and replacing the fuel pressure regulator cover and spring assembly. It is important to note that basic tools, including a T-27 Torx driver, are required for this procedure.

While the blue spring upgrade from Ford is effective in raising fuel pressure, there are also aftermarket options available, such as the EightySixd fuel pressure spring, which claims to provide even higher fuel pressure levels than the Ford upgrade. This spring is designed to increase fuel pressure to 70-80 psi at idle and 50-55 psi at wide-open throttle, exceeding Ford's recommended fuel pressure levels for preventing injector failure. Additionally, the EightySixd spring offers improved durability, with significantly lower tension loss over extended use.

Overall, the blue spring upgrade is a cost-effective modification that can help improve fuel pressure and protect against injector wear and failure in the 6.0L Power Stroke engine. For those seeking even higher fuel pressure levels and improved spring durability, aftermarket options like the EightySixd spring provide an alternative to the Ford upgrade.
