Testing the fuel pump relay on an 86 E300 is a crucial diagnostic step to ensure proper fuel delivery and engine performance. The fuel pump relay acts as a switch, controlling power to the fuel pump, and its failure can lead to starting issues or stalling. To test the relay, start by locating it in the fuse box, typically under the hood or near the driver’s side kick panel. Use a multimeter to check for continuity across the relay’s terminals, ensuring it engages when power is applied. Additionally, swap the relay with another of the same type (e.g., the horn relay) to see if the issue persists, as this can confirm whether the relay is faulty. Always refer to the vehicle’s manual for specific relay locations and procedures to ensure accurate testing.
| Characteristics | Values |
|---|---|
| Relay Location | Typically found in the fuse box under the hood or near the battery. |
| Tools Required | Multimeter, jumper wires, battery or power source. |
| Testing Method | Measure resistance across relay pins (85 and 86) and check for continuity. |
| Expected Resistance Range | 50-150 ohms (varies by model, consult manual for exact specs). |
| Power Supply for Test | 12V DC (from battery or external source). |
| Pin Configuration | Pin 87 (power in), Pin 30 (power out), Pin 85 (ground), Pin 86 (control). |
| Symptoms of Faulty Relay | No fuel pump operation, engine cranks but won’t start, intermittent stalling. |
| Replacement Part | OEM or compatible fuel pump relay for 1986 Mercedes E300. |
| Safety Precautions | Disconnect battery before testing, avoid short circuits. |
| Additional Checks | Inspect wiring harness, fuel pump fuse, and fuel pump itself. |
