Replacing Axial Fuel In A Toyota Matrix: Step-By-Step Guide

If you're looking to replace the fuel filter on your Toyota Matrix, it's important to note that it is built into the fuel pump assembly, which is located inside the fuel tank. While the fuel tank does not need to be removed, there is an access hole under the rear bench seat that allows for the fuel pump to be removed and dismantled. The average cost for a Toyota Matrix Fuel Filter Replacement is between $97 and $124, with labor costs estimated between $53 and $67, and parts priced between $44 and $57. It's also worth noting that fuel filters are typically replaced as part of scheduled maintenance or when there is a problem with the fuel system. Additionally, factors such as driving manner, speed, air conditioner usage, tire pressure, and electrical consumption can impact the fuel consumption of your Toyota Matrix.

Fuel filter location

The fuel filter on a Toyota Matrix is built into the fuel pump assembly, which is located inside the fuel tank. There is no need to remove the fuel tank to access the fuel pump, as there is an access hole under the rear bench seat. Removing the rear seat cushion will allow access to the fuel pump assembly, which can then be dismantled to replace the fuel filter.

The fuel filter is typically mounted to the undercarriage, on the main fuel line after the fuel pump. It is usually plumbed into the high-pressure fuel supply line beneath the car, next to a sturdy frame rail.

The fuel filter is made of cellulose or synthetic-based filter media that traps contaminants such as rust particles and dirt in the fuel as it flows from the fuel tank to the fuel injectors.

Some newer cars do not have serviceable fuel filters, as the filter is built into the fuel pump located in the fuel tank.

Removing the fuel pump

To remove the fuel pump from a Toyota Matrix, follow these steps:

Firstly, remove the gas filler cap. This will start to reduce the air pressure in the fuel system. Next, remove the rear seat base. You will find fastener clips along the edges of the seat that need to be unhooked. Now, remove the fuel pump service hole cover. This will look like a metal cover plate screwed into the bodywork.

Then, disconnect the wiring plug and any connectors running into the fuel pump. Start the engine and let it run until the car stalls. This will remove any excess fuel pressure from the system. Now, disconnect the negative battery terminal from the battery, which is located under the hood.

Unscrew the circular plastic lid that holds the old pump in place. Be sure to remove any dirt from around the area first to prevent contamination. Gently lift out the old fuel pump. Remove and replace the old gasket around the access hole.

Now you can gently lower the new fuel pump into place and reconnect the wiring and cables. Replace the fuel pump service cover and rear bench seat. Reconnect the negative battery terminal and tighten the gas cap.

Finally, turn on the ignition for around 10-15 seconds to allow the fuel pump to prime itself. You may need to repeat this a few times until the system is pressurised and the car will start.

Fuel tank access

To access the fuel tank of a Toyota Matrix, you will first need to locate the fuel filter. The fuel filter is built into the fuel pump assembly, which is located inside the fuel tank.

For the 2006 model, there is no need to remove the fuel tank. Instead, you can access the fuel pump by locating the access hole under the rear bench seat. Remove the rear bench seat, then take out the cover to access the fuel pump.

For the 2003-2008 models, the process is likely to be similar, but it is always recommended to refer to your owner's manual for specific instructions.

Once you have located the access point, you will need to remove the fuel pump assembly. This typically involves releasing two lines on either end of the fuel filter and taking out any necessary screws or bolts holding the assembly in place. Be sure to have a container ready to catch any fuel that may spill during this process.

After removing the fuel pump assembly, you can then proceed to replace the axial fuel as needed. Remember to exercise extreme caution when working with fuel, and ensure that the area is well-ventilated.

Dismantling the fuel pump

To dismantle the fuel pump of a Toyota Matrix, follow these steps:

First, locate the fuel pump. The fuel pump is located inside the fuel tank, but you don't have to remove the fuel tank on this model. Instead, there is an access hole under the rear bench seat. Remove the rear bench seat and then take out the cover to access the fuel pump.

Once you have located the fuel pump, you can start the dismantling process. Here are the steps to dismantle the fuel pump:

• Disconnect the fuel lines: Before removing the fuel pump, make sure to disconnect the fuel lines that are attached to it. Place a container under the lines to catch any spilled fuel.
• Remove the fuel pump mounting bracket: The fuel pump is usually held in place by a mounting bracket. Remove the bracket to release the fuel pump.
• Separate the fuel pump from the sending unit: The sending unit is the part of the fuel pump that sends information about the fuel level to the gauge. Carefully separate the fuel pump from the sending unit.
• Dismantle the fuel pump: Depending on the design of your fuel pump, you may need to remove screws, bolts, or other fasteners to dismantle it. Be careful not to damage any internal components.
• Clean the fuel pump components: Before inspecting or replacing any parts, clean the fuel pump components with a suitable solvent to remove any built-up dirt or debris.
• Inspect and replace parts as needed: Once the fuel pump is dismantled, you can inspect the individual components for wear or damage. Replace any parts that are faulty or worn out.
• Reassemble the fuel pump: If you are just cleaning or inspecting the fuel pump, reassemble the components in the reverse order of disassembly. Make sure that all gaskets and seals are properly aligned and seated.

Please note that working on fuel system components can be dangerous, so it is important to take appropriate safety precautions and refer to a qualified mechanic or repair manual for specific instructions for your vehicle.

Fuel filter replacement cost

The fuel filter in a Toyota Matrix is built into the fuel pump assembly, which is located inside the fuel tank. The average cost of replacing the fuel filter in this car is between $97 and $124, with parts costing between $44 and $57 and labor between $53 and $67. However, some estimates place the cost of this service at around $201, with parts costing $61 and labor $140.

The cost of replacing a fuel filter depends on the type of car and the labor involved. The cost typically ranges from $90 to $142, including parts and labor. Some sources state that the average cost of a fuel filter replacement is between $70 and $150.

It is important to note that the fuel filter is a vital component of a vehicle's fuel system, and regular replacement is necessary to maintain optimal engine performance. Fuel filters should be replaced according to the manufacturer's recommended schedule, which is typically every 40,000 to 80,000 miles or every 5 years/50,000 miles.
