Installing fuel injectors in a Subaru BRZ can be a tricky process. It involves careful calibration and a number of steps to ensure that the injectors are installed correctly and function properly. The process includes disconnecting the battery negative terminal, removing protective covers, and separating the direct injector control unit. It is also important to adjust the settings in the ROM file and ensure that the injectors are compatible with the vehicle's fuel system. There are a variety of fuel injectors available for the Subaru BRZ, including those from well-known manufacturers such as Injector Dynamics, Bosch, and DeatschWerks.
Characteristics and Values Table for Installing Fuel Injectors in a BRZ
| Characteristics | Values |
|---|---|
| Vehicle Compatibility | 2013-2020 Subaru BRZ, 2013-2016 Scion FR-S, 2017-2019 Toyota 86 |
| Fuel Injector Types | Fuel Injector Clinic 660cc Injector Set, Deatschwerks 450cc Fuel Injectors, Fuel Injector Clinic 540cc Injector Set, DeatschWerks 700cc Fuel Injectors, Fuel Injector Clinic 850cc Injector Set, Fuel Injector Clinic 1200cc Injector Set, Deatschwerks 900cc Fuel Injectors, Deatschwerks 1500cc Fuel Injectors, Fuel Injector Clinic 1650cc FIC Injector Set, Fuel Injector Clinic 2150cc Injector Set |
| Installation Steps | Disconnect battery negative terminal, remove metal protective covers on inlet manifold, separate direct injector control unit, remove second metal cover, disconnect electrical connectors from injectors, loosen vehicle fuel-filler cap, install new injectors, calibrate ECU settings (Injector Flow Scaling, Injector Lag Time Offset, cranking fuel tables), program ECU, start engine, check for fuel leaks |
| Tools/Parts Required | EcuTek injector wiring adaptors, ProECU software, seal installation tool, engine oil, grease |
| Tips/Considerations | Put injectors in freezer to shrink seals, use grease on tips, line up injectors and alternate tightening fuel rail bolts to avoid crooked installation, adjust cranking maps values as needed, ensure correct MAP sensor scaling |
Explore related products
What You'll Learn
Injector installation tools and techniques
To install fuel injectors in a Subaru BRZ, you will need some specific tools and knowledge of certain techniques. Here is a step-by-step guide:
First, it is important to prepare the injectors for installation. One technique is to put the injectors into a freezer to shrink the seals. This will make it easier to install them. You can also use some grease on the tips of the injectors to ensure a smooth installation.
Next, you will need to disconnect the battery negative terminal and remove the metal protective covers on both sides of the inlet manifold. These covers are retained by two M8 (12mm headed) bolts each side. Be careful not to lose these bolts, as you will need them later.
Once the covers are removed, you will be able to access the port injectors and fuel rails. Disconnect the electrical connectors from the injectors and loosen the vehicle fuel filler cap to release fuel tank pressure. You may also need to separate the direct injector control unit from one of the covers before removing it. This is retained by 3x M6 (10mm headed) bolts.
When you are ready to install the new injectors, follow the manufacturer's instructions carefully. One important technique to remember is to alternate tightening the fuel rail bolts so that the injectors go in evenly. If you tighten one side too much, the injectors may become crooked.
After physical installation, you will need to modify some settings in the ROM file using software such as EcuTek ProECU. The Fuel Injector setting will need to be calibrated, and you may also need to adjust the cranking fuel maps. Be sure to follow the fine-tuning procedure in the BRZ Tuning Guide to ensure optimal performance.
Finally, you can start the engine and check the fuel injection system for any leaks. Only the port injectors are fired during cranking, so pay close attention to these.
