The location of the fuel pump on a 1973 Volkswagen Type 2 Bus, commonly referred to as a 73 Bus, can vary depending on the specific model and engine configuration. Typically, in air-cooled VW buses, the fuel pump is mounted on the engine itself, often near the carburetor or fuel injection system. For a Type 4 engine, which was an option in later Type 2 models, the fuel pump is usually located on the driver's side of the engine, close to the fuel filter. For the more common Type 1 engine, the fuel pump is often found on the passenger side, near the carburetor. It’s essential to consult the vehicle’s manual or a repair guide specific to your model to accurately locate and service the fuel pump.
Explore related products
What You'll Learn
Location of fuel pump in 73 bus engine bay
The fuel pump in a 1973 Volkswagen Type 2 Bus (often referred to as a "73 bus") is typically located in the engine bay, but its exact position depends on whether the vehicle has a carbureted or fuel-injected engine. For carbureted models, the fuel pump is usually mounted on the driver’s side of the engine compartment, directly on the engine block or nearby. It is often a mechanical pump driven by the camshaft, identifiable by its cylindrical shape and fuel lines connecting to the carburetor. Accessing it requires removing the engine lid and locating the pump near the rear of the engine, close to the firewall.
If your 73 bus has a fuel-injected engine (a less common modification for this era), the fuel pump is likely located within the fuel tank, as these systems use electric pumps. To access it, you’ll need to remove the rear seat or cargo floor panel to expose the fuel tank. This setup is more complex and requires caution due to the risk of fuel spillage or electrical hazards. Always disconnect the battery before working on electric fuel systems.
For carbureted models, replacing the fuel pump involves disconnecting the fuel lines, unbolting the pump from the engine block, and installing the new unit. Ensure the pump is aligned correctly to avoid leaks. Use a wrench or socket set to remove the mounting bolts, and have a catch pan ready for any residual fuel. After installation, prime the pump by turning the ignition on for a few seconds before starting the engine.
One common issue with mechanical fuel pumps on 73 buses is diaphragm failure, which can lead to reduced fuel pressure or engine stalling. Symptoms include difficulty starting, sputtering, or a whining noise from the pump. If you suspect a faulty pump, test fuel pressure using a gauge connected to the fuel line. Pressure should match the manufacturer’s specifications (typically 2-3 PSI for carbureted engines). Replacement pumps are widely available for this model, but ensure compatibility with your specific engine type.
When working in the engine bay of a 73 bus, safety is paramount. Allow the engine to cool before starting any work, and wear safety goggles to protect against fuel splashes. Keep a fire extinguisher nearby, as fuel leaks can pose a fire risk. For fuel-injected systems, relieve pressure in the fuel lines by disconnecting the fuel pump fuse and running the engine until it stalls. This step is critical to prevent accidental fuel spray during pump replacement. With proper precautions, locating and servicing the fuel pump in a 73 bus is a manageable task for DIY enthusiasts.
