Fuel Line Installation Guide: 1987 Harley Sportster

Installing a fuel line on a 1987 Harley-Davidson Sportster can seem daunting, but with the right tools and a methodical approach, it's a manageable task. This guide will walk you through the process step-by-step, ensuring you have all the necessary information to complete the installation safely and effectively. From preparing the materials to connecting the fuel line to the engine, you'll learn how to make the necessary adjustments to your Sportster's fuel system.

Prepare Tools and Materials: Gather necessary tools, fuel line, and fittings for the 1987 Harley Sportster installation

Before you begin the fuel line installation on your 1987 Harley Sportster, it's crucial to gather all the necessary tools and materials to ensure a smooth and successful process. Here's a comprehensive guide on what you need to prepare:

Tools:

• Fuel Line Cutter: Invest in a quality fuel line cutter or a pair of sharp, heavy-duty scissors. This tool is essential for precisely cutting the fuel line to the desired length.
• Fuel Line Crimper: A crimper is a must-have for installing fittings securely. Look for one with adjustable jaws to accommodate various fuel line sizes.
• Pliers: Standard pliers are useful for gripping and holding components in place during the installation process.
• Wrench Set: You'll need a set of wrenches, including a socket set, to tighten fittings and bolts. Ensure you have the appropriate sizes for your Harley's fuel system.
• Rattail File: This tool is handy for smoothing out sharp edges and ensuring a clean fit for the fuel line.
• Safety Gear: Don't forget personal protective equipment, including gloves and safety goggles, to protect yourself during the installation.

Materials:

• Fuel Line: Obtain a length of fuel line specifically designed for Harley-Davidson motorcycles. Ensure it is compatible with your 1987 Sportster model. Measure the existing fuel line to determine the required length.
• Fittings: Gather the necessary fittings, such as fuel line connectors, bends, and adapters. Common types include 90-degree bends, straight connectors, and fuel filter adapters. Ensure they are made from high-quality materials to withstand fuel pressure.
• Fuel Filter: If your Sportster doesn't already have one, consider installing a fuel filter to protect the engine from contaminants.
• Fuel Pump: Depending on your project's scope, you might need a new or rebuilt fuel pump to ensure optimal fuel delivery.

By gathering these tools and materials, you'll be well-prepared to tackle the fuel line installation on your 1987 Harley Sportster. Remember to work systematically, following the manufacturer's instructions for each component, to ensure a professional-looking and functional result.

Locate Fuel Tank: Identify the fuel tank and access points for fuel line installation

To begin the process of installing a fuel line on your 1987 Harley Sportster, you'll need to locate the fuel tank. This is a crucial step as it provides access to the necessary components for the installation. The fuel tank on a Harley Sportster is typically located on the right side of the bike, just behind the seat. It is a rectangular or oval-shaped container that holds the fuel for the engine.

Once you've identified the fuel tank, you'll need to find the access points for the fuel line installation. These access points are usually located near the tank and provide openings for the fuel lines to be connected. On a 1987 Sportster, you might find these access points as small holes or ports on the tank's surface. These openings are strategically placed to allow for easy installation and maintenance of the fuel system.

Carefully inspect the fuel tank and its surrounding areas to locate these access points. They are often marked or labeled to ensure you connect the fuel lines to the correct locations. It is essential to match the fuel lines with the corresponding access points to ensure proper functionality and prevent any fuel leaks.

When you've identified the access points, you can proceed with the installation process, ensuring that you have the necessary tools and fuel lines ready for connection. This step is fundamental to the overall success of the fuel line installation, as it provides the necessary entry points for the fuel lines to be attached securely.

Remember, the key to a successful installation is careful identification of the fuel tank and its access points, ensuring that you have a clear understanding of the bike's fuel system layout before proceeding with the work.

Cut and Connect: Carefully cut and connect fuel line to tank and engine, ensuring proper alignment

When installing a new fuel line on your 1987 Harley Sportster, the process of cutting and connecting the line requires precision and attention to detail. Here's a step-by-step guide to ensure a successful installation:

Preparation: Begin by laying out all the necessary components: the new fuel line, the fuel tank, and the engine's fuel system. Familiarize yourself with the existing fuel line's route and connections to understand the layout. It's crucial to have a clear picture of the system to make accurate cuts and connections. Gather the appropriate tools, including a fuel line cutter, a fuel line crimping tool, and a fuel filter (if you're replacing it).

Cutting the Fuel Line: Locate the old fuel line and identify the sections that need replacement. Carefully cut the old line, ensuring you have enough length to connect the new line to both the tank and the engine. Measure and mark the cuts accurately to avoid any mistakes. When cutting the new fuel line, follow the same measurements to ensure compatibility. Use a sharp, clean blade to make precise cuts, as this will impact the overall performance of the fuel system.

Connecting the Fuel Line to the Tank: Start by attaching one end of the new fuel line to the tank. Ensure a secure connection by using the appropriate crimping tool to create a tight seal. Follow the manufacturer's instructions for the specific crimping technique. Check that the line is routed correctly and securely fastened to the tank's mounting points.

Engine Connections: Now, it's time to connect the fuel line to the engine. Identify the fuel inlet on the engine and locate the corresponding port on the fuel line. Carefully align the port with the inlet and secure it using the appropriate fasteners or clips. Ensure that the connection is tight and there are no leaks. Repeat this process for any additional engine connections, such as the fuel pump or carburetor.

Alignment and Testing: Proper alignment is critical during the installation process. Ensure that the fuel line is routed correctly, avoiding any sharp bends or kinks that could restrict fuel flow. Check that all connections are secure and tight. Finally, start the engine and test the fuel system. Listen for any unusual noises and ensure that fuel is delivered to all parts of the engine as expected. If any issues arise, carefully inspect the connections and make adjustments or replacements as necessary.

Secure with Clamps: Use fuel line clamps to secure the line and prevent leaks

When installing a new fuel line on your 1987 Harley Sportster, ensuring a secure and leak-free connection is crucial. One of the most effective methods to achieve this is by using fuel line clamps. These clamps provide a reliable and adjustable way to hold the fuel line in place, offering both strength and flexibility. Here's a step-by-step guide on how to secure the fuel line with clamps:

Start by ensuring you have the appropriate fuel line clamps for your specific application. Harley Sportster models often require fuel line clamps that are compatible with the diameter of the fuel line you are using. Measure the fuel line to determine the correct clamp size. Once you have the right clamps, locate the fuel line where it connects to the fuel tank and the engine. Clean the areas where the fuel line will be clamped to ensure a tight fit. Apply a small amount of fuel line adhesive or tape to the fuel line and the clamp to create a secure bond. This step is essential to prevent any potential leaks.

Now, begin securing the fuel line. Slide the clamp onto the fuel line, ensuring it is positioned at the desired location. Tighten the clamp securely by hand, making sure it is snug but not overly tight to avoid damaging the fuel line. You can use a wrench or a specialized fuel line clamp tool to tighten the clamp further if needed. Repeat this process for each section of the fuel line, clamping it at regular intervals to ensure even tension. The goal is to create a continuous and secure path for the fuel line, minimizing any potential points of failure.

After clamping the fuel line, inspect the connections to ensure there are no visible signs of leakage. You can use a soapy water solution to test for leaks by applying it to the clamped areas. If no bubbles appear, the connection is secure. If any leaks are detected, carefully adjust the clamp position or tighten it slightly to resolve the issue. It's important to double-check all clamped sections to guarantee a professional and safe installation.

Remember, proper clamping is vital to the longevity of your fuel system. Well-secured fuel lines prevent fuel leaks, which can lead to engine performance issues and potential safety hazards. By following these steps and paying attention to detail, you can ensure a successful fuel line installation on your 1987 Harley Sportster.

Test for Leaks: Inspect all connections and test for leaks before starting the engine

Before you start the engine of your 1987 Harley Sportster, it's crucial to ensure that all fuel lines are properly installed and leak-free. This step is often overlooked, but it's an essential part of the maintenance process to prevent potential issues and ensure optimal performance. Here's a detailed guide on how to inspect and test for leaks:

Step 1: Visual Inspection

Begin by visually examining all the connections and fittings. Look for any signs of damage, cracks, or deterioration in the fuel lines. Check for any visible leaks or moisture around the connections. Pay close attention to the areas where the fuel lines connect to the fuel tank, carburetor, and engine. Ensure that all fittings are tight and secure. If you notice any damage or potential leak points, it's best to replace the affected parts before proceeding.

Step 2: Pressure Testing

Use a fuel line pressure tester or a simple pump to apply pressure to the fuel system. This test will help identify any leaks or weak points in the system. Start by attaching the tester to the fuel line, ensuring a secure connection. Gradually increase the pressure and observe for any leaks. You can use a soapy water solution to make the detection of leaks easier. If you notice any bubbles or soap suds around a connection, it indicates a potential leak. Make sure to test all critical points, including the fuel filter, carburetor, and engine connections.

Step 3: Bubble Test

Another effective method is the bubble test, which is particularly useful for identifying leaks in the fuel lines. Fill a clear container with a small amount of water and add a few drops of dish soap. Carefully immerse the fuel line connections into the soapy water and observe for any bubbles. Bubbles indicate the presence of air or fuel entering the water, which could be a sign of a leak. This test is simple yet highly effective in detecting even the smallest leaks.

Step 4: Engine Start-Up

After ensuring all connections are secure and leak-free, you can start the engine. However, do so with caution and in a well-ventilated area. Listen carefully for any unusual noises or hissing sounds, which could indicate a fuel leak. If you notice any leaks while the engine is running, immediately shut it off and address the issue.

By following these steps, you can thoroughly inspect and test for leaks in the fuel system of your 1987 Harley Sportster. This process is vital to maintain a healthy engine and prevent potential issues caused by fuel leaks, ensuring a smooth and reliable riding experience. Remember, regular maintenance and inspections can save you from potential headaches and costly repairs down the line.
