If you're looking to install a fuel line on a 1966 Chevelle, you'll want to pay attention to a few key things. The fuel system of a Chevelle consists of the fuel tank, fuel line from the tank to the engine, fuel filter, and fuel pump. When it comes to fuel lines, you have a few options. You can purchase pre-bent lines that match the original shape or opt for a braided steel line, which offers more flexibility. Additionally, you'll need to consider the fuel line size, which can range from 5/16 to 3/8 or even 1/2 for more powerful engines. Keep in mind that modern fuel can be harsh on rubber components, so choosing the right materials is crucial. You'll also need a tubing bender and a flaring kit to create a fuel line that lasts for years.
Explore related products
![JEGS 13098 Main Fuel Line, Tank to Fuel Pump for 1964-1967 Chevrolet Chevelle, Malibu Convertible, El Camino [3/8 in. O.D, Steel]](https://m.media-amazon.com/images/I/21RXQdIHuPL._AC_UY218_.jpg)
![JEGS 13140 Main Fuel Line, Tank to Fuel Pump for 1970-1972 Chevrolet Chevelle, Malibu, SS, Hardtop [3/8 in. O.D, Steel]](https://m.media-amazon.com/images/I/31Hg658h10L._AC_UY218_.jpg)
What You'll Learn
Vapor lock issues
Vapor lock is a common issue in cars, and the 1966 Chevelle is no exception. It occurs when the fuel in the line gets heated and vaporizes, causing the engine to lose fuel pressure and, in some cases, stall. Here are some detailed instructions and tips to address vapor lock issues when installing a fuel line on your 1966 Chevelle:
Understanding the Cause:
Vapor lock is typically caused by excessive heat in the engine bay. This heat can come from various sources, such as the engine itself, the headers, or the fuel pump. The fuel line, especially if it's made of rubber, can conduct this heat and cause the fuel to vaporize.
Insulating the Fuel Line:
One of the most effective ways to prevent vapor lock is to insulate the fuel line, particularly near the engine block and above the manifold. You can use reflective foil or heat-resistant materials to wrap the fuel line and protect it from the heat. This is a relatively simple and inexpensive solution that can make a significant difference.
Return Fuel Line Installation:
Some Chevelle owners have found success in combating vapor lock by installing a return fuel line. This line allows fuel to circulate back to the tank, preventing it from getting too hot and vaporizing. When installing a return fuel line, consider using an OEM 1967 steel return line with rubber gas lines at the gas tank vent and fuel filter. You can then connect it to the OEM vent tube using a T-connector.
Fuel Line Materials:
The type of fuel line you use can impact vapor lock issues. Modern fuel can be harsh on rubber products, causing them to deteriorate and fail over time. Consider using braided-steel lines, which are more durable and can handle higher temperatures. Additionally, ensure that all connections and fittings are secure and properly insulated to prevent heat transfer.
Fuel Delivery and Pump:
In some cases, vapor lock may be a symptom of a larger fuel delivery problem or a faulty fuel pump. Ensure that your fuel tank, sending unit, and fuel filter are all in good condition and not restricted. A vacuum gauge installed temporarily in the fuel line circuit can help diagnose fuel delivery issues. Additionally, consider upgrading to a more efficient fuel pump if your current one struggles in hot conditions.
Other Considerations:
- A mechanical fuel pump attached directly to the engine block can contribute to vapor lock issues. Relocating the pump or switching to an electric pump may help.
- The type of fuel you use can also impact vapor lock. ""Winter gas" tends to be worse for vapor lock, so switching to "summer gas" may alleviate the issue.
- A carb spacer can help reduce the heat transfer between the manifold and the carburetor, reducing the chances of vapor lock.
Remember to consult a professional mechanic or a Chevelle specialist if you're unsure about any aspect of the fuel line installation or vapor lock prevention.
Metal Fuel Lines: Optimal Thickness for Safety and Performance
You may want to see also
Explore related products
Fuel line size
The fuel line size for your 1966 Chevelle will depend on the engine and its performance. The stock size for the fuel line is 5/16", but for engines with higher horsepower, an upgrade to 3/8" is recommended. This is because the 5/16" line may be too restrictive for modern V-8 engines, and a larger line will allow for a higher volume of fuel to be delivered.
When upgrading the fuel system, it is important to ensure that the inside diameter of the hose and fittings maintains a minimum size. For example, if you determine that you need at least a 3/8" diameter, then you should ensure that there are no restrictions smaller than that in the entire system.
Additionally, when choosing a fuel line, consider the type of fuel you will be using. Modern fuel can be hard on rubber products, causing seepage and failure. Therefore, you may want to consider a fuel line with a polytetrafluoroethylene (PTFE) conductive-core inner liner, which is designed to resist deterioration.
If you are installing a return fuel line to combat vapor lock, as some 1966 Chevelle owners have done, you may need to drill a new hole in the tank and install an aftermarket port. This can be more time-consuming and challenging than other methods.
Finally, when installing a new fuel line, you may need to lift the body off the frame to get the line in place, especially if you are using a pre-bent line. This process can be difficult and may require special tools and knowledge.
Disconnecting Plastic Fuel Lines: A Step-by-Step Guide
You may want to see also
Explore related products
Fuel system upgrades
The fuel system of a 1966 Chevelle comprises the fuel tank, fuel line from the tank to the engine, fuel filter, and fuel pump. When upgrading the fuel system, you should consider the performance expectations and limitations of each component.
Firstly, the fuel tank does not necessarily need to be replaced if it is in good condition. However, it is recommended to clean or replace the original tank to prevent clogging fuel filters with rust and debris. Aftermarket fuel tanks with baffling can help keep fuel near the pickup tube during acceleration, turning, and braking. This is particularly important for fuel injection systems, as they lack the float bowls of a carburetor as a reserve.
Next, the fuel line should be designed to match the needs of the engine and induction system. Pre-bent fuel lines are available, but they can be challenging to install without lifting the body off the frame. A tubing bender and a flaring kit can be used to create a custom fuel line, ensuring that the inside diameter of the hose and fittings meet the minimum size requirements.
Additionally, the fuel filter and fuel pump should be considered for upgrades. Modern fuel can be harsh on rubber products, so it is essential to inspect and replace the pickup tube and fuel-sending unit assembly if needed.
Finally, carburetor upgrades or conversions to electronic fuel injection should be contemplated. The Chevelle offers various carburetor options, including the 4 Barrel Double Pumper, Vacuum Secondary, Dominator, and 2 Barrel racing carburetor.
Fuel Efficiency: In-Line Catalysts Explained
You may want to see also
Explore related products
Fuel tank and fuel pump
The fuel system of a 1966 Chevelle is made up of the fuel tank, fuel line from the tank to the engine, fuel filter, and fuel pump. The fuel tank and fuel pump are key components of the fuel system, and their installation and maintenance are crucial for the vehicle's performance and safety. Here are some detailed instructions and considerations for the fuel tank and fuel pump:
Fuel Tank:
When working with the fuel tank, it is important to use the correct components and ensure a proper seal to prevent leaks. Consider the following steps:
- Inspect the fuel tank: Before installing a fuel tank, it is essential to inspect it for any damage or corrosion. Ensure that the tank is in good condition and free from any leaks.
- Use a compatible fuel tank: The fuel tank should be compatible with your 1966 Chevelle. Consider using a factory or replacement fuel tank that meets the original equipment manufacturer (OEM) specifications.
- Check the pickup tube and fuel-sending unit: It is recommended to inspect and, if necessary, replace the pickup tube and fuel-sending unit assembly. Ensure that the components are the correct size and compatible with your vehicle.
- Maintain a minimum hose diameter: When designing the fuel system, ensure that the inside diameter of the hoses and fittings maintain a minimum size, such as 3/8 inch, to provide sufficient fuel flow.
- Consider a pre-bent fuel line: You can purchase a pre-bent fuel line that matches the exact shape of the original. This option can simplify the installation process and ensure a proper fit.
- Use compatible fittings: When connecting the fuel lines to the fuel tank, use compatible fittings, such as aluminum AN fittings. Ensure that the threads engage perfectly to avoid damaging the fittings.
- Secure the bulkhead fitting: When installing the bulkhead fitting, hold the washer and nut firmly against the inside of the fuel tank while threading the fitting. Use a wrench for a tight fit, but be careful not to force it to avoid damaging the fitting.
- Finish with the sending unit: Complete the fuel tank assembly by installing the sending unit. Inspect the O-ring and replace it if necessary to ensure a good seal. Tighten the sending unit securely against the tank.
Fuel Pump:
The fuel pump plays a crucial role in delivering fuel from the tank to the engine. Here are some considerations for the fuel pump installation and location:
- Electric vs. Mechanical Fuel Pump: Decide between an electric or mechanical fuel pump based on your vehicle's requirements and your personal preference. Electric pumps are typically more efficient and can be mounted in various locations.
- Mounting Location: The fuel pump's mounting location is important for optimal performance. Consider mounting the pump below the fuel tank to enable gravity feed. This can help prevent the pump from running dry, extending its lifespan.
- Priming the Pump: To keep the pump primed, consider mounting it on the rear inside pass frame rail near the control arm mounting area. This location allows for a drop below the sump, ensuring that the pump remains primed.
- Clearance and Accessibility: Ensure that the fuel pump has sufficient clearance and is easily accessible for future maintenance or repairs. Consider the surrounding components and the space available when choosing the mounting location.
- Compatibility and Performance: Choose a fuel pump that is compatible with your 1966 Chevelle and can deliver the required fuel flow rate. Consider the engine's specifications and performance expectations when selecting the fuel pump.
- Fuel Pump Controllers: Explore the option of using fuel pump controllers, such as the Aeromotive 340 Stealth Fuel Pump, which offers increased durability, quiet operation, and innovative baffle and tray design to control fuel slosh.
Removing Fuel Lines: A Step-by-Step Guide for Boat Owners
You may want to see also
Explore related products
Fuel line material
The fuel line material for a 1966 Chevelle is available in steel or stainless steel. The original Chevelle system used rubber to connect the steel line at the front and rear of the car. Modern fuel can be hard on rubber products, causing seepage and failure. Braided-steel lines are available, which feature a rubber lining. However, an alternative to rubber is a polytetrafluoroethylene (PTFE) conductive-core inner liner, which is designed to resist deterioration.
If you are installing a new fuel line, you can purchase pre-bent lines that are designed to fit the original shape. These can be purchased in steel or stainless steel. You can also use a tubing bender and a flaring kit to create your own fuel line.
When installing a fuel line, it is important to consider the diameter of the line. The 1966 Chevelle used 5/16-inch fuel lines, which are too restrictive for a modern V-8 engine. Upgrading to a 3/8-inch fuel line will supply the volume of fuel needed for up to 600 hp.
The installation process for a fuel line can be difficult, especially if you are trying to install it with the car fully assembled. You may need to lift the body off the frame to get the fuel line in place, and you will likely need to bend and reshape the line to fit into the factory hold-downs. It is also important to ensure that the inside diameter of the hose and fittings maintain a minimum size, such as 3/8 inch, to avoid restrictions in the system.
Disconnecting Fuel Lines: Using the Right Tool for the Job
You may want to see also
Frequently asked questions
The fuel system of a Chevelle is made up of the fuel tank, fuel line from the tank to the engine, fuel filter, and fuel pump. The first step is to decide on the size of the fuel line. The stock size line is 5/16", but you can upgrade to a 3/8" or 1/2" line for better performance. You can purchase a pre-bent fuel line or bend your own with a tubing bender and a flaring kit. You will also need to inspect and possibly change the pickup tube and fuel-sending unit assembly. Finally, follow the steps outlined in the owner's manual to install the new fuel line, making sure to connect it securely and use the correct insulation to protect the line.
The stock size fuel line for a Chevelle is typically 5/16", but it is recommended to upgrade to a larger size such as 3/8" or 1/2" to accommodate higher performance expectations and modern fuel requirements.
It is possible, but it will be a tight fit and may require some creative maneuvering. You will need to lift the body off the frame by at least 3-4 inches to get the pre-bent line in, especially if you're working on the passenger side.
Upgrading to a larger fuel line such as 3/8" or 1/2" can provide several benefits. Firstly, it can help accommodate higher performance expectations and future upgrades. Secondly, modern fuel can be hard on rubber products, and a larger steel fuel line can help deliver a higher volume of fuel and prevent seepage and failure.
When installing a fuel line on a 1966 Chevelle, there are a few common issues to be aware of. Firstly, check for rust and dirt on the frame rails and mounting clips, as these can cause problems during installation. Secondly, pay attention to the type of fuel line material used, as modern fuel can deteriorate rubber products over time. Finally, be prepared for a challenging installation process, especially when working in tight spaces or maneuvering the fuel line through the frame and engine compartment.
