Throttle Body Injection (TBI) is a type of fuel injection system that has one or two fuel injectors mounted in a throttle body. The orientation of these injectors is such that they spray fuel into the throttle body bore, right above the throttle plates. This allows the fuel to be drawn off the blades of the throttle body and into the intake manifold. TBI systems were commonly used in late 80s and early 90s vehicles, particularly in General Motors (GM) pickups with V6 and V8 engines. While TBI is considered the most primitive and least efficient of the three primary types of fuel injection systems, it served as an important transition from carburetion to multiport fuel injection (MPI).
| Characteristics | Values |
|---|---|
| Type of fuel injection system | Throttle Body Injection (TBI) |
| Number of fuel injectors | One or two |
| Mounting position | Mounted in a throttle body |
| Injector spray direction | Above the throttle plates/blades |
| Air-fuel mixture entry | Intake manifold |
| Airflow | Restricted by stock injectors |
| Fuel pressure | 11-15 psi on average |
| Fuel vaporization | Less effective than port fuel injection |
| Fuel dripping | Normal at idle |
| Fuel injector type | Low-Impedance |
| ECU compatibility | Capable of controlling Low-Impedance injectors |
| Vehicle type | Late 80s or early 90s US Domestic vehicles |
Explore related products
What You'll Learn
- TBI injectors spray fuel into the throttle body bore
- TBI is a simple, carb-like fuel injection system
- TBI injectors don't vaporise fuel as well as port fuel injection systems
- TBI injectors can be controlled by the ECU
- TBI is the most primitive and least efficient of the three primary fuel injection systems
TBI injectors spray fuel into the throttle body bore
Throttle Body Injection (TBI) is a type of fuel injection system that has one or two fuel injectors mounted in a throttle body. TBI injectors spray fuel into the throttle body bore, right above the throttle plates. This is known as the throttle body injection system, which is commonly found in late 1980s or early 1990s US Domestic vehicles.
The TBI system uses Low-Impedance Fuel Injectors, which inject fuel above the throttle blades, allowing the fuel to be drawn off the blades of the throttle body and into the intake manifold. The intake manifold then distributes the air-fuel mixture to the engine's individual cylinders.
The TBI system is simple and carb-like in appearance. It is also easy to identify, with more wires going to the throttle body than a carburetor. The TBI system is also known as a batch-fire system, where all or multiple injectors are fired at the same time.
The TBI injectors do not vaporize fuel as efficiently as a port fuel injection (PFI) system. TBI injectors operate at 11-15 psi on average, while PFI injectors operate at 40-60 psi. This difference in pressure can cause fuel to "puddle" on the throttle plate, which may appear as if the injectors are dripping fuel.
The TBI system is the most primitive and least efficient of the three primary types of fuel injection systems, which include TBI, Multiport Injection (MPI), and Gasoline Direct Injection (GDI). Despite its inefficiencies, the TBI system served as an important stepping stone in the evolution of fuel injection technology, bridging the gap between carburetors and MPI systems.
Fuel Injector Types: Identifying Your Car's Fuel Injectors
You may want to see also
Explore related products
TBI is a simple, carb-like fuel injection system
TBI, or throttle body injection, is a type of electronic fuel injection (EFI) system. It is a relatively simple system that is designed to resemble carburetors, with a single throttle body on top of the intake manifold. This throttle body contains a throttle blade and one or more fuel injectors. The fuel injectors spray fuel onto the throttle blades, which then draw the fuel into the intake manifold. This is in contrast to carburetors, which use an intake vacuum to pull fuel from the fuel bowl through the metering circuits into the air stream.
TBI systems are generally easier to work with than carburetors, as they are more reliable and consistent, especially in cold temperatures and at high elevations. They also offer better fuel economy and slightly more horsepower. Additionally, TBI systems can tolerate radical cams with durations of up to about 250 degrees, resulting in a smoother-running engine, better idling, easier starting, and improved throttle response.
One advantage of TBI systems is that they are often a direct replacement for carburetors, with similar mounting and connection methods. This makes them a popular upgrade for vehicles that traditionally used carburetors. TBI systems are also self-tuning and do not require special computer controls. However, they may require additional wiring and the addition of a camshaft position sensor.
Despite the advantages of TBI systems, there are some potential drawbacks. They may be more expensive than carburetors, with prices ranging from $2,500 to $2,700 for a typical bolt-on TBI system. Additionally, TBI systems may be more difficult to troubleshoot than carburetors, and they may have drivability issues that are not easily detected. In some cases, TBI systems may also require modifications to the air intake to achieve optimal performance.
Removing Fuel Injector Rail from 2005 Nissan Altima: Step-by-Step Guide
You may want to see also
Explore related products
TBI injectors don't vaporise fuel as well as port fuel injection systems
TBI systems, or Throttle Body Injection systems, are commonly found in late 1980s to early 1990s US vehicles. They are characterised by a throttle body with a throttle blade and one or more fuel injectors built into it. These injectors spray fuel onto the throttle blades, which is then drawn into the intake manifold. While TBI systems offer simplicity and a carburetor-like appearance, they have limitations in terms of fuel flow and power output due to the restricted number of injectors.
In contrast, port fuel injection (PFI) systems, also known as Multi-Port Fuel Injection (MPFI) systems, can have multiple injectors firing simultaneously or sequentially. This allows for finer control over the amount of fuel delivered to each cylinder, resulting in higher fuel flow rates and the ability to meet the demands of high-performance engines.
It is worth noting that TBI systems have their advantages, particularly for those seeking a simple, carburetor-like setup. They can be a valid option for moderate-performance street rods, especially if the factory intake manifold designed for TBI is utilised. However, for those seeking higher performance, fuel economy, or emissions goals, an MPFI system may be a more suitable choice.
Additionally, modern fuel systems have evolved to incorporate common rail high-pressure fuel systems, which can further enhance power output and lower emissions by pulsating the injectors at different times during the power and combustion stroke. This level of precision and control is not achievable with a TBI system without significant modifications, such as converting to a dual TBI setup or incorporating additional injectors, which adds complexity and cost.
Removing Fuel Injectors from a Ford Taurus: Step-by-Step Guide
You may want to see also
Explore related products
TBI injectors can be controlled by the ECU
TBI, or throttle body injection, is a type of fuel injection system that mimics carburetors by delivering gasoline in a single location close to the throttle plates. TBI systems usually employ a single injector for in-line engines and two injectors for V-engines. These injectors are designed for high-flow and low-pressure. TBI injectors can be controlled by the ECU (Engine Control Unit). The ECU acts as the brain of EFI systems, receiving signals from dozens of sensors installed in the vehicle and determining the optimal fuel delivery strategy. It is also responsible for controlling the fuel supply through the fuel injectors.
The ECU controls the TBI injectors by sending an electronic signal or "pulse" to open the injector, allowing fuel to pass through. In the absence of this signal, an internal spring closes the injector valve, preventing fuel flow. This process ensures that the necessary amount of fuel is delivered to the engine. TBI injectors typically inject fuel above the throttle blades, spraying fuel onto the blades and allowing it to be drawn into the intake manifold.
It is important to note that TBI injection systems commonly use low-impedance fuel injectors. This means that the ECU must be capable of controlling low-impedance injectors, also referred to as Low-Z injectors. Additionally, TBI systems operate at a higher fuel pressure than carburetors but lower than MPFI or DI systems, typically around 12-15 psi.
The ECU's control of TBI injectors can be further understood by comparing it to voice-activated lighting. In this analogy, the sensors in the vehicle act as microphones, the ECU acts as the smart device, and the fuel injectors are like smart bulbs that obey the ECU's commands. This highlights the role of the ECU in interpreting sensor data and controlling the injectors accordingly.
In some cases, such as with the Holley TBI unit, the ECU can control the firing of injectors in alternating pairs. This strategy, known as batch injection, involves firing all injectors simultaneously, regardless of the engine cycle. The ECU only needs to know the engine speed and not the specific part of the engine cycle. This simplifies the injection process and allows for fine control over the fuel delivery to each cylinder.
Chrysler Sebring's Fuel Injectors: How Many Does It Need?
You may want to see also
Explore related products
TBI is the most primitive and least efficient of the three primary fuel injection systems
TBI, or throttle body injection, is a type of fuel injection system that uses one or two fuel injectors mounted in a throttle body. It is often found on older vehicles, including those from the late 1980s to early 1990s. TBI is considered the most primitive and least efficient of the three primary fuel injection systems, which also include multiport injection (MPI) and gasoline direct injection (GDI).
TBI systems generally use a single throttle body on top of the intake manifold, with a throttle blade and at least one, but usually two, fuel injectors built into the throttle body. These fuel injectors spray fuel onto the throttle blades, allowing the fuel to be drawn into the intake manifold. While TBI is a step up from a carburetor, it is less efficient than MPI and GDI systems.
One issue with TBI systems is that they can result in uneven fuel distribution. The fuel may puddle in the intake manifold and cylinder head passages, leading to some cylinders running richer while others run leaner. This can cause problems such as reduced fuel economy, increased emissions, and even engine misfires.
Another drawback of TBI systems is that they are less precise than other fuel injection systems. In MPI systems, for example, the injectors are located directly above each intake valve, allowing for more precise fuel delivery. TBI systems also tend to have lower fuel pressure than MPI systems, which can affect the atomization of the fuel.
Despite its limitations, TBI remains a popular choice for those looking to convert their carbureted engines to fuel injection. Conversion kits are readily available and TBI is often seen as a good compromise between carburation and more complex fuel injection systems.
Bosch Fuel Injectors: Where Are They Manufactured?
You may want to see also
Frequently asked questions
Throttle Body Injection (TBI) is a type of fuel injection system that has one or two fuel injectors mounted in a throttle body.
The injectors deliver fuel into the air above the throttle plates. From there, the air-fuel mixture enters the intake manifold, where it is distributed to the engine’s individual cylinders.
TBI systems were used in a variety of different production vehicles during the late 1980s and early 1990s. Some well-known applications include the V6 and V8 engines found in General Motors (GM) pickups.
