Fuel tank baffles are an essential component of vehicle performance, particularly for those converted to EFI. Baffles are used to control fuel slosh, which can cause fuel starvation and negatively impact lap times and speed. The placement of baffles is critical, as improper positioning can lead to issues during turns when fuel is pulled away from the pump. For vehicles used in drag racing, a fuel cell is an effective solution, while road racing may require a different baffle installation method. The type of vehicle and its intended use are key factors in determining the ideal location and configuration of baffles within the fuel tank.
Characteristics and Values of Fuel Tank Baffle Placement
| Characteristics | Values |
|---|---|
| Placement | Baffles should be placed in the correct location to control fuel slosh, especially during turns |
| Fuel Pump Position | The fuel pump should not be mounted at the front corner of the tank to avoid fuel starvation issues |
| Baffle Size | The baffled area for the fuel pump should be small enough to control fuel slosh effectively |
| Baffle Type | Vertical baffles are used to prevent horizontal travel of fluids |
| Attachment Method | Bolts or magnets can be used to secure baffles, with bolts preferred to avoid potential damage from magnets |
| Fuel Return Line | Dumping the fuel return line into the sump can help with fuel starvation issues |
| Fuel Type | Baffles are important for vehicles with fuel injection systems to maintain consistent pressure |
Explore related products
What You'll Learn
Fuel tank baffle requirements
Firstly, fuel tanks must adhere to specific construction and installation requirements. These requirements include the use of approved materials, such as nickel-copper for tanks up to a certain capacity, and the thickness of the tank walls. All joints and fittings must be securely welded or brazed to prevent leakage. Fuel tanks must also be adequately supported, electrically bonded to the common ground, and installed to allow for examination, testing, and removal for cleaning.
Baffle plates, when required, must be constructed from the same material as the fuel tank and be of equal or greater thickness. They should be securely connected to the tank walls by welding or brazing. Limber holes at the bottom and air holes at the top of the baffle plates are essential for proper ventilation and fuel flow. The placement of the baffles within the fuel tank is critical to their effectiveness.
The location of the fuel pump in relation to the baffles is a key consideration. Mounting the fuel pump in the front corner of the tank, as in the case of Project Track Attack, resulted in fuel starvation issues during right turns. The baffles must be positioned to ensure consistent fuel delivery to the pump during various driving conditions, including left and right turns, acceleration, and deceleration.
Additionally, the driving style and intended use of the vehicle should influence the design and placement of the baffles. For example, a fuel cell with a smaller baffled area may be suitable for drag racing, while a road racing or regular driver may require a different baffle configuration to maintain fuel volume and trunk space. The use of magnets to secure baffles in plastic fuel tanks has been suggested, but there are concerns about potential damage to the tank and the strength of the magnets. Proper research and consultation with experts are recommended to ensure the effectiveness and safety of any baffle installation.
