If your car's engine is acting up, a blown fuel injector fuse could be the culprit. This fuse is located in the primary fuse box, which is often found inside the cabin on the driver's side, near the pedals, or to the left of the steering column. For trucks, larger SUVs, and older vehicles, the main fuse box may be under the hood in the engine compartment. In some European models and vehicles with complex electrical systems, a secondary fuse box may be located in the trunk, behind a side panel, or under the floor covering. Once you've located the fuse box, look for a diagram with labels related to the fuel system, such as Fuel Injector or Electronic Fuel Injection.
| Characteristics | Values |
|---|---|
| Location of the primary fuse box | Inside the cabin on the driver's side, under the hood in the engine compartment, or in the trunk |
| How to access the fuse box | Look for a small access panel near the pedals or to the left of the steering column; it may have a latch or tabs to open |
| Location of the secondary fuse box | In some European models or vehicles with complex electrical systems, it may be located in the trunk behind a side panel or under the floor covering |
| Identifying the fuel injector fuse | Look for labels such as "Fuel Injector," "INJ," "EFI," "Fuel Pump/Injectors," "Engine Control Module (ECM)," or "Powertrain Control Module (PCM)" on the diagram inside the fuse box lid |
| Fuse information | The fuse will have a number or letter indicating its amperage rating (e.g., 10A, 15A, 20A) |
Explore related products
What You'll Learn
- The primary fuse box is often located inside the cabin, on the driver's side
- In trucks and larger SUVs, the main fuse box is usually under the hood
- In some European models, there might be a secondary fuse box located in the trunk
- Common labels to look for include Fuel Injector, often abbreviated as INJ
- If there's a problem with the fuel injector circuit, the car scanner may display codes like P0200
The primary fuse box is often located inside the cabin, on the driver's side
When your car's engine starts acting up and you suspect a blown fuel injector fuse, you'll want to locate the fuse box as soon as possible. In a large number of sedan and smaller SUV models, the primary fuse box is often located inside the cabin, tucked away on the driver's side. This is a good place to start your search for the fuel injector fuse.
Get down near the pedals and look for a small access panel, usually made of plastic. This panel might have a latch or a couple of tabs that you need to press to open it. Sometimes, it's situated to the left of the steering column, down near where your left knee might rest.
If you can't find the fuse box on the driver's side, don't worry. Another very common location for the main fuse box, especially in trucks, larger SUVs, and some older vehicles, is under the hood in the engine compartment. So, if you've checked the driver's side and it's not there, head over to the engine compartment and look for the fuse box there.
In some less common scenarios, particularly in certain European models or vehicles with more complex electrical systems, you might find a secondary fuse box located in the trunk. This could be behind a side panel or under the floor covering where the spare tire is stored. So, if you've checked the usual spots and still haven't found it, don't rule out the trunk just yet. Remember to refer to the owner's manual if you need more specific information about your vehicle's fuse box location.
