The fuel filter in a Ford F350 is located between the fuel bowl on the primary side of the carburetor and where the fuel line hooks to it. The vehicle has two fuel filters. The first filter mounts on top of the engine on the left-hand side. The second filter is inside the diesel fuel conditioner module, which is attached to the fuel tank. The location of the filter varies depending on the model year of the Ford F350. For instance, for the 2017 model, the fuel line quick-connect coupling needs to be disconnected from the in-tank fuel pump.
| Characteristics | Values |
|---|---|
| Location of the fuel filter | Between the fuel bowl on the primary side of the carburetor and where the fuel line hooks to it |
| Number of fuel filters | 2 |
| Location of the first filter | On top of the engine on the left-hand side |
| Location of the second filter | Inside the diesel fuel conditioner module |
| Fuel filter type | Brass style filter |
| Fuel filter replacement | Ford fuel filters are the only recommended fuel filters for Ford and Lincoln vehicles |
| Fuel filter replacement cost | $6.07 (Motorcraft Fuel Hose KFL-34 for 1994-1997 FORD F350) to $79.95 (Fuel Filter for 2011-2016 Ford F-350 Super Duty 6.7L V8) |
Explore related products
What You'll Learn
The fuel filter location for a 2017 Ford F350
The fuel filter on a 2017 Ford F350 is located externally. To change the filter, you must first drain it and remove the five screws. The filter should then slide over and lock into the lower half of the housing, allowing you to grab and pull it straight down out of the upper housing.
The fuel filter is part of the fuel system, which includes the fuel tank, fuel pump, fuel lines, and fuel injectors. The filter's job is to remove impurities from the fuel before it reaches the engine. Over time, the filter can become clogged with debris, reducing fuel efficiency and engine performance.
For the 2017 model, you must disconnect the fuel line quick connect coupling from the in-tank fuel pump. Place a drain pan under the water in the fuel separator filter housing found under the cab between the frame rails. Remove all three fuel lines going to the filter by sliding the plastic clips over and pulling the lines away from the filter one at a time. Loosen the filter from its housing by turning it a quarter turn, then install the new fuel filter and tighten it into the housing.
Reinstall all three fuel lines into the filter and lock the clips into place. Finally, cycle the key to the "ON" position and leave it for 30 seconds while the fuel pump primes the fuel system.
It is recommended that you replace your fuel filter every 10,000-25,000 miles, depending on your driving habits and the quality of fuel used.
Solvent Fuel Filters: Function and Importance
You may want to see also
Explore related products
The fuel filter location for a 1992 Ford F350
The 1992 Ford F350 has a 7.3L fuel/water separator/filter. The fuel filter is located between the fuel bowl on the primary side of the carburetor and where the fuel line hooks to it. It is a brass-style filter.
Your vehicle has two fuel filters. The first filter mounts on top of the engine on the left-hand side. The second filter is inside the diesel fuel conditioner module. The module is attached to the fuel tank in different locations depending on the configuration of your truck.
For example, the module is at the front of the fuel tank or at the front of the aft-axle fuel tank on some models. Regular fuel filter changes are an important part of engine maintenance. Failing to keep up with scheduled maintenance could lead to engine performance issues and fuel injection system damage.
When changing the engine-mounted and diesel fuel conditioner, it is important to note that although the fuel system is not fully pressurized when the vehicle is off, some residual pressure may remain in the fuel system. This is because it can take some time for the pressure to completely bleed off. Therefore, it is recommended that you place an absorbent cloth below the filter connectors to absorb any fuel that may drain. The engine-mounted fuel filter is a plastic disposable cartridge.
Fuel Filter Installation Guide for Poulan Woodshark
You may want to see also
Explore related products
The fuel filter location for a 1986 Ford F350
The 1986 Ford F350 has two fuel filters. The first filter is mounted on top of the engine, on the left-hand side. This is a plastic disposable cartridge. The second filter is inside the diesel fuel conditioner module, which is attached to the fuel tank. The module can be found either at the front of the fuel tank or at the front of the aft-axle fuel tank, depending on the configuration of your truck.
To change the engine-mounted filter, you will need to remove the lower portion of the diesel fuel conditioner module housing. Slide the filter element toward the drain plug to disengage the securing clips. Then, slide the new filter element into the housing and fully engage the securing clips. Finally, install the lower portion of the housing and tighten the bolts.
The carb inlet fuel filter is located in between the fuel bowl on the primary side of the carburetor and where the fuel line hooks to it. It is a brass-style filter.
Cadillac DeVille: Locating the Fuel Filter
You may want to see also
Explore related products
The fuel filter location for a 2014 Ford F350
The 2014 Ford F350 with a 6.7L diesel engine has two fuel filters. The first filter is mounted on top of the engine on the left-hand side. The second filter is inside the diesel fuel conditioner module, which is attached to the fuel tank. The module can be found either at the front of the fuel tank or at the front of the aft-axle fuel tank, depending on the configuration of your truck.
To change the engine-mounted fuel filter, you will need to remove the lower portion of the diesel fuel conditioner module housing. Slide the filter element towards the drain plug to disengage the securing clips. Then, slide the new filter element into the housing and engage the securing clips. Finally, install the lower portion of the housing and tighten the bolts.
The fuel filter in the diesel fuel conditioner module can also be changed. To do this, first drain the diesel fuel conditioner module by turning the drain plug counterclockwise. Then, disconnect the electrical connector and loosen the bolts securing the lower portion of the module housing. Do not fully remove these bolts. Next, locate and drain the filter. Finally, install the new filter and reverse the previous steps to reassemble the module.
It is important to note that the fuel system may still have residual pressure when the vehicle is off, so it is recommended to place an absorbent cloth below the filter connectors to absorb any fuel that may drain.
Jeep Grand Cherokee Fuel Filter Cost and Replacement Guide
You may want to see also
Explore related products
The fuel filter location for a 2011-2016 Ford F350
The fuel filter is always located between the fuel tank and the engine. In most vehicles, the fuel filter is located inside the top of the fuel tank, where it connects with the fuel line. However, in some cars, it might be located elsewhere along the fuel line.
The 2011 Ford F350 does not have an inline filter. It only has a filter screen in the tank, which does not have a maintenance interval.
The fuel filter in the 2014 Ford F150 is located inside the driver's side door, close to the frame well and along the fuel line. It is easy to find and relatively affordable to replace.
For the 2016 Ford F350, the fuel filter is located behind a guard. To access it, you need to loosen the bolt with a 10mm wrench, swing the guard up and out of the way, disconnect the sensor wire, and then use a 32mm socket to remove the canister.
It is recommended that you change your fuel filter every 5 years or 50,000 miles, but this may vary depending on your driving habits and other factors.
Where's the Fuel Filter on a 2001 Dodge Ram 1500?
You may want to see also
Frequently asked questions
Your vehicle has two fuel filters. The first filter mounts on top of the engine on the left-hand side. The second filter is inside the diesel fuel conditioner module, which is attached to the fuel tank.
First, loosen the fuel filter housing about three turns prior to draining it. This will keep additional fuel from entering the housing when draining. Then, slide the filter element toward the drain plug to disengage the securing clips.
Turn the ignition on multiple times without starting the engine. The vehicle uses an electric lift pump to circulate the fuel from the tank through the filters. By cycling the key, it pumps the fuel up to the filter housing and returns it to the tank.
Ford fuel filters are the only fuel filters recommended for Ford and Lincoln vehicles. You can purchase a Ford filter kit from Walmart.
Regular fuel filter changes are an important part of engine maintenance. Using fuel that has high levels of impurities may require more frequent filter replacements.
