Edelbrock 8123 is a pre-fitted stainless steel fuel line kit for Edelbrock carburetors. It is designed for Edelbrock fuel pumps with a 3/8 pipe thread and comes with a fuel pressure adapter fitting, a 0-15 PSI fuel pressure gauge, a 90-degree max flow swivel hose end, and a 6' Pro-Flo 200 series stainless steel braided hose. The kit also includes two aluminum pipe plugs and a banjo fitting. When it comes to the fuel return line for the SBC 350 engine, some prefer to use a T-fitting with 6AN fittings for the inlet and outlet to the carb, and a reducer to 4AN for the return line. However, others suggest that a fuel pressure regulator set to 5.5 psig is sufficient without the need for a return line.
Explore related products
What You'll Learn
Edelbrock 8123: Pre-Fitted Stainless Steel Fuel Line Kit
Edelbrock's 8123 Pre-Fitted Stainless Steel Fuel Line Kit is a high-quality fuel line kit designed for mechanical fuel pumps with a 3/8" NPT outlet. It is compatible with Edelbrock Single- or Dual-Feed fuel inlet kits #8128, #8131, #8133, or #8134. The Edelbrock #8123 kit is specifically tailored for S/B Chevy, S/B Chrysler, and B/B Chrysler applications, offering a clean and precise fuel supply line.
The kit includes a range of essential components for a seamless installation:
- Fuel Pressure Adapter Fitting -6AN Male to 3/8" NPT
- 0-15 PSI Fuel Pressure Gauge
- 90° Max Flow Swivel Hose End -6AN
- Pro-Flo 200 Series Stainless Steel Braided Hose -6AN
- Red/Blue Banjo Fitting 9/16"-24 Thread to -06AN Hose
- Aluminum Pipe Plugs 3/8" NPT
The Edelbrock 8123 kit has received generally positive reviews, with many users praising its ease of installation, attractive appearance, and high quality. It is worth noting that some users have encountered issues with the elbow fitting not being compatible with their fuel pump, requiring additional purchases for a successful installation.
When it comes to the size of the fuel line for an SBC 350, a 3/8" line is commonly recommended. This size ensures adequate fuel flow and can be a good choice for future motor upgrades. It is important to ensure that all components, including the sending unit, have the correct size connections to prevent leaks and optimize fuel delivery.
Fuel Line Sizing for 500HP: Choosing the Right Diameter
You may want to see also
Explore related products
SBC 350 + Edelbrock 1406 fuel return line
The Edelbrock 1406 carburettor operates best with a fuel pressure of 4 3/4 to 5 psi at the bowl inlet. A fuel pressure regulator set to 5.5 psig is also recommended.
To run a return line off a mechanical pump, your pump will need to have three openings: one for suction from the tank, one for pressure to the carb, and a third for the return line to the tank. A pressure regulator may not work well with a mechanical fuel pump due to the pulses generated by the pump. Therefore, it is recommended to choose a mechanical pump with limited pressure and use it without a regulator.
One user with the SBC 350 and Edelbrock 1406 setup recommends installing a permanently mounted small pressure gauge downstream of the regulator to be sure of the pressure at all throttle conditions. They also suggest using 6AN fittings for in and out to the carb and a reducer to 4AN for the return line.
Another user recommends using generic pumps from Carter or Airtex and notes that a standard 2-port pump can be used if you don't want to use a return line. For the fuel line from the fuel pump to the carb on a 350 engine, one user recommends a 3/8" line, which they found to be suitable for future motor upgrades.
Fuel Line Size for CT70: Choosing the Right Fit
You may want to see also
Explore related products
$7.99 $9.98
SBC 350 fuel line sizing
The standard size for an SBC 350 fuel line is 3/8". This size is commonly recommended by mechanics and enthusiasts alike, and many pre-flared steel lines of this diameter are readily available at auto parts stores. This size is also compatible with many fuel pumps, including those with 3/8" pipe thread, such as the Edelbrock fuel pump.
However, it's worth noting that some fuel pumps may require a different fuel pump fitting. For example, when using a stock fuel pump with the Edelbrock 8123 carburettor, a 1/4 npt X 3/8 elbow fitting is needed. In some cases, you may need to purchase additional fittings or make adjustments to ensure a proper connection.
When considering fuel line sizing, it's important to think about the entire fuel system. For instance, the sending unit should also be considered, as it can create a bottleneck if it is a smaller size, such as 5/16". Additionally, if you plan on upgrading your engine in the future, a 3/8" fuel line is a good choice as it offers compatibility with larger engines.
While a 3/8" fuel line is generally sufficient, some enthusiasts suggest that going up to a 1/2" line may be beneficial, especially if you plan on adding nitrous later. This larger size can provide increased fuel flow and help accommodate future modifications. However, it's important to balance this with the potential for excess fuel, which can be a safety concern.
Fuel Line Size Guide for the Honda CB350: Get It Right
You may want to see also
Explore related products
SBC 350 fuel line materials
When it comes to choosing the right fuel line for your SBC 350 engine, it's important to consider not only the size but also the material. The most common materials used for fuel lines are steel and rubber, each with its own advantages and considerations.
Steel Fuel Lines
Steel, especially stainless steel, is a popular choice for fuel lines due to its durability and resistance to corrosion. Pre-flared steel lines are readily available from most auto parts stores, offering convenience and ease of installation. They are also a good option if you plan to upgrade your motor in the future. However, it's important to ensure that the fittings are compatible with your fuel pump, as some users have encountered issues with elbow fittings not matching up correctly, requiring additional adjustments or modifications.
Rubber Fuel Lines
Rubber fuel lines offer flexibility and are often used in conjunction with steel lines to provide a secure connection. They can be a good alternative if you encounter compatibility issues with steel lines. However, they may not offer the same level of durability and corrosion resistance as steel.
Fuel Line Kits
Edelbrock offers pre-fitted stainless steel fuel line kits specifically designed for Edelbrock carburetors and fuel pumps. These kits include all the necessary components for a straightforward installation, although some users have reported minor fitting issues. It's always a good idea to carefully review the specifications and consider the experiences of other users before making a purchase.
In conclusion, when choosing the fuel line material for your SBC 350, consider the compatibility, durability, and ease of installation offered by different options. Both steel and rubber fuel lines have their advantages, and fuel line kits can provide a convenient all-in-one solution, ensuring you have everything you need for the job.
Emergency Fuel Line Repair: Temporary Plug Solutions
You may want to see also
Explore related products
SBC 350 fuel line installation
The SBC 350 engine is a small-block engine produced by Chevrolet, with a displacement of 350 cubic inches (5.7 litres). It's a popular choice for car enthusiasts due to its performance capabilities and relatively simple installation. Here's a step-by-step guide to installing the fuel line for an SBC 350 engine:
Step 1: Understanding the Fuel Line System
The SBC 350 engine typically uses a high-pressure fuel supply system, which can be either a carbureted or fuel-injected system. The fuel line is responsible for delivering fuel from the tank to the engine, and it's important to ensure an uninterrupted flow of fuel to the engine to maintain optimal performance.
Step 2: Selecting the Correct Fuel Line Size
The size of the fuel line is crucial for the proper functioning of the engine. The most common recommendation for the SBC 350 engine is to use a 3/8-inch fuel line. This size ensures adequate fuel flow and can accommodate future engine upgrades. However, some engines may have unique requirements, so it's important to consult a professional or refer to specific engine specifications.
Step 3: Preparing the Fuel Line
Before installation, it's essential to ensure that the fuel line is in good condition and free of any damage or leaks. You can purchase pre-flared steel lines from auto parts stores, which can save time and effort. Additionally, consider using a regulator to maintain correct fuel pressure and a fuel filter to ensure that the fuel remains clean before entering the engine.
Step 4: Installation Process
The installation process can vary depending on the specific vehicle and engine configuration. It's important to refer to the vehicle's repair manual or seek guidance from a qualified mechanic. The fuel line should be securely connected to the fuel pump, carburetor, and any other relevant components, ensuring that all connections are tight and sealed to prevent leaks.
Step 5: Testing and Verification
Once the fuel line is installed, it's crucial to test the system for leaks and ensure that the fuel flow is uninterrupted. Start the engine and carefully inspect all connections for any signs of leakage. Additionally, verify that the engine performance meets expectations, including smooth idling and adequate acceleration.
Step 6: Maintenance and Care
Proper maintenance of the fuel line is essential to ensure the long-term performance and safety of the vehicle. Regularly inspect the fuel line for any signs of wear, corrosion, or damage, and replace it if necessary. Keep the fuel line connections clean and consider using fuel treatments to maintain fuel quality.
In conclusion, installing the fuel line for an SBC 350 engine requires careful attention to detail and a good understanding of the engine's fuel system. By following the steps outlined above, you can ensure a successful installation that delivers optimal fuel flow and performance for your SBC 350 engine.
