The common rail diesel injection system is a direct fuel injection system used in diesel engines. It is a cost-effective and fuel-efficient system that has become the gold standard for all diesel engines. The common rail is a reservoir where high-pressure fuel is stored and passed into the injectors for injection. The pressure is maintained by a pressure control valve, and the fuel injectors are controlled by the engine control unit (ECU). Injecting fuel at high pressure delivers power and fuel consumption benefits by injecting fuel as a larger number of smaller droplets, giving a much higher ratio of surface area to volume. This provides improved vaporization from the surface of the fuel droplets, and so more efficient combining of atmospheric oxygen with vaporized fuel, delivering more complete combustion.
| Characteristics | Values |
|---|---|
| Definition | A direct fuel injection system used in diesel engines |
| Composition | Injection pump, the rail, injectors and sensors |
| Function | The high-pressure pump pressurizes the fuel and transfers it to the rail, which acts as a pressure accumulator and reservoir |
| Pressure | Over 2,000 bar or 200 MPa or 29,000 psi |
| Injectors | Solenoid valves or piezoelectric injectors |
| Fuel Injection | Multiple close injections increase efficiency |
| Fuel Consumption | Improved fuel economy |
| Emissions | Lower emissions |
| Noise | Lower engine noise |
| Flexibility | Fuel pressure independent of engine speed and load conditions |
| Performance | Higher torque, improved power, and overall performance |
Explore related products
What You'll Learn
Common rail direct fuel injection
Common rail injection is commonly used in diesel engines and is the basis for gasoline direct injection systems in petrol engines. The technology was pioneered in 1916 by Vickers, who utilised mechanical common rail systems in G-class submarine engines. From 1921 to 1980, Doxford Engines employed a common rail system in their opposed-piston marine engines, generating pressures of around 600 bars.
The common rail system offers several advantages over traditional diesel systems. Firstly, it requires little to no heating-up time, depending on the ambient temperature. Secondly, it produces lower engine noise and emissions. This is achieved through the electronic control unit, which can inject a small amount of diesel prior to the main injection event, reducing explosiveness and optimising injection timing. Additionally, the high-pressure fuel injection system provides better fuel atomisation, resulting in improved combustion, greater economy, and quieter engine operation.
The key components of a common rail system include the electric feed pump, filter, overflow valve, return manifold, high-pressure pump, and high-pressure control valve. The electric feed pump supplies fuel to the high-pressure pump, which increases the pressure of the diesel fuel. The filter ensures system cleanliness and longevity, while the overflow valve allows excess fuel to return to the fuel tank. The return manifold controls the return of fuel to the tank, and the high-pressure control valve regulates the pressure generated within the pump electronically.
The development of common rail systems began in the late 1980s to early 1990s, with the goal of creating a fuel system for future diesel-powered passenger cars. Researchers such as Rudolf Diesel laid the groundwork for modern common rail diesel fuel injection systems, with Vickers Ltd. of Great Britain patenting a common rail fuel injection system with mechanically actuated injectors in 1913. The first common-rail-diesel-engine used in a road vehicle was the MN 106-engine by East German VEB IFA Motorenwerke Nordhausen, fitted to a single IFA W50 in 1985.
How Diesel Fuel Can Kill Wasps
You may want to see also
Explore related products
Injectors and sensors
Injectors are a critical component of a diesel fuel rail. They are responsible for injecting the highly pressurised fuel stored in the common rail into the cylinders. The injectors are controlled and operated by the Engine Control Module (ECM), which takes into consideration multiple sensor and signal inputs. The ECM receives feedback from various sensors in the system, such as the fuel temperature sensor, and adjusts the pressure and fuel injection accordingly.
The fuel injectors are typically controlled by the Engine Control Unit (ECU). When electrically activated, a hydraulic valve, consisting of a nozzle and plunger, is mechanically or hydraulically opened, and fuel is sprayed into the cylinders at the desired pressure. The injectors in a common rail system are designed to inject fuel as a larger number of smaller droplets, which increases the surface area to volume ratio. This improves vaporisation and allows for more efficient combustion.
Third-generation common rail diesels feature piezoelectric injectors, which offer increased precision and can handle fuel pressures up to 2,500 bar (250 MPa or 36,000 psi). These injectors are electronically controlled, allowing for fine adjustments to the fuel injection time and quantity. This technology also enables better fuel atomisation, resulting in lower engine noise and improved fuel efficiency.
In addition to the fuel temperature sensor, other sensors in the system may vary depending on the specific vehicle and system configuration. Proper sensor functioning is crucial for optimal performance and longevity of the diesel fuel rail system. Sensors provide critical data to the ECM, which uses this information to make adjustments and ensure the system operates efficiently and within safe parameters.
The sensors and the ECM work together to ensure precise control of the injectors, optimising the injection timing and quantity based on various factors such as fuel quality and engine temperature. This level of control and precision contributes to the overall performance, efficiency, and reliability of the diesel fuel rail system.
Destroying Tree Stumps: Using Diesel Fuel for Quick Results
You may want to see also
Explore related products
Fuel pressure independent of engine speed
A diesel fuel rail is a component of a direct fuel injection system. It is a high-pressure reservoir that stores diesel fuel before it is injected into the engine cylinders. The pressure in the fuel rail is maintained by a high-pressure pump, which ensures that the fuel is always available to the injectors at high pressure, regardless of engine speed.
In traditional diesel engines, the injection pressure is directly proportional to engine speed. This means that the highest injection pressure can only be achieved at the highest engine speeds, and the maximum achievable injection pressure decreases as engine speed decreases. This limitation is overcome by common rail systems, which can provide high-pressure fuel injection even at low engine speeds.
The fuel pressure in a common rail system is independent of engine speed because the fuel pressure energy is stored remotely in the accumulator (rail) and the injectors are electrically actuated. This allows the injection pressure to remain near the pressure in the accumulator, regardless of engine speed. As a result, the common rail system offers greater flexibility in controlling fuel injection quantity and timing, enabling better spray penetration and mixing, even at low engine speeds.
The ability to maintain fuel pressure at low engine speeds allows engines to produce higher torque in such conditions, especially when combined with a variable geometry turbocharger (VGT). This feature is particularly advantageous for diesel-powered passenger cars, as it improves driving comfort and fuel economy while complying with emission limits.
To control the pressure in the common rail, several approaches can be employed. One early method involved supplying excess fuel to the common rail and using a pressure control valve to spill the excess back into the fuel tank. More advanced approaches involve metering the fuel at the high-pressure pump to minimize the amount of fuel pressurized to rail pressure. This can be achieved through inlet metering, outlet metering, or by varying the effective displacement of the high-pressure pump.
Using Diesel Fuel in Oil Heaters: Is It Safe?
You may want to see also
Explore related products
Common rail pressure control
Common rail systems are widely used in diesel engines. They are high-pressure direct fuel injection systems that feed solenoid valves. The key components of a common rail system are:
- Electric feed pump
- Filter
- Overflow valve
- Return manifold
- High-pressure pump
- High-pressure control valve
- Injectors
- Engine Control Module (ECM)
- Fuel temperature sensor
The high-pressure pump is the heart of the fuel system, increasing the pressure of the diesel fuel. The high-pressure control valve controls the pressure generated within the pump electronically. The pressure in the common rail is monitored by a pressure sensor, and the difference between the nominal rail pressure value and the measured value is the input signal for the controller.
There are several approaches to controlling the pressure in the common rail. One early approach was to supply more fuel than needed to the common rail and use a pressure control valve to spill excess fuel back into the fuel tank. This method is still used in some systems, but it is less efficient as it can result in excessively high fuel return temperatures. A more preferred approach is to meter the fuel at the high-pressure pump to minimize the amount of fuel pressurized to the rail pressure. This can be done through inlet metering or outlet metering.
The injectors in the common rail system are controlled and operated by the ECM, which adjusts the pressure and fuel injection according to sensor and signal inputs. The ECM can inject a small amount of diesel before the main injection event ("pilot" injection) to reduce explosiveness and vibration, optimizing injection timing and quantity for variations in fuel quality and cold starting.
The fuel injectors are typically controlled by the Engine Control Unit (ECU). When the fuel injectors are electrically activated, a hydraulic valve is opened and fuel is sprayed into the cylinders at the desired pressure. Third-generation common rail diesels feature piezoelectric injectors, which allow for increased precision and higher fuel pressures.
Flex Fuel vs. Diesel: What's the Difference?
You may want to see also
Explore related products
Advantages of common rail systems
A common rail system is a fuel injection system designed for modern diesel engines. It offers precise control over fuel injection, resulting in improved performance and efficiency.
Improved Fuel Efficiency
The common rail system provides precise control over fuel injection timing and pressure, ensuring that the ideal amount of fuel is delivered when it is needed. This optimization of the combustion process results in substantial improvements in fuel economy, reducing operational costs.
Reduced Emissions
The precise control over fuel injection also helps to curb harmful emissions. By optimizing the combustion process, the system ensures that fuel is used more efficiently, reducing the environmental impact of diesel engines.
Enhanced Performance
The common rail system's ability to fine-tune fuel injection ensures that the engine operates at peak performance levels. This results in amplified power and torque output, making it particularly advantageous for heavy-duty trucks dealing with heavy loads or challenging terrain.
Durability and Reliability
Common rail systems are designed with durability and reliability in mind. The high-pressure components are engineered to withstand the demanding conditions often encountered in heavy-duty trucking. This robustness translates into fewer breakdowns, reduced maintenance costs, and improved long-term durability for the engine.
Flexibility in Design
The flexibility provided by common rail systems allows Original Equipment Manufacturers (OEMs) to design for optimum performance and exceptional end-user value. This flexibility enables compliance with stringent emission control standards while also improving fuel consumption and power.
The advantages of common rail systems have made them a popular choice in the diesel engine industry, particularly in heavy-duty trucks where their economic and environmental benefits are most pronounced.
Understanding Diesel Fuel Cost Fluctuations
You may want to see also
Frequently asked questions
A diesel fuel rail is a component of a common rail diesel injection system. It is a reservoir where high-pressure fuel is stored and then passed into the injectors for combustion.
It is a cost-effective and fuel-efficient fuel injection system that is widely used in diesel engines. It is composed of an injection pump, the rail, injectors, and sensors which detect the operating conditions of the engine for a centralized electronic unit (ECU) which manages all the components.
The system offers improved fuel economy, lower emissions, more power, and improved torque. It also requires little to no heating-up time and produces lower engine noise.
The high-pressure pump pressurizes the fuel and transfers it to the rail, which acts as a pressure accumulator and reservoir. The pressure is regulated by an electronically-controlled valve so that the rail maintains the correct pressure required by the ECU. The fuel then reaches the injectors, which are controlled and operated by the ECM/ECU after taking into consideration multiple sensor and signal inputs.
Early researchers, including Rudolf Diesel, worked with fuel systems that contained some of the essential features of modern common rail diesel fuel injection systems. In 1913, a patent for a common rail fuel injection system with mechanically actuated injectors was issued to Vickers Ltd. of Great Britain. Development programs in the late 1980s and early 1990s aimed to create a fuel system for future diesel-powered passenger cars, and the common rail injection system became the gold standard for all diesel engines.
