Fuel Pressure Requirements For The Mk3 Supra Explained

The fuel pressure for a Toyota Supra MK3 depends on a variety of factors, including the age and condition of the injectors, the type of fuel pump, and the desired horsepower. Some sources suggest that the fuel pressure should be set at around 30 psi, while others recommend a higher pressure of 40-44 psi. It is important to note that increasing fuel pressure can lead to running too rich, and it is generally recommended to upgrade to larger injectors instead of increasing fuel pressure to unsafe levels. Additionally, proper maintenance of the fuel filter and vacuum lines is crucial to ensuring optimal fuel pressure and preventing potential issues.

Fuel pressure regulator vac line

The fuel pressure regulator vac line is a topic of discussion among Toyota Supra MK3 owners and enthusiasts. The vac line, or vacuum pipe, is connected to the fuel pressure regulator, which controls the fuel pressure in the engine. A properly functioning vac line is essential for maintaining the correct fuel pressure and ensuring the engine runs smoothly.

Some owners have reported issues with the vac line, such as no vacuum being present on the line, which can affect the performance of the fuel pressure regulator. In some cases, this may be due to the vacuum routing taking a convoluted path via the EGR (Exhaust Gas Recirculation), resulting in a lack of vacuum along the line.

To troubleshoot and resolve vac line issues, some owners have suggested bypassing the VSV (Vacuum Switching Valve) and connecting the vacuum pipe directly from the manifold to the regulator. While this can help resolve the issue, it is important to note that it may also cause problems with hot starting due to heat soak in the fuel rail.

It is recommended to perform thorough diagnostics and refer to the factory service manual or a trusted mechanic before making any modifications to the fuel system, as incorrect fuel pressure can lead to serious engine damage.

When installing a fuel pressure regulator, it is important to follow the correct procedure. This typically involves loosening the lock nut, applying gasoline to a new O-ring, installing the O-ring and regulator, adjusting the regulator orientation, and then tightening the lock nut. It is also crucial to connect the fuel pipes, vacuum sensing hose, and PCV hose correctly.

Additionally, it is important to ensure that the fuel pressure is set correctly for your specific setup. The base fuel pressure should be adjusted based on factors such as the fuel pump, injectors, and desired performance. Some aftermarket fuel pressure regulators, such as the Aeromotive AFPR, have adjustable base fuel pressure settings, allowing you to fine-tune the fuel delivery to match your engine's requirements.

Aeromotive AFPR

The Aeromotive AFPR is a fuel pressure regulator designed to be installed in a 1987-1992 Toyota Supra Turbo MK3. The AFPR is part of an exclusive install solution that includes a stainless-steel braided fuel hose kit, two hoses, and four hard-to-source fittings. The installation kit allows you to integrate the Aeromotive AFPR into your factory fuel rail and factory setup, resulting in a tuneable system with custom-fabricated components.

The Aeromotive AFPR can help you achieve the desired fuel pressure in your MK3 Supra. It is adjustable, allowing you to set the fuel pressure to meet the requirements of your specific setup. The fuel pressure can be fine-tuned to ensure optimal performance and avoid issues such as running too rich or putting excessive strain on the injectors.

One user reported setting their Aeromotive AFPR to 30 psi while the engine is running, noting that there is a difference between static and running pressure. They also mentioned that the fuel pressure will be higher if the fuel pump is running with the engine stopped. It is important to note that increasing fuel pressure alone may not compensate for a lack of flow, and it is crucial to consider the condition and capacity of other components, such as the injectors and ECU.

Additionally, the Aeromotive AFPR can be paired with other performance upgrades. For example, SupraStore.com offers a fuel kit that includes the Aeromotive AFPR, stainless steel fuel lines and fittings, a fuel pressure gauge, 550cc injectors, injector clips, and a high-flow Walbro fuel pump. This kit is designed to increase fuel pressure and support higher boost levels in the MK3 Supra.

When installing the Aeromotive AFPR, it is important to follow the instructions carefully. The installation process involves removing the stock AFPR, installing the new fittings and hoses, mounting the AFPR, and adjusting the base fuel pressure level. It is recommended to refer to the Aeromotive AFPR instructions and seek guidance from reputable sources or professionals when making adjustments to your vehicle's fuel system.

Fuel injectors

The fuel injectors are a key component in the performance of your Toyota Supra MK3. They play a critical role in delivering the right amount of fuel to the engine, ensuring optimal combustion and engine performance. Here are some essential details about fuel injectors for your MK3:

Fuel Injector Function

Fuel Injector Types

There are two types of fuel injectors commonly used in the Toyota Supra MK3:

• Stock Fuel Injectors: These are the original injectors that came with your MK3. They are designed to provide the appropriate fuel flow for the stock engine configuration. Over time, stock injectors may become clogged or worn out, leading to poor engine performance and fuel efficiency.
• Aftermarket Fuel Injectors: These are injectors designed to replace the stock injectors and offer improved performance. They can provide a higher flow rate, allowing for increased horsepower and torque. Aftermarket injectors are often chosen when engine modifications have been made, such as installing a turbocharger or supercharger, which require a higher fuel flow.

Fuel Injector Maintenance and Upgrades

Maintaining your fuel injectors is crucial to ensure reliable engine performance. Here are some key points:

• Clogged Injectors: As mentioned, clogged injectors can lead to poor performance and may require replacement. Regular use of high-quality fuel and fuel additives can help prevent clogging.
• Upgrading Injectors: If you are planning to increase the performance of your MK3 with engine modifications, upgrading your fuel injectors is essential. The stock injectors may not be able to keep up with the increased fuel demands, leading to a lean condition and potential engine damage.
• Fuel Pressure: Fuel pressure plays a critical role in injector performance. The fuel pressure regulator (FPR) ensures that the injectors receive the correct fuel pressure. Adjusting the FPR can impact injector performance, and it's important to follow manufacturer guidelines to avoid complications.

Fuel Injector Sizing

When choosing aftermarket fuel injectors, it's important to select the appropriate size. Injectors are sized based on their flow rate, typically measured in cc/min (cubic centimeters per minute) or lb/hr (pounds per hour). The injectors must be matched to your engine's fuel requirements, which are determined by factors such as horsepower, boost pressure, and engine configuration.

In summary, fuel injectors are a critical component in your Toyota Supra MK3's fuel system. Proper maintenance, sizing, and fuel pressure are key to ensuring optimal engine performance and longevity. Upgrading injectors can be a necessary step when modifying your engine to achieve higher performance levels.

Fuel pump relay

The fuel pump relay in a Mk3 Supra is located on top of the passenger side fender by the strut mount. The only fuse it runs through is the 15A EFI fuse.

The fuel pump relay can be bypassed by using a relay or toggle switch to provide a direct 12V line from the battery to the pump, and grounding it in the trunk. However, this may not be sufficient to start the car, as the fuel pump relay under the hood controls the signal wire from the ECU that tells the pump to run, turn on, and turn off.

If you are having issues with the fuel pump relay, you can try the following:

• Check all wire connections to ensure there are no bad/weak connections.
• Bypass the relay on the passenger side of the engine bay/shock tower.
• Check for any hidden kill switches that may have been installed by a previous owner.

You can also refer to the TSRM for more information on testing and troubleshooting the fuel pump relay.

Fuel pressure gauge

A fuel pressure gauge is a vital tool for monitoring the fuel pressure in your car's engine, ensuring optimal engine operation and performance. Proper fuel pressure levels are critical as fluctuations can affect engine performance, decrease fuel economy, and potentially cause damage to the fuel system.

Symptoms of Low/High Fuel Pressure:

Low fuel pressure can result in rough idling, poor performance, and decreased fuel economy. On the other hand, high fuel pressure can lead to a rich air-fuel mixture, causing black exhaust, high emissions, and possible damage to your fuel system.

Choosing the Right Fuel Pressure Gauge:

When choosing a fuel pressure gauge, it is important to consider the fuel pressure range suitable for your vehicle. For example, a 30 PSI gauge is ideal for diesel trucks with lower fuel pressure levels, while a 100 PSI gauge is recommended for vehicles with fuel-injected gas engines or racing applications. Additionally, you can choose between analog or digital gauges, with some offering a wide range of display colours.

Installation:

Installing a fuel pressure gauge typically involves connecting the included fuel pressure sensor to your fuel filter housing, fuel pump, or fuel rail. The sensor harness and power harness are then connected to the gauge, which is mounted in a visible location. Some gauges come with a mounting bracket and hardware for installation without a gauge pod.

Maintenance and Troubleshooting:

To maintain and troubleshoot your fuel pressure gauge, refer to the manufacturer's instructions and guidelines. Regularly check for fuel leaks and ensure that all connections are secure. It is also important to monitor fuel pressure levels and adjust them as needed to prevent damage to the fuel pump and injectors.

Brands and Availability:
