The Boeing 747 is one of the most recognizable airplanes in the world, with its high passenger capacity and long range. The fuel tank of the Boeing 747 is so large that it takes up the entire wingspan of the plane. The majority of the fuel is stored in the wings, with two main fuel tanks in each wing, reserve fuel tanks in the outer wing sections, and a central wing tank in the middle. The exact capacity varies between models, with some even containing additional fuel tanks in the tail. The debut version, the 747-100, could carry 48,400 gallons of fuel, while the 747-400 has eight fuel tanks with a combined capacity of 57,164 gallons of Jet-A fuel.
| Characteristics | Values |
|---|---|
| Number of fuel tanks | 8 |
| Combined capacity | 57,164 gallons of Jet-A fuel |
| Weight of combined capacity | Over 380,000 pounds |
| Fuel management | Largely automated but requires certain crew actions |
| Fuel distribution | Profoundly impacts aircraft performance; fuel must be burned off in some tanks before using fuel in others to prevent unbalancing |
| Fuel tank size | Large enough to span the entire wing |
Explore related products
What You'll Learn
- The Boeing 747 fuel tank takes up the entire wingspan of the plane
- The 747-400 has eight fuel tanks with a capacity of 57,164 gallons
- The 747's four engines burn around 1 gallon of fuel per second
- The 747-8 Intercontinental has issues with its tail fuel tanks
- The 747-100, 200, 300, and 400 have different fuel capacities
The Boeing 747 fuel tank takes up the entire wingspan of the plane
The Boeing 747 is a remarkable aircraft with a fuel tank that spans the entire width of its wings. This impressive feature is a defining characteristic of the 747, and its impact on the plane's performance and fuel management is significant.
With eight fuel tanks in total, the 747-400 can hold up to 57,164 gallons of Jet-A fuel, weighing over 380,000 pounds. This vast fuel capacity enables the aircraft to undertake long-haul journeys, such as flying from Long Beach to Hawaii. However, the distribution of fuel across these tanks is carefully managed to maintain the aircraft's balance during flight.
The fuel tanks' location within the wings serves a strategic purpose. Wings present a large surface area when an enemy aircraft is spotted, making them vulnerable to gunfire. By placing the fuel tanks within the wings, the risk of explosion from gunfire is significantly increased. This design consideration is a crucial aspect of the 747's safety features.
While the majority of commercial airliners follow a similar fuel tank design, there are exceptions. For instance, the Piper Archer aircraft has fuel tanks that do not extend the entire length of its wings. Additionally, early 747s had a central fuel tank, but by the 1990s, these were rarely used due to safety concerns.
In conclusion, the Boeing 747's fuel tanks, spanning the entire wingspan, are a critical component of this aircraft's performance and safety. The careful management of fuel distribution and the strategic placement of the tanks showcase the engineering ingenuity behind this iconic plane.
The Lifespan of Fuel in Underground Tanks
You may want to see also
Explore related products
The 747-400 has eight fuel tanks with a capacity of 57,164 gallons
The Boeing 747-400 is a popular aircraft used by airlines such as Atlas Air, Kalitta Air, and Polar Air Cargo. The 747-400 has eight fuel tanks with a capacity of 57,164 gallons of Jet-A fuel. This weight exceeds 380,000 pounds, and pilots typically discuss fuel in terms of weight. The distribution of fuel across the tanks significantly impacts the aircraft's performance. For instance, during long trips, it is crucial to burn off fuel from specific tanks before using fuel from others to prevent the aircraft from becoming unbalanced.
The 747-400's fuel management system is mostly automated, but the crew must still take specific actions. The 747-400's wingspan was extended by 17 feet compared to the Classic 747, and its wings were fitted with 6-foot-tall winglets to reduce aerodynamic drag. Despite the increased length, the wings were significantly lighter due to new aluminium alloys.
The horizontal tail was redesigned to accommodate a 3,300-US-gallon fuel tank, increasing the range by 350 nautical miles. Additionally, the 747-400ER (Extended Range) variant, launched in 2000, offered the option of one or two additional 3,240 US gallon body fuel tanks in the forward cargo hold. However, no orders were placed for airplanes with two body fuel tanks.
The 747-400's value has declined steeply since the 2010s, and many of these aircraft are now over 20 years old, leading to their accelerated retirement. The 747, along with similar aircraft like the Airbus A340 and MD-11, has relatively high operating costs due to its more than two engines. However, their main appeal in the early 1990s was their long range and high capacity.
Repairing Your Motorcycle Fuel Tank: A Step-by-Step Guide
You may want to see also
Explore related products
The 747's four engines burn around 1 gallon of fuel per second
The Boeing 747 is a fuel-guzzling aircraft, burning through approximately 4 litres or 1 gallon of fuel per second while in flight. That's 240,000 horsepower! To put that into perspective, that's the equivalent of over 720,000 horses' power.
The 747-400 model has eight fuel tanks with a combined capacity of 57,164 gallons of Jet-A fuel, weighing over 380,000 pounds. The fuel tanks are so large that they take up the entire wingspan of the plane. This amount of fuel is necessary for the aircraft's long-haul capabilities, but it also presents a safety concern. With so much fuel in the wings, there is a risk of explosion if the wings are hit by gunfire or other projectiles.
The distribution of fuel among the tanks is carefully managed to ensure the aircraft remains balanced during flight. Fuel management is mostly automated, but the crew must also perform specific tasks to ensure safe and efficient fuel usage.
The high fuel consumption of the 747 can impact the flight route and refuelling decisions. For example, if fuel prices are significantly lower at one airport, airlines may opt to refuel there, even if it means consuming more fuel to reach that airport, as the overall cost may still be lower.
The introduction of electric planes is not expected to replace the 747 on its long-haul routes anytime soon. Electric planes would need to carry the weight of depleted batteries for the entire trip, impacting efficiency and maximum takeoff weight.
Fuel Tank Location: Where is it?
You may want to see also
Explore related products
The 747-8 Intercontinental has issues with its tail fuel tanks
The Boeing 747 is a large aircraft with fuel tanks that typically span the entire wingspan. The 747-400, for example, has eight fuel tanks with a combined capacity of 57,164 gallons of Jet-A fuel.
The 747-8 Intercontinental, however, has encountered issues with its tail fuel tanks. In 2012, it was discovered that the weight of the fuel in the tail tanks could potentially cause a "flutter problem" or "wing flutter". This phenomenon occurs when structural vibrations enter a feedback cycle, resulting in enhanced shaking that can cause serious damage to the aircraft.
As a result, the Federal Aviation Administration (FAA) mandated that Boeing not allow fuel in the tail tanks of the 747-8 Intercontinental until engineers could address this issue. This restriction led to a reduction in the aircraft's fuel capacity and range. Boeing worked towards a solution, and subsequent 747-8 aircraft were assembled with the tail tanks blocked inside the factory.
The problem specifically affects the passenger version of the 747-8 Intercontinental, while the freighter version does not use the tail tanks. Airline operators have stated that the impact on performance is minimal, and they remain positive that a modification will be found to restore access to the tail fuel tanks.
Propane Tank Fuel Level: Checking and Maintaining
You may want to see also
Explore related products
The 747-100, 200, 300, and 400 have different fuel capacities
The Boeing 747 is a large aircraft that has been in service since the 1970s, with several variants produced over the years. The 747-100 was the initial model, followed by the 747-200, 747-300, and 747-400 series. Each of these variants has different specifications, including fuel capacity.
The 747-100 was the first model of the 747, with later variants offering improvements in fuel capacity and range. The 747-100 was powered by Pratt & Whitney JT9D-3A engines, which offered sufficient payload and range for medium-haul operations but was marginal for long-haul routes. The 747-100B, a higher maximum takeoff weight (MTOW) variant, was later developed, offering an increased fuel capacity of 48,070 US gallons (182,000 litres). This allowed for a range of 5,000 nautical miles (9,300 km) with a typical 452-passenger payload.
The 747-200 model was introduced in 1971, featuring more powerful engines and a higher MTOW. The 747-200B, the basic passenger version, had increased fuel capacity, with a range of over 5,000 nautical miles (9,300 km) that increased to 6,000 nautical miles (11,000 km) with later engines. The freighter model, the 747-200F, had a capacity of 105 tons (95.3 tonnes) and an MTOW of up to 833,000 pounds (378 tonnes).
The 747-300 series was launched in 1980, with the first aircraft completed in 1983. This variant included a stretched upper deck and increased seating capacity, but specific fuel capacity figures are not readily available. However, it is known that the 747-400, which entered service in 1989, has a higher fuel efficiency than previous 747 versions due to its wingtip extensions and winglets. The 747-400 has eight fuel tanks with a combined capacity of 57,164 gallons of Jet-A fuel.
In summary, the 747-100, 200, 300, and 400 variants of the Boeing 747 have different fuel capacities, with each new variant generally offering improvements in fuel capacity and range over its predecessors. While specific fuel capacity figures are not available for all models, it is clear that Boeing made advancements in this area with each new iteration of the 747.
The Art of Leveling Your Outdoor Fuel Tank
You may want to see also
Frequently asked questions
The Boeing 747 has eight fuel tanks.
The fuel tanks are so big that they take up the entire wingspan of the plane.
The eight fuel tanks have a combined capacity of 57,164 gallons of Jet-A fuel, weighing over 380,000 pounds.
The distribution of fuel among the tanks affects the performance of the aircraft. During long trips, fuel must be burned off from certain tanks before using fuel from others to prevent the aircraft from becoming unbalanced.
Yes, fuel management in the 747-400 is largely automated, but there are still specific actions that the crew must perform.
