Replacing The Fuel Pump In Your '93 Chevy Silverado K1500

If you're looking to replace the fuel pump in your 1993 Chevy Silverado K1500, there are a few methods you can use. One option is to drop the fuel tank and replace the pump from there. This can be a challenging task and usually requires multiple people and a lift. Another approach, suggested by some Silverado owners, is to lift or remove the bed of the truck. This provides access to the fuel pump without fully removing the bed. When doing this, it's recommended to loosen the rear bed-to-frame bolts and remove the other bed-to-frame bolts, as well as disconnecting the fuel tank filler hose. Once you have access to the fuel pump, be sure to disconnect the electrical connections and relieve the pressure in the system before disconnecting the fuel lines. When installing the new fuel pump, ensure that all connections are secure and that the pump is properly grounded. Additionally, consider replacing the fuel strainer and checking for any other issues while the bed is removed.

Removing the truck bed for access

Removing the truck bed from your Chevy Silverado K1500 is a great way to access the fuel pump for replacement. Here is a step-by-step guide to help you through the process:

Step 1: Gather the Necessary Tools and Materials

Before you begin, make sure you have the required tools and materials to complete the job. These include a transmission jack, wrenches, and a new fuel pump. It is also recommended to have a few extra pairs of hands to help with lifting the truck bed.

Step 2: Disconnect the Battery

Safety should always be a top priority when working on any vehicle. Before proceeding, disconnect the battery to eliminate the risk of electrical short circuits or unexpected engine starts.

Step 3: Remove the Tailgate and Rear Bumper

The tailgate and rear bumper can be removed to reduce the overall weight of the truck bed, making it easier to lift. This step is optional but can be helpful, especially if you have limited help.

Step 4: Loosen and Disconnect Relevant Components

Several components need to be loosened or disconnected before removing the truck bed. These include:

• The gas filler neck: Loosen and disconnect the gas filler neck from the bed.
• The ground strap: Disconnect the ground strap near the filler neck.
• Wiring and lights: Disconnect the wiring harness on the driver's side of the bed and unplug the taillights.
• Brake and blinker electrical wires: Disconnect the rear brake and blinker electrical wires.

Step 5: Unbolt and Remove the Truck Bed

With the necessary components disconnected, it's now time to unbolt and remove the truck bed. Using the appropriate-sized wrench or socket, remove the bolts securing the truck bed to the frame. There are typically eight bolts, but this may vary depending on your specific model. Once the bolts are removed, carefully lift the truck bed and set it aside, preferably with the help of a few assistants.

Step 6: Access and Replace the Fuel Pump

With the truck bed removed, you now have clear access to the fuel pump. Lower the fuel tank using a jack, if necessary, to gain better access. Remove the old fuel pump and install the new one, ensuring all connections are secure. Reinstall the fuel tank if it was lowered.

Step 7: Reinstall the Truck Bed

Finally, carefully lift the truck bed back into place and secure it with the bolts previously removed. Reconnect all disconnected components, including the gas filler neck, ground strap, wiring, and taillights. Reinstall the tailgate and rear bumper if they were removed.

By following these steps, you should now have successfully accessed and replaced the fuel pump in your 1993 Chevy Silverado K1500 by removing and reinstalling the truck bed.

Disconnecting the fuel filler neck

Step 1: Start by unbolting the fuel filler neck from the bed of the truck. This will involve removing the bolts that secure the neck to the bed. It is also important to disconnect any wires or hoses attached to the filler neck.

Step 2: With the filler neck free, push it through the hole in the bedside and set it aside. You may need to remove the tail lights and carefully pull out the wires to gain better access. Ensure that you have a clear workspace and that all necessary tools are within reach.

Step 3: At this point, you should be able to access the fuel pump more easily. Before proceeding, it is recommended to wash the top of the fuel tank to remove any dirt, gravel, or dust that may have accumulated. This will help ensure that no debris falls into the tank during the pump replacement.

Step 4: Now, carefully disconnect the fuel lines and electrical connections attached to the fuel pump. This will involve identifying the correct wires and hoses and detaching them one by one. It is important to be gentle during this process to avoid any damage.

Step 5: Once all the connections to the fuel pump have been disconnected, you can proceed with removing the fuel pump itself. This will likely involve removing additional bolts or fasteners that secure the pump to the fuel tank. Remember to have a fuel container nearby to catch any remaining fuel that may spill during the process.

Step 6: With the fuel pump removed, you can now install the new fuel pump. Ensure that all connections are securely attached and that there are no leaks before reassembling the components. Follow the previous steps in reverse order, making sure that all fasteners and connections are tightened securely.

Step 7: Reattach the fuel filler neck to the bedside by bolting it securely and reconnecting any wires or hoses. Ensure that all components are properly aligned and secured before lowering the truck bed back into place.

Step 8: Finally, perform a thorough inspection of your work. Check all connections, hoses, and wires to ensure that everything is properly connected and secured. Start the engine and check for any leaks or unusual noises. If everything appears to be in order, you have successfully replaced the fuel pump and disconnected/reconnected the fuel filler neck.

Remember to take your time, work in a well-ventilated area, and wear appropriate safety gear when performing this task.

Draining the fuel tank

To drain the fuel tank of a 1993 Chevy Silverado K1500, first, raise the rear of the truck using a floor jack and support it with jack stands. Place the jack stands under the frame so they don't interfere with the removal process.

If the tank is over half full, drain the fuel into a container. To do this, jump the fuel pump relay by placing a jumper wire between the battery positive terminal of the relay and the fuel pump terminal. The pump will run continuously until the jumper is removed. Next, remove the cap on the fuel rail Schrader valve, which looks like a tire air valve. Place a rag over the valve to capture any expelled fuel, then place a rubber hose over the valve and run it over the fender and into a fuel container.

Remove the cover on the fuse/relay box on the driver's side fenderwell and locate the fuel pump relay from the diagram on the fuse block cover. Remove the relay and check the terminals with a voltmeter. Probe the terminals in the fuse block vacated by the four-pronged relay to find the one with battery voltage. Note this terminal, then turn the voltmeter to ohms and probe the remaining terminals for a good ground. The ground will be the terminal leading to the fuel pump. Jump the battery terminal and this ground terminal with a jumper wire. The fuel pump will turn on and pump the fuel out of the Schrader valve and into the container.

Remove 8 gallons of fuel to be on the safe side. To stop the fuel flow, simply unplug the jumper wire. When finished, remove the jumper wire and plug the relay back in. Remove the fuel hose from the Schrader valve, replace the valve, and put the cap back on.

Removing the fuel pump electrical connector

To remove the fuel pump electrical connector from a 1993 Chevy Silverado K1500, first, raise the rear of the truck using a floor jack and support it with jack stands for safety. Place the jack stands under the frame so they don't interfere with the removal process.

Next, drain the fuel tank into a container if it is over half full. To do this, jump the fuel pump relay by placing a jumper wire between the battery positive terminal of the relay and the fuel pump terminal. This will cause the pump to run continuously until the jumper is removed. Remove the cap on the fuel rail Schrader valve, which looks like a tire air valve. Use a valve stem retractor to remove the Schrader valve and place a rag over it to capture any expelled fuel.

Place a rubber hose over the Schrader valve and run it over the fender and into a fuel container. Remove the cover on the fuse/relay box on the driver's side fenderwell and locate the fuel pump relay from the diagram on the fuse block cover. Remove the relay.

Check the terminals with a voltmeter by connecting the black lead to a solid ground and probing the terminals in the fuse block with the red lead. Probe each of the four female terminals to find the one with battery voltage. Note this terminal. Switch the voltmeter dial to ohms and probe the remaining terminals for a good ground. The ground terminal will be the one leading to the fuel pump. Jump the battery terminal and this ground terminal with a jumper wire. The fuel pump will turn on and pump the fuel out of the Schrader valve and into the container.

Remove 8 gallons of fuel to be safe. To stop the fuel flow, simply unplug the jumper wire. When finished, remove the jumper wire and plug the relay back in. Remove the fuel hose from the Schrader valve, replace the valve, and put the cap back on.

Now, you can unplug the fuel pump electrical connector at the backside of the fuel tank.

Lowering the fuel tank

To lower the fuel tank of your 1993 Chevy Silverado K1500, follow these steps:

First, ensure the rear of the truck is raised with a floor jack and supported by jack stands. Place the jack stands under the frame to avoid interfering with the removal process. Next, if the fuel tank is over half full, drain the fuel into a container. To do this, jump the fuel pump relay by connecting a jumper wire from the battery positive terminal of the relay to the fuel pump terminal. This will run the pump continuously until the jumper is removed.

Now, you can remove the cap on the fuel rail Schrader valve, which looks like a tire air valve. Use a valve stem retractor to remove the Schrader valve and place a rag over it to capture any expelled fuel. Place a rubber hose over the Schrader and run it over the fender and into a fuel container.

Remove the cover on the fuse/relay box on the driver's side fenderwell and locate the fuel pump relay from the diagram on the fuse block cover. Remove the relay and check the terminals with a voltmeter. Connect the black lead of the voltmeter to a solid ground and use the red lead to probe the terminals in the fuse block. Identify the terminal with battery voltage and note it down. Switch the voltmeter to ohms and probe the remaining terminals for a good ground. The ground terminal will be the one leading to the fuel pump.

Jump the battery terminal and the ground terminal with a jumper wire to turn on the fuel pump, which will pump the fuel out of the Schrader and into the container. Remove around 8 gallons of fuel to be safe, and then stop the fuel flow by unplugging the jumper wire. Once done, remove the jumper wire and plug the relay back in.

Now, you can remove the fuel hose from the Schrader and replace the valve and cap. Unplug the fuel pump electrical connector at the backside of the fuel tank and loosen the hose clamps on the top and bottom of the fuel filler hose with a screwdriver. Remove the hose and then loosen and pull off the fuel vent hose clamp at the fuel tank. The fuel vent hose runs parallel to the filler hose.

Place the floor jack under the fuel tank, between the two fuel tank straps. Remove the two tank-retaining strap bolts using a 15-mm socket. Now, carefully lower the fuel tank enough to access the top of the tank and remove all the hoses from the top of the fuel pump cap. These are quick-disconnect fittings, so pinch the connectors and pull them off. There should be three connectors.

At this point, you can lower the fuel tank to the ground and pull it out from under the truck to access the fuel pump for removal.
