The Mercedes-Benz W126 is a series of S-Class automobiles manufactured between 1979 and 1992. Fuel injectors deliver fuel into the air stream as it enters the combustion chamber. If your car is running poorly, the injector should be checked. Removing and replacing fuel injectors on a W126 involves several steps, including disconnecting the battery, relieving fuel rail pressure, removing electrical connections, and carefully lifting the fuel rails. It is important to ensure that the injector holders are free of grime and that the engine is clean before beginning the process.
How to Remove Fuel Injectors W126
| Characteristics | Values |
|---|---|
| Tools Required | 3/8 drive ratchet, extension, 10mm socket, 5mm allen socket, 12mm combination wrench, two 14mm combinations, 17mm combination wrench, sil-lube |
| Step 1 | Disconnect the battery to eliminate potential spark hazards during repairs |
| Step 2 | Relieve the fuel rail pressure via the Schrader valve |
| Step 3 | Remove each injector electrical connection |
| Step 4 | Remove the air cleaner box and tubes |
| Step 5 | Remove the 2 large 17mm fuel lines from the side of the fuel distributor |
| Step 6 | Pull off the air distribution tube from the hose that goes to the other side under the distributor and all 4 injector holders |
| Step 7 | Disconnect the fuel line from the fuel injector |
| Step 8 | Use the 5mm allen socket to remove the hold-down bolt on the injector clip |
| Step 9 | Tighten each injector clip down till you have all 4 back in, then start putting the injection lines back on the fuel injectors |
| Step 10 | Reconnect all the lines and vacuum tubes back on in reverse order |
| Step 11 | Reconnect any electrical connections then turn the key on for 30 seconds before starting |
