A faulty injector driver module can cause a car to run erratically and display a check engine code. The injector driver is a solid-state relay that uses 5v to close a 12v circuit to the ground. A faulty injector driver can be caused by a variety of issues, such as a faulty coil in injector #1, a faulty ECU, or a wiring issue. To fix a bad injector driver, one can attempt to replace the injector, check the wiring and resistance, or send the ECU for repair or replacement.
Characteristics and Values of Fixing a Bad Driver for Fuel Injector in ECU
| Characteristics | Values |
|---|---|
| ECU Code | YDH1 |
| Check Engine Code | P0206 |
| Cylinder | 6 Open Injector Circuit |
| Resistance | Greater than 10,000 ohms |
| Voltage | 9v to fire the injector |
| Coil | May be faulty, causing the injector to draw too many amps and overheat the driver |
| Wiring | May be brittle or faulty |
| Injector Driver Module | May not be working properly |
| Injector Control | Ideally, each injector should be driven individually |
| Engine ECU | Turns on all injectors at the same time |
