Wingtip Bearing Changes: Fuel Usage Calculation Strategies

Wingtips, the part of an aircraft's wing that is furthest from the fuselage, have been modified over the years to improve fuel efficiency. Wingtip bearing change is a crucial factor in calculating fuel usage, and involves taking into account the elapsed time between bearing changes and the rate of fuel consumption. For example, with a wingtip bearing change of 15, an elapsed time of 6 minutes, and a fuel consumption rate of 8.6 gal/hr, the approximate fuel required to fly to a station can be calculated. This calculation is essential for pilots to ensure they have sufficient fuel for their flights and can adjust their fuel load accordingly.

Wingtip bearing change and fuel efficiency

Wingtips refer to the tip of an aircraft's wing, the part that is furthest from the fuselage. Wingtip designs have evolved since their incorporation into commercial liners in the mid-1980s, as aviation companies seek to minimize fuel usage.

The shaped end of a wingtip is often called a "winglet", and its function is to minimize vortex drag, or lift-induced drag. Drag occurs when high-pressure air from beneath the wing escapes into the low-pressure air above the wing, reducing lift and causing the plane to use more fuel to stay airborne. Wingtips act as a barrier to minimize the exchange of high-pressure and low-pressure air, thereby reducing the drag that occurs at the wingtips and improving the lift-to-drag ratio. This enables aircraft to maintain performance while consuming less fuel.

The benefits of wingtips have been demonstrated by several studies. NASA has claimed that wingtips save aviation companies billions of dollars annually by improving fuel efficiency. A Boeing study of blended winglets showed an improvement of almost 5% in fuel consumption, while Tamarack's "Active Winglets" are expected to provide 15-33% in savings.

Despite the added cost and weight of wingtips, the gains in fuel efficiency usually outweigh the drawbacks. Winglets can cost around $1 million per plane to install and add significant weight, but the fuel savings tend to counterbalance the added costs.

Calculating fuel consumption rate

To calculate the fuel consumption rate of a vehicle, you can use the formula:

Fuel consumption = Fuel used ÷ Distance travelled

This formula tells you how much fuel a vehicle burns at a certain distance. The result can be given in litres per kilometre (L/km) or litres per 100 kilometres (L/100km).

For example, if a vehicle consumes 100 litres of fuel to travel a total distance of 1320 km, you can calculate its fuel consumption rate as follows:

Fuel consumption = Fuel used ÷ Distance travelled

Fuel consumption = 100 L ÷ 1320 km

Fuel consumption = 0.07576 L/km

To convert this to the more typical unit of L/100km, you can multiply the above value by 100:

07576 L/km x 100 = 7.576 L/100 km

Alternatively, if you know the fuel efficiency of your vehicle, you can simply take its reciprocal to find your vehicle's fuel consumption rate:

Fuel consumption = 1 ÷ Fuel efficiency

For instance, if your vehicle's fuel efficiency is 25 miles per gallon (mpg), its fuel consumption rate would be:

Fuel consumption = 1 ÷ 25 mpg

Fuel consumption = 0.04 mpg

It's important to note that fuel consumption rates can vary based on driving conditions and habits. For example, driving at a constant pace on a highway will generally result in lower fuel consumption compared to frequent stops and starts in a city. Additionally, factors such as speed, use of air conditioning, cargo load, and tyre inflation can also impact fuel consumption.

Wingtip design evolution

Wingtip design has evolved significantly over the years, with the goal of improving aircraft efficiency and performance. Here is a detailed overview of the evolution of wingtip design:

Early History

The concept of wingtips was first introduced in the late 19th and early 20th centuries. In 1897, English engineer Frederick W. Lanchester patented wing end-plates to control wingtip vortices. Later, in 1910, Scottish-born engineer William E. Somerville patented and installed the first functional winglets on his biplane and monoplane designs.

Mid-20th Century Developments

During and after World War II, several pioneers contributed to the development of wingtip devices. Dr. Sighard F. Hoerner, a German aerodynamicist, introduced the concept of "Hoerner tips" or "Hoerner wingtips", which are drooped wingtips that redirect wingtip vortices away from the upper wing surface. These tips were used on gliders and light aircraft for many years.

The "Lippisch-Ohren" or "Lippisch-ears" wingtips, attributed to Alexander Lippisch, were added to the Heinkel He 162A jet fighter during World War II to counteract dutch roll characteristics.

In the 1970s, Richard T. Whitcomb, an engineer at NASA's Langley Research Center, further advanced the concept of winglets by theorizing that near-vertical winglets could significantly reduce vortex drag. This led to the first flight tests of winglets on a Boeing KC-135 Stratotanker in the late 1970s, demonstrating a 7% increase in cruise range.

The Middle-Eastern oil crisis of 1973 also played a pivotal role in the adoption of wingtips, as airlines sought fuel-saving measures due to skyrocketing fuel prices.

Evolution of Winglet Designs

Over the years, various types of winglet designs have emerged, each aiming to improve efficiency and performance:

• Winglet: Found on aircraft like the B737NG, A330, B747-400, and A350. Winglets are vertical extensions at the wingtips that reduce vortex-related drag.
• Wingtip Fence: Featured on the A320, A380, and B737MAX. Wingtip fences are surfaces extending above and below the wingtip, reducing vortex interference and improving aircraft handling.
• Blended Winglet: Boeing 737, 757, and Airbus A320neo are examples of aircraft with blended winglets. These winglets have a smooth curve instead of a sharp angle, reducing interference drag at the wing/winglet junction.
• Raked Wingtip: Boeing 777, 767-400ER, and 787 are equipped with raked wingtips, which are swept back and increase the effective aspect ratio while reducing wingtip vortices.
• Split Winglet: A variant of the Whitcomb winglet found on Boeing 737 aircraft, where the lower winglet is placed near the trailing edge.
• Hoerner Wingtip: Named after Sighard Hoerner, these wingtips are designed to neutralize the impact on the corrected aspect ratio. They are found on aircraft like the Grumman American AA-5 series.
• Küchemann Wingtip: Attributed to German aerodynamicist Dietrich Küchemann, these wingtips are designed for transonic speeds and smooth pressure distribution over the wing. They are featured on aircraft like the Vickers VC10 and Airbus A320.
• Rakelet: A combination of raked wingtip and winglet, considered a new wingtip device.
• Endplate Wingtip: Vertical plates positioned at the wingtip, increasing lift and reducing drag. Found on early aircraft and the Airbus A320 family.

Continuous Innovation

The evolution of wingtip design continues, driven by advancements in aerodynamics, materials, and manufacturing techniques. Aircraft manufacturers like Boeing and Airbus constantly innovate and test new wingtip designs to improve fuel efficiency, range, and performance. The latest designs, such as folding wingtips on the Boeing 777X and active winglets that can adjust during flight, showcase the ongoing pursuit of optimizing wingtip technology.

Vortex drag and fuel usage

Vortex drag, also known as lift-induced drag, is a force that acts parallel to the airflow and along the direction of it. It occurs when high-pressure air from beneath the wing of an aircraft spills over into the low-pressure air above the wing. This reduces the lift generated by the aircraft, causing it to consume more fuel to stay airborne.

The wingtips of an aircraft are designed to minimize vortex drag. The shaped end of a wingtip is called a winglet, and its function is to act as a barrier that reduces the exchange of high-pressure and low-pressure air. During flight, aircraft maintain low pressure above the wing and high pressure beneath it. Without wingtips, these high and low-pressure air systems would converge at the wingtip, creating vortices that displace a lot of energy and slow the plane down. Wingtips minimize the confluence of these air systems, reducing the rate of convergence between pressurized air and maximizing the lift-to-drag ratio. This enables aircraft to operate at the same capacity while consuming much less fuel.

The incorporation of wingtips into aircraft design has been shown to significantly improve fuel efficiency. NASA estimates that wingtips save aviation companies billions of dollars annually by reducing fuel consumption. A Boeing study found that blended winglets improved fuel consumption by close to 5%, while Tamarack's 'Active Winglets' are claimed to provide savings of 15-33%.

Calculating the exact fuel savings from wingtip modifications can be complex and depends on various factors, including the aircraft's weight, speed, route, and other operational metrics. However, the benefits of reduced vortex drag through wingtip modifications are clear, and they have become an indispensable part of aircraft design, increasing range and enabling more efficient travel.

Benefits of wingtip modifications

Wingtip modifications have been an indispensable part of aircraft design for decades, offering a range of benefits that improve performance and efficiency. Here are some key advantages of wingtip modifications:

Fuel Savings and Efficiency:

Wingtip modifications, such as winglets, are designed to reduce drag by minimizing the exchange of high-pressure and low-pressure air at the wingtips. This reduction in drag leads to significant fuel savings, with studies showing improvements of up to 5% in fuel consumption. Over time, these savings can accumulate, particularly on long-haul routes, resulting in substantial cost reductions for airlines.

Increased Range:

By reducing drag, wingtip modifications enable aircraft to fly longer distances more efficiently. Airlines operating long-haul routes can take advantage of the extended range that wingtip modifications offer without the need for additional fuel. This increased range opens up new possibilities for airlines, allowing them to explore new routes and destinations that were previously out of reach.

Environmental Impact:

With reduced fuel consumption, airlines can significantly lower their carbon footprint. As the aviation industry moves towards more sustainable practices, wingtip modifications play a crucial role in reducing overall emissions. By minimizing fuel burn, wingtip devices contribute to greener operations, making air travel more environmentally friendly.

Improved Takeoff and Climb Performance:

Wingtip modifications enhance takeoff and climb performance by reducing drag. This improved performance is especially beneficial for flights operating from shorter runways or airports at higher altitudes. Aircraft can achieve faster climb rates, access higher altitudes, and utilize shorter runways, all while reducing community noise during takeoff.

Increased Payload-Range Capability:

Wingtip modifications, such as winglets, can also increase the payload-range capability of aircraft. This means that planes can carry more weight over the same distance or fly the same payload over greater distances. This flexibility is valuable for both commercial and military aircraft, allowing them to carry additional cargo or serve more customers without increasing fuel consumption.
