The Delta IV Heavy rocket was a pivotal player in space flight evolution, with a remarkable success rate over six decades of flights. It was the most powerful member of the Delta IV line, which was initially developed by Boeing and later transferred to United Launch Alliance. The Delta IV Heavy rocket burned ultracold liquid hydrogen, a high-performance fuel, and had a total mass at launch of approximately 733,000 kg (1,616,000 lb).
| Characteristics | Values |
|---|---|
| Fuel | Liquid hydrogen and liquid oxygen |
| Engine | RS-68 liquid hydrogen engine |
| Manufacturer | Aerojet Rocketdyne |
| Configuration | Delta IV Medium+, with two or four solid rocket motors (SRMs) and the Delta IV Heavy |
| Common Booster Core (CBC) | Two additional CBCs as liquid rocket boosters |
| Weight | 74,500 lbs |
| Nominal Burn Time | 90 seconds |
| Total Mass at Launch | 733,000 kg |
Explore related products
What You'll Learn
Delta IV Heavy burns ultracold liquid hydrogen
The Delta IV Heavy was the most powerful member of the Delta IV line of rockets, which were initially developed by Boeing and later transferred to United Launch Alliance. The Delta IV Heavy was first launched in 2004 and was the world's highest-capacity launch vehicle in operation after the retirement of the Space Shuttle in 2011 until the Falcon Heavy debuted in 2018. It was the last operating member of the Delta IV family, with its final flight taking place on April 9, 2024.
The Delta IV Heavy was an all liquid-fueled launch vehicle, consisting of an upper stage, one main booster, and two strap-on boosters. The first stage of the Delta IV Heavy consisted of a central Common Booster Core (CBC) with two additional CBCs as liquid rocket boosters. At lift-off, all three rocket engines operated at full thrust. The central engine then throttled down to 55% to conserve fuel until the other two engines separated. The Delta IV Heavy used three RS-68 engines, one in the central core and one in each booster. The RS-68 engine is the largest existing hydrogen-burning engine, burning liquid hydrogen and liquid oxygen.
In the final seconds of the countdown, the liquid hydrogen fuel would flow through the engines and upwards along the booster body. After ignition, the hydrogen would inflame, creating a characteristic fireball and charred look on the booster. The total mass of the Delta IV Heavy at launch was approximately 733,000 kg, and it produced around 952,000 kg of thrust to power the rocket skyward at liftoff.
The Delta IV Heavy was used to launch a variety of payloads, including the Parker Solar Probe in 2018 and the Orion spacecraft in 2014. Its first operational payload was the DSP-23 satellite, which was successfully launched in 2007. The ignition of the Delta IV Heavy rocket is visually striking, with the rocket appearing to burn itself up on the launchpad before heading to space.
Hydrogen Fuel: A Green Energy Revolution?
You may want to see also
Explore related products
Liquid hydrogen is used to cool down engines
The Delta IV Heavy was the most powerful member of the Delta IV line of rockets, which was developed by Boeing and later transferred to United Launch Alliance. It was an all-liquid-fueled launch vehicle, with a central Common Booster Core (CBC) and two additional CBCs as liquid rocket boosters. The Delta IV Heavy used liquid hydrogen as fuel and burned through more than 700,000 gallons of it during launch.
The cooling of rocket engines with liquid hydrogen is an important step before launch, known as "prechill." During this process, engineers deliver liquid hydrogen to the engines while the liquid hydrogen core stage tank is being filled. This allows them to evaluate data and ensure that critical engine components are chilled to the required temperatures for operation. Maintaining a consistent temperature is crucial as any warming of liquid hydrogen can cause it to turn into gas, creating thermal conditioning issues for the engine.
Liquid hydrogen is also used for cooling in hydrogen-powered cars to enable quick refuelling. Hydrogen cooling systems help prevent the hydrogen in the storage tank from heating up above the maximum permissible temperature. By cooling the hydrogen to temperatures between -33°C and -40°C, the tank temperature can be maintained below 85°C, allowing for a faster refuelling process.
In addition to engine cooling, liquid hydrogen has other applications, such as cooling neutrons for neutron scattering experiments. The use of liquid hydrogen in these experiments takes advantage of the similar masses of neutrons and hydrogen nuclei, maximizing the kinetic energy exchange during interactions.
Semi Trucks' Fuel Efficiency: Miles Per Gallon
You may want to see also
Explore related products
$851.64
Liquid hydrogen is lighter than air and rises upward
The Delta IV Heavy was an expendable heavy-lift launch vehicle, the largest type in the Delta IV family. It was manufactured by United Launch Alliance (ULA) and was first launched in 2004. The Delta IV Heavy was an all liquid-fueled launch vehicle, consisting of an upper stage, one main booster, and two strap-on boosters. The Delta IV Heavy's total mass at launch was approximately 733,000 kg (1,616,000 lb), and it produced around 952,000 kg (2,099,000 lb) of thrust to power the rocket skyward at liftoff.
The Delta IV Heavy first stage consisted of a central Common Booster Core (CBC) with two additional CBCs as liquid rocket boosters. The launch vehicle used three RS-68 engines, one in the central core and one in each booster. The RS-68 engine is the largest existing hydrogen-burning engine. It burns liquid hydrogen and liquid oxygen at 1410 lbf/in² (9.7 MPa).
Liquid hydrogen is used as rocket fuel because it is lighter than air and rises upward. Hydrogen is 14 times lighter than air and 57 times lighter than gasoline vapor. This means that when released, hydrogen will typically rise and disperse rapidly, greatly reducing the risk of ignition at ground level. Hydrogen has a lower radiant heat than conventional gasoline, meaning the air around a hydrogen flame is not as hot as around a gasoline flame, reducing the risk of secondary fires.
Additionally, hydrogen is not toxic, unlike conventional fuels, and it produces only water when used in fuel cells, whereas vehicle combustion of conventional fuels generates harmful air pollution. Hydrogen is safer to handle than conventional fuels, and in the event of a leak or spill, it will not contaminate the environment or threaten the health of humans or wildlife.
Superyacht Fuel Consumption: How Much Is Too Much?
You may want to see also
Explore related products
Liquid hydrogen creates a dramatic fireball
The Delta IV Heavy was an all-liquid-fuelled launch vehicle, consisting of an upper stage, a main booster, and two strap-on boosters. The rocket was developed by Boeing and later transferred to United Launch Alliance for manufacturing. The Delta IV Heavy first stage consisted of a central Common Booster Core (CBC) with two additional CBCs as liquid rocket boosters. The rocket engines used liquid hydrogen as fuel and liquid oxygen as an oxidizer.
Liquid hydrogen is a highly flammable substance that, when ignited, creates a dramatic fireball. This fireball is characterized by its large size and intense heat. The combustion of liquid hydrogen releases a significant amount of energy, resulting in a rapid expansion of gases and a subsequent explosion. The fireball produced by the ignition of liquid hydrogen can cause extensive damage to people, equipment, and the surrounding environment.
The size of the fireball is influenced by several factors, including the amount of hydrogen, the fireball's diameter-to-height ratio, and the combustion pressure and temperature. Experimental data and simulations have shown that a liquid hydrogen fireball can reach diameters of up to 7-8 meters. The fireball's shape may deviate from a perfect sphere due to factors such as tank rupture and non-instantaneous opening of tank walls.
Safety considerations are crucial when dealing with liquid hydrogen due to the potential for catastrophic consequences in the event of a release or ignition. The fireball's thermal effects, including high temperatures and radiative heat flux, can result in severe burns and even fatality. Therefore, it is essential to establish hazard distances and perform quantitative risk assessments to estimate the potential harm to people and structures in the vicinity.
The dramatic fireball created by liquid hydrogen ignition is a visually striking and powerful demonstration of the energy released by the combustion of this fuel. While it contributes to the characteristic spectacle of rocket launches, it also underscores the critical importance of safety measures and the ongoing development of more accurate consequence modelling methods.
The True Worth of US Fossil Fuel Companies
You may want to see also
Explore related products
Delta IV Heavy can lift 28,370 kg to low Earth orbit
The Delta IV Heavy rocket was developed by Boeing and was the most powerful member of the Delta IV line of rockets. It was an all-liquid-fuelled launch vehicle, with a central Common Booster Core (CBC) and two additional CBCs as liquid rocket boosters. The rocket's total mass at launch was approximately 733,000 kg (1,616,000 lb), and it produced around 952,000 kg (2,099,000 lb) of thrust to power the rocket skyward at liftoff.
Delta IV Heavy was capable of lifting 28,370 kg (62,550 lb) to low Earth orbit and 13,810 kg (30,450 lb) to geostationary transfer orbit (GTO). This capacity made it the highest capacity of any operational launch vehicle in the world after the Space Shuttle retired in 2011 until the Falcon Heavy debuted in 2018. It was manufactured by United Launch Alliance (ULA) and first launched in December 2004.
The Delta IV Heavy's first stage consisted of a central CBC with two additional CBCs as liquid rocket boosters. At lift-off, all three rocket engines operated at full thrust. After 44 seconds, the central engine throttled down to 55% to conserve fuel until the other two engines separated. The Delta IV Heavy used three RS-68 engines, one in the central core and one in each booster. In the final seconds of countdown, liquid hydrogen fuel flowed through the engines, and after ignition, the hydrogen inflamed, creating a fireball and the charred appearance of the booster.
The Delta IV Heavy was used for several notable missions, including the launch of NASA's Orion spacecraft in 2014, which flew higher and faster than any other crewed spacecraft since Apollo 17 in 1972. It also launched the Parker Solar Probe in 2018, which studied the sun at close proximity to learn more about space weather. The final Delta IV Heavy core and boosters were completed in May 2023, and its last flight took place on April 9, 2024, marking the end of the Delta IV program.
Exploring Fuel Requirements for Leaving Earth's Atmosphere
You may want to see also
Frequently asked questions
Delta IV Heavy burns ultracold liquid hydrogen, a high-performance fuel. The total mass at launch is approximately 733,000 kg (1,616,000 lb).
The Delta IV Heavy rocket uses liquid hydrogen and liquid oxygen. The excess hydrogen is burned to prevent oxygen build-up in the engines, which could damage them.
The Delta 4 rocket produces around 952,000 kg (2,099,000 lb) of thrust at liftoff.
