The Scheid Diesel P7100 pump is a high-performance fuel injection pump that has been customised to use a 16mm plunger, as opposed to the standard 12mm plunger found in stock P-pumps. The increased diameter of the plunger allows for a higher rate of fuel injection, resulting in greater power output. This modification is part of advancements in mechanical injection pumps, specifically for use in sled pulling sports. The Scheid Diesel P7100 pump is capable of producing more than 1,500cc of fuel and spinning at over 7,000 rpm. This article will explore the impact of the 16mm plunger on fuel movement and the overall performance of the pump.
| Characteristics | Values |
|---|---|
| Diameter | 16mm |
| Function | To move media through a cylindrical chamber |
| Movement | Up and down in the plunger sleeve |
| Fuel production | More than 1,500cc of fuel |
| RPM | More than 7,000 |
Explore related products
What You'll Learn
The Scheid Diesel P7100 pump
The P7100 pump is capable of producing more than 1,500cc of fuel and spinning at speeds of over 7,000 rpm. To achieve this, Scheid Diesel has made extensive modifications to the original P-pump design, including the use of proprietary coatings on the camshaft, plungers, and other parts to increase durability. The pump cam, an important component in the 16mm build, was also designed by Scheid and features their proprietary coatings, improving reliability and reducing friction.
The P7100 conversion kit offered by Scheid Diesel includes everything needed to add the pump to a compatible vehicle. The kit addresses the challenges of integrating a larger pump, such as the need for an external oil feed line to lubricate the governor springs and weights, and a modified throttle linkage to accommodate the P7100's requirements.
Overall, the Scheid Diesel P7100 pump represents a significant advancement in diesel fuel injection technology, showcasing the potential for increased performance and power through innovative modifications to the P-pump design.
