The cost of replacing a fuel pump relay varies depending on the vehicle and the complexity of the procedure. It is generally recommended to consult a professional mechanic for an accurate estimate. Online sources suggest that the cost should typically be under $100, with some people expressing suspicion at prices higher than this. Testing and replacement can be done at home if you have the right equipment and knowledge, which can help to reduce costs.
| Characteristics | Values |
|---|---|
| Cost | Under $100 at a repair shop |
| Testing | Simple and straightforward |
| Replacement | Simple, but a professional should be consulted if electrical circuits are not understood |
| Location | Engine compartment, attached to the multi-use bracket on the upper dash panel extension |
| Models | Honda Accord, Honda Civic, Ford F150, Chevrolet Silverado 1500, Toyota Camry |
Explore related products
What You'll Learn
- Fuel pump relay replacement cost: Under $100 at a repair shop
- Testing a fuel pump relay: Apply power and ground to the small circuit
- Replacing a fuel pump relay: Disconnect wiring harness plug, remove the old relay, and install a new, identical one
- Fuel pump relay issues: Relay is operable but not activated when the ignition switch is turned on
- Fuel pump relays by car make: Honda, Ford, Chevrolet, and Toyota all have their own relays
Fuel pump relay replacement cost: Under $100 at a repair shop
The cost of replacing a fuel pump relay in a repair shop should be under $100, depending on how much diagnostic time is required. The replacement process is straightforward and involves the following steps:
- Verify that the ignition switch is in the "OFF" position.
- Disconnect the wiring harness plug.
- Remove the old fuel pump relay.
- Install the new fuel pump relay.
- Securely connect the wiring harness plug.
Before replacing the relay, it is essential to properly diagnose the issue. Testing a fuel pump relay is simple and can be done by following these steps:
- Locate the relay, which is usually attached to the multi-use bracket on the upper dash panel extension in the engine compartment.
- Identify the relay according to diagrams in the owner's manual or service manual for the vehicle.
- Check for loose connections.
- Apply power and ground to the small circuit with proper polarity, which should make the relay click.
- Measure the resistance across the relay and compare it to the data in the service manual or on the relay itself. If the resistance is too high, the relay needs to be replaced.
It is important to note that relays are inexpensive and should be replaced, not repaired or tampered with. The new relay must be identical in function and size to the original one.
