The AIM-9 Sidewinder is a short-range, supersonic, heat-seeking, air-to-air missile. It has been in service with the United States Navy since 1956 and with the Air Force since 1964. The AIM-9 Sidewinder is one of the oldest, cheapest, and most successful air-to-air missiles, with an estimated 270 aircraft kills. While the exact cost of the fuel used by the AIM-9 Sidewinder is not publicly available, the missile itself has a hefty price tag of around $427,000 to $472,000 per unit.
| Characteristics | Values |
|---|---|
| Type | Short-range, supersonic, heat-seeking, air-to-air missile |
| Warhead | High-explosive, blast-fragmentation |
| Weight | 4.5 kg (10 lb) |
| Speed | Mach 1.7 above launch speed |
| Range | 900 m (3000 ft) to 4.8 km (2.6 nm) |
| Kill Radius | 9 m (30 ft) |
| Propulsion | Thiokol MK 17 solid-fuel rocket motor |
| Thrust | 17.8 kN (4000 lb) |
| Duration | 2.2 s |
| Turn Rate | 12G |
| Guidance System | Infrared heat-seeking, passive infrared, IIR (Imaging Infrared) seeker |
| Users | United States Navy, Air Force, Western fixed-wing combat aircraft, helicopters |
| Cost | USD $56,000 to USD $84,000 (FY 1999) |
| Latest Version | AIM-9X Block II |
| Latest Cost | $455,000 each (FY2023) |
