The performance of diesel engines is heavily influenced by their injection system design. The main purpose of a fuel injection system is to deliver fuel into the engine cylinders while precisely controlling the injection timing, fuel atomization, and other parameters. The pressure at which diesel fuel is injected has a direct impact on the engine's efficiency, with higher pressures creating more efficiency. Today's diesel engines have considerably more fuel injection pressure than diesels of the past, with common rail injection systems delivering fuel at pressures as high as 28,000 psi. This raises the question of how many psi a diesel fuel injector can handle.
| Characteristics | Values |
|---|---|
| Purpose of fuel injection system | To deliver fuel into the engine cylinders, while precisely controlling the injection timing, fuel atomization, and other parameters |
| Main types of injection systems | Pump-line-nozzle, unit injector, and common rail |
| Fuel injection pressure range | 10,000-30,000 psi |
| Early Stanadyne DB2 injection pumps | 6,700 psi |
| Newer common-rail systems | 34,000-35,000 psi |
| Green Diesel Corp system | 160,000 psi |
| Fuel injection start | ≈15 BTDC on the compression stroke |
| Fuel atomization | Enabled by high-pressure injection; the biggest contributing factor to efficiency |
| Injection duration | The period of time during which fuel enters the combustion chamber from the injector |
| Injector lag | The difference between the actual SOI and indicated SOI |
| Injection delay | The time it takes for a pressure wave to travel between the pump and injector, influenced by the length of the line and the speed of sound in the fuel |
| End of injection (EOI) | The time in the cycle when fuel injection stops |
| Injected fuel quantity | The amount of fuel delivered to an engine cylinder per power stroke, expressed in mm3/stroke or mg/stroke |
| Injection pattern | The rate of injection of fuel, which often varies during the injection duration period |
