The external fuel tank of the Space Shuttle, also known as the ET, is painted orange due to the colour of the spray-on foam insulation. The ET is the largest element of the Space Shuttle and is responsible for containing the liquid hydrogen fuel and liquid oxygen oxidizer. The ET also features eight propellant-depletion sensors, four for fuel, and four for oxidizer, which constantly compute the instantaneous mass of the vehicle.
Explore related products
What You'll Learn
The orange colour is from spray-on foam insulation
The orange colour of some fuel tanks is due to the spray-on foam insulation that is applied to them. The Space Shuttle external tank (ET), for example, had an orange colour due to the application of this insulation. The ET was the component of the Space Shuttle launch vehicle responsible for containing and supplying liquid hydrogen fuel and liquid oxygen oxidizer to the engines during lift-off and ascent.
The ET was the largest and heaviest element of the Space Shuttle when loaded. While these external tanks were always discarded, there were plans to reuse them in orbit for various purposes, such as incorporating them into a space station or utilising them as rocket fuel tanks for interplanetary missions. The orange colour of the ET is a distinctive feature that sets it apart, and it is directly attributed to the spray-on foam insulation used in its construction.
This insulation played a critical role in protecting the tank from extreme temperatures and ensuring the thermal stability of the fuel and oxidizer it contained. By applying this insulation, engineers could mitigate the effects of rapid temperature changes during the shuttle's journey through different atmospheric layers. The choice of colour for the insulation may have been influenced by a combination of practical and safety considerations, ensuring the tank is easily identifiable and distinguished from other components.
Additionally, the orange colour of the spray-on foam insulation on fuel tanks can serve as a visual indicator for maintenance and inspection. It provides a clear contrast against the typical colours of fuels and lubricants, making it easier to identify leaks or damage during routine checks. This visual contrast aids in quickly detecting and addressing any issues, contributing to the overall safety and maintenance of the fuel tanks and surrounding systems.
