The Briggs & Stratton red disk fuel filter is for gravity-fed fuel systems, while the white disk and paper style are for fuel pump-equipped mowers. The direction of the fuel flow is usually indicated by an arrow on the filter. However, some users have suggested that the direction may not be critical for this type of filter. Some recommend mounting the filter so that the larger end is nearer the fuel tank, while others suggest mounting it so that the end with the filter element is fastened towards the carburetor to see any trash or dirt coming from the tank.
Explore related products
What You'll Learn
- The larger half of the filter leads into the direction of fuel flow
- The red filter is for gravity-fed fuel systems
- The white filter is for fuel pump-equipped mowers
- The filter should be mounted so the bigger end is nearer the fuel tank
- The filter should be mounted so that you can see trash coming from the tank
The larger half of the filter leads into the direction of fuel flow
The direction in which a fuel filter is installed can vary depending on its design and the system it is being fitted to. Some fuel filters have an arrow indicating the direction of fuel flow, and the filter should be installed accordingly.
The Briggs and Stratton red disk fuel filter is designed for gravity-fed fuel systems. It has a larger and narrower half, with the larger half leading into the direction of fuel flow into the motor. This means that the narrower half of the filter is on the side of the fuel tank.
Some users have noted that the direction of installation does not seem to matter for this particular filter, as it is a simple screen sandwiched between two plastic housings. However, others have pointed out that installing the filter in the correct direction ensures that any dirt or debris in the fuel can be seen, allowing for timely filter changes.
When installing a fuel filter, it is important to refer to the specific instructions provided by the manufacturer, as well as consider the type of fuel system it is being installed on.
