Honda Fury motorcycle owners may need to replace the fuel filter, which is located in the fuel pump at the bottom of the bowl. The fuel filter is not designed to last the lifetime of the vehicle and will need to be replaced. Honda changed the design of the fuel filter from a horizontal to a vertical element in 2012 models to address issues with the bike dying or not starting. Fuel filter kits for the Honda Fury are available for purchase online.
| Characteristics | Values |
|---|---|
| Fuel filter location | Inside the fuel tank |
| Fuel filter type | Type A (horizontal), Type B (vertical) |
| Kit part number | 16706-HN8-305 |
| Filter replacement | Not a lifetime part, needs replacement after a certain number of miles |
Explore related products
$52.99 $55.99
What You'll Learn
Honda Fury fuel filter location
The Honda Fury fuel filter location has changed over the years, with some early models having a horizontal fuel filter element at the bottom of the bowl, while newer models have a vertical element.
For the Honda Fury models from 2010, 2011, and some early 2012, the fuel filter element is located in the fuel pump in a horizontal position at the bottom of the bowl. This design was changed to a vertical element in the 2012 model and onwards, as the previous design led to issues with the bike dying or not starting.
For the Honda Pilot models from 2009 to 2015, the fuel filter is located inside the fuel tank, on the suction side of the pump. It is not serviced unless the pump itself is being replaced. The fuel filter and pump are one unit inside the tank.
The fuel filter can be changed separately, but it requires removing the tank and the fuel tank insert assembly. This assembly includes the filter, which can be described as a suction strainer, the fuel pump, the fuel pressure regulator, and the fuel tank level sender.
For the Honda Civic, the fuel filter location is in the tank, while for the Honda Accord, it is on the frame rail, and it is an in-line filter.
Changing Fuel Filter: 2005 Chevy Cavalier Guide
You may want to see also
Explore related products
Fuel filter replacement
Honda Fury motorcycles from 2010, 2011, and some early 2012 models had their fuel filter element in the fuel pump in the horizontal position at the bottom of the bowl. This design was flawed and resulted in numerous problems with the bike dying or not starting. Honda rectified this issue by changing to a vertical element in the 2012 model.
If you own one of the older models, you can upgrade the fuel filter by purchasing the Filter kit P/N 16706-HN8-305. This kit includes a Type B vertical filter, a modified fuel pump unit holder, and three O-ring seals. The process can be done without removing the tank, and you will only need a couple of fuel line clamps.
- Remove any covers or obstructions that may hinder access to the fuel pump and adjuster.
- Clean out your filter bowl.
- Remove the O-ring on the surface groove using a pick.
- Spin off the filter element, being mindful of the proper direction to turn it.
- Remove the fuel unit plastic housing by pushing from the bottom to relieve pressure on the tabs, then use a flat blade to open the tabs.
- When reassembling, ensure the O-ring is placed in the housing groove first.
- Install the new vertical filter and secure it with the three O-ring seals.
It is important to note that the fuel filter is not a lifetime part and will need to be replaced periodically, similar to a car's fuel filter. Regular maintenance of the fuel filter will help ensure the optimal performance of your Honda Fury motorcycle.
Fuel Filter Issues: Signs You Shouldn't Ignore
You may want to see also
Explore related products
Fuel filter kit
The Honda Fury fuel filter kit is a popular upgrade for Honda Fury motorcycles, especially for older models. The fuel filter kit, with part number #16706-HN8-305, includes a Type B vertical filter, a modified fuel pump unit holder, and three O-ring seals. This kit replaces the original Type A horizontal filter found in early Honda Fury models (2010, 2011, and some early 2012).
The Type B vertical filter in the kit allows the fuel pump to draw fuel from further up inside the reservoir, which is useful in situations of excessive fuel contamination. The vertical filter addresses the issues with the original horizontal filter design, which often led to problems with the bike dying or not starting.
To install the Honda Fury fuel filter kit, you will need to remove any covers that are blocking access to the shock and adjuster. You will also need to remove the fuel unit plastic housing by relieving pressure on the tabs and then opening them with a flat blade or a similar tool. The next step is to remove the old filter element by spinning it off in the proper direction (usually a quarter turn or slightly more).
When installing the new filter from the kit, pay attention to the outlet nipple on the fuel pump unit, which must be aligned properly. It may take some force to push the new filter down onto the unit. Remember to put the O-ring into the bore of the pump housing before installing the new filter. Once everything is assembled, put back the fuel clamps and verify that the system is primed and the fuel pump is full. Finally, start the bike and let it run, checking for any leaks.
Some Honda Fury owners have also added a small inline filter in the pump feed line, which can be done without removing the wheel. This additional filter can help keep the fuel pump clean and has been reported to work well without any issues.
Cleaning Diesel Fuel Filters: Step-by-Step Guide
You may want to see also
Explore related products
Fuel filter installation
The fuel filter in a Honda Fury motorcycle is located in the fuel pump at the bottom of the bowl. The fuel pump is in a reservoir, which is designed to hold sediment at the bottom, with the fuel filter held above to stay out of the sediment.
The fuel filter should be replaced as part of regular maintenance. Dirt in the fuel is captured by the filter, which clogs over time, causing it to operate less efficiently. This can lead to engine runnability problems such as low power, hesitation, and hard starting.
To install a new fuel filter, first relieve the pressure in the fuel line. Place a bowl or bucket beneath the fuel filter to catch any fuel that may spill out when disconnected from the fuel filter. Remove the clips holding the fuel filter in place, usually two plastic clips on either side of the cylindrical fuel filter. Use a flat-head screwdriver to pop them out.
Before installing the new fuel filter, compare it to the old one to ensure they are the same. Check that the outside diameters and the nozzles are the same size, and that it will fit into the bracket. Slide the new fuel filter into the bracket. It should easily slide in and stop when it is seated properly.
It is important to note that diesel-powered vehicles have multiple fuel filters that act as water separators and must be changed regularly. The fuel filters in diesel cars and trucks are usually larger, and the system is more complex and under higher pressure.
Jeep Renegade Fuel Filter: Location and Access Guide
You may want to see also
Explore related products
Fuel filter maintenance
Honda Fury motorcycles from 2010, 2011, and some early 2012 models have a fuel filter element in the fuel pump in the horizontal position at the bottom of the bowl. This design was changed to a vertical element in the 2012 model due to issues with the bike dying or not starting.
To maintain the fuel filter, you will need to replace the fuel filter element, as it is not a lifetime part. Here are the steps to replace the fuel filter:
- Remove any covers or parts that may obstruct access to the fuel filter. This may include removing the shock and adjuster if you are running OEM.
- Clean out your filter bowl.
- Remove the fuel unit plastic housing by pushing from the bottom to relieve pressure on the tabs, then use a flat blade to open the tabs.
- Spin off the old filter element, noting the proper direction to turn it.
- Install the new filter element onto the pump element outlet. Apply silicone grease to the O-ring before installation. Ensure the filter element is locked in correctly and aligned with the pump plastic housing.
- Reassemble the fuel unit plastic housing and ensure all tabs are secure.
It is recommended to refer to the service manual or instructions provided with the fuel filter kit for a more detailed guide on maintaining and replacing the fuel filter.
Fuel Filter Facts for the 2006 Trailblazer
You may want to see also
Frequently asked questions
The fuel filter on a Honda Fury is located in the fuel tank.
To replace the fuel filter, you will need to remove the fuel tank and the fuel tank insert assembly. This will give you access to the fuel filter, which is part of the fuel pump assembly.
Honda Fury motorcycles use a Type A horizontal filter as original equipment. However, an upgraded Type B vertical filter is also available, which can be installed using a fuel filter kit.
