The fuel tank on a 76 Ford F150 is located behind the seat in the cab, and there is also a side-mounted auxiliary fuel tank. There are two different filler hoses for the aft axle fuel tank: one with an Evaporative Emission System and one without. The hose must be made of neoprene rubber to prevent rotting.
| Characteristics | Values |
|---|---|
| Fuel tank capacity | 17-19 gallons |
| Fuel tank location | Between the frame rails, behind the seat, or underneath the cab |
| Fuel tank type | Aft axle fuel tank with or without an Evaporative Emission System |
| Fuel tank hose material | Neoprene rubber |
| Fuel tank selector | Manual lever or switch at the base of the driver's side floor |
| Fuel gauge functionality | May vary, some users report issues with accuracy |
Explore related products
What You'll Learn
The 1976 F150 has dual fuel tanks
The 1976 F150 Styleside pickup has an aft-axle fuel tank, which can be equipped with or without an Evaporative Emission System. If the vehicle has the Evaporative Emission System, there will be a charcoal canister mounted on the frame rail next to the alternator. A round fuel vapour valve is nestled into the top of the fuel tank, with a line routing from it to the canister.
The fuel tanks on the 1976 F150 are known to have some issues. One common problem is the front tank gauge reading empty when it still has fuel, which is a common issue with dual-tank F Series trucks from 1979 to 1997. Additionally, the original sending unit on the 1976 F150 has been reported to read the fuel gauge too high, and the outlet tubing size may not match the vehicle's specifications.
It is important to note that the hoses used for the fuel system must be made from neoprene rubber to prevent them from rotting out within a short time.
