The fuel filter in a VT Commodore is located behind the fuel tank, near the differential, and is attached to the chassis via a plastic clip. It is accessible from underneath and behind the car on the right side. Before attempting to replace the fuel filter, it is important to relieve fuel pressure and disconnect the battery and fuel fuse to avoid leakage. Ryco fuel filters are a popular choice for the VT Commodore as they are designed to protect the fuel system components by removing contaminants and moisture.
| Characteristics | Values |
|---|---|
| Location | Behind the fuel tank, next to the differential, on the right side of the car |
| Accessibility | From underneath and behind the car |
| Attachment | Held in place with a plastic clip attached to the chassis |
| Type | Metal in-line type |
| Cost | $20 |
| Tools | $25 at Holden |
| Fuel leakage prevention | Purchase the correct fuel filter with special fittings |
| Direction | Make a note of which direction the filter is installed |
| Fuel pressure | Relieve fuel pressure before starting |
Explore related products
What You'll Learn
The fuel filter is located behind the fuel tank, near the differential
The fuel filter in a VT Commodore is located behind the fuel tank, near the differential. It is accessible from underneath the car, on the right side. The filter is held in place with a plastic clip, which can be removed once the hoses have been detached.
Before attempting to access the fuel filter, it is important to relieve fuel pressure. This can be done by leaving the car running and removing the fuel pump fuse. Additionally, it is recommended to disconnect the battery and fuel fuse to ensure safety.
When removing the hoses, be cautious as they can break easily. Some people suggest squeezing them, possibly using pliers. However, it is important to note that applying too much force can result in breakage.
The fuel filter is a metal inline type and costs around $20 to replace. Ensure that you purchase the correct replacement filter as the fuel line has special fittings to prevent leakage.
It is also worth noting that Holden has made it deliberately difficult to change the fuel filter, as they want to discourage home mechanics. Therefore, it is advised to seek professional assistance if you are unsure about the process.
Polaris 600 Switchback: Where's the Fuel Filter?
You may want to see also
Explore related products
It is attached to the chassis with a plastic clip
The fuel filter in a VT Commodore is located behind the fuel tank, next to the differential, and on the right side of the car. It is attached to the chassis with a plastic clip, which can be removed, although it is recommended to remove the hoses first.
To access the fuel filter, you can back the car up on ramps to provide ample workspace. Before starting, it is crucial to relieve fuel pressure by leaving the car running and pulling out the fuel pump fuse. Additionally, removing the fuel cap can help release pressure from the tank.
When it comes to removing the hoses, caution must be exercised to avoid fuel leakage. Some people suggest squeezing the hoses, possibly with pliers, but they can break easily. It is important to note that the fuel line has special fittings to prevent leakage.
The plastic clip that secures the fuel filter to the chassis can be challenging to remove without breaking. Applying slight pressure to the ends while depressing the locking clip may help release it. A small screwdriver might also assist in removing the clip and hoses.
It is worth mentioning that Holden has made it deliberately difficult for home mechanics to perform this task. Specialized tools for removing the fuel line from the filter are available from Holden for a modest price, making the process more accessible.
Polaris 900 XP Fuel Filter: Where is it?
You may want to see also
Explore related products
Relieve fuel pressure before starting
To relieve fuel pressure before starting work on a VT Commodore, there are a few methods that can be used. One source outlines the following steps: firstly, remove the fuel cap to relieve pressure from the tank. Then, open the bonnet and locate the "fuse and electrical centre", usually on the left wall. Under the lid, there is a map to the fuel pump relay, which should be removed. Try to start the engine and let it "run" until it dies. Then, turn the engine over for about 10 seconds.
Another method to relieve fuel pressure is to leave the car running and then pull out the fuel pump fuse.
It is important to relieve fuel pressure and be cautious when working with fuel. One source states that a manual is a must-have when attempting this task. Additionally, it is recommended to disconnect the battery and fuel fuse before starting.
The fuel filter on a VT Commodore is accessible from underneath and behind the car, next to the differential, and on the right side. It is held in place with a plastic clip, which can be removed after the hoses are detached. Some people recommend squeezing the hoses, possibly with pliers, to remove them, but be aware that they break easily.
When replacing the fuel filter, it is important to note the direction the filter is installed. Leave one of the plugs on the new filter connected, and as you take off one end of the hose, plug it straight into the new filter. Then, put the old filter's plug on the old filter, and connect the other end of the hose to the new filter before re-clipping it to the car.
Fuel Filter Installation: Carburetor Fuel Filter Placement
You may want to see also
Explore related products
Disconnect the battery and fuel fuse
The fuel filter in a VT Commodore is accessible from underneath and behind the car, next to the differential and on the right side of the car. Before attempting to change the fuel filter, it is important to disconnect the battery and fuel fuse.
To disconnect the battery, start by locating the battery in the car. The battery may be located behind the kick panel on the driver or passenger side of the car, or it may be in the trunk or engine bay. Once you have located the battery, disconnect the negative terminal first, followed by the positive terminal. Be careful not to short-circuit the battery by touching the positive and negative terminals together.
After disconnecting the battery, locate the fuel fuse. The fuel fuse is typically located in the fuse box, which may be found in the engine bay or inside the car, such as under the dashboard or in the glove compartment. The fuse box may have a diagram or list that indicates which fuse is for the fuel system. If not, look for a fuse that is labeled as "Fuel Pump" or "Fuel Injector". Once you have located the fuel fuse, remove it from the fuse box.
It is important to note that disconnecting the battery and fuel fuse should only be done when the car is not running. Additionally, be sure to relieve fuel pressure before working on the fuel system to avoid fuel leakage and potential safety hazards. This can be done by leaving the car running and pulling out the fuel pump fuse, or by removing the fuel cap to take the pressure from the tank.
Volvo V70 Fuel Filter: Where is it?
You may want to see also
Explore related products
Use a screwdriver to remove hoses and clips
To replace the fuel filter on a Holden Commodore VT V6, you will need to relieve fuel pressure. This can be done by removing the fuel cap to relieve pressure from the tank, then locating the fuel pump relay in the fuse and electrical centre, removing it, and letting the engine run until it stops. You should then crank the engine a further two to three times.
The fuel filter is located underneath and behind the car, next to the differential on the right side. You can back the car up onto ramps to make it easier to work on.
Now, to use a screwdriver to remove the hoses and clips:
The filter is held in place with a plastic clip. It is recommended to leave this until after the hoses have been removed. To remove the hoses, some people suggest squeezing them, possibly using pliers, but this can cause breakage. Instead, insert a small flat screwdriver into the larger holes on each side of the hose-end clip, in the direction of the filter end of the hose/clip. With a little levering of the screwdriver and a push-pull action, the hose should come out easily without breaking.
Before removing the filter, make a note of the direction it is installed. To avoid fuel leakage, leave one of the plugs on the new filter, and as you take off one end of the hose, plug it straight into the new filter. Then, put the plug that came with the new filter on the old filter before removing the other hose.
Be sure to disconnect the battery and fuel fuse before attempting to remove the filter, and be careful with fuel leakage.
Outboard Fuel Filter: 1974 Mercury Edition
You may want to see also
Frequently asked questions
The fuel filter in a VT Commodore is located behind the fuel tank, near the differential. It is attached to the chassis via a plastic clip and is accessible from underneath and behind the car, on the right side.
It is recommended to relieve fuel pressure before attempting to change the fuel filter. This can be done by leaving the car running and pulling out the fuel pump fuse. The filter is held in place with a plastic clip, which can be removed after the hoses have been detached. To avoid fuel leakage, leave one of the plugs on the new filter connected while removing the other hose end from the old filter.
A manual and ramps are essential when changing the fuel filter. Tools for taking the fuel line off the filter can be purchased for around $25.
The VT Commodore uses a metal inline fuel filter. Ryco fuel filters are designed to suit Holden Commodores with V6 engines.
Some signs that the fuel filter may need replacement include the car stalling under load or jerking while driving. It is important to consult a professional mechanic if you are unsure about replacing the fuel filter yourself.
