The fuel filter on a Gen 2 Yamaha FZ1 is located within the fuel pump assembly, which is inside the fuel tank. To access the fuel filter, you must first remove the gas tank and disconnect the electrical connectors below it. Then, by removing the fuel line and carefully taking out the pump assembly, you can access and clean or replace the fuel filter.
| Characteristics | Values |
|---|---|
| Fuel Filter OEM Part Number | Yamaha: 1FK-24560-01-00 / 809-24560-01-00 / 1Fk-24560-10-00 / 1Fk-24560-00-00 |
| Location | Inside the fuel tank |
| Steps to access the fuel filter | 1. Remove the gas tank. |
| 2. Disconnect the two electrical connectors below the tank. | |
| 3. Remove the fuel line. | |
| 4. Disconnect the breather tube. | |
| 5. Remove the long Allen bolt from the rear of the tank. | |
| 6. With the tank vertice, pull the rubber pressure relief hose out of the way. | |
| 7. Remove the allenhead bolts from the aluminum retaining ring. | |
| 8. Carefully pull the fuel pump assembly out of the tank. | |
| 9. Disconnect the #1 and #2 connectors. | |
| 10. Separate the base from the body by pulling back the outer white plastic clips. | |
| 11. Disconnect the pump from the body by releasing the blue plastic clips. | |
| 12. Slide the pump out and remove the plug from the top of the pump. |
Explore related products
What You'll Learn
The fuel filter is inside the fuel tank
The fuel filter on the Yamaha FZ1 is located inside the fuel tank, incorporated into the fuel pump assembly.
To access the fuel filter, you will first need to remove the gas tank. Prop up the tank and remove the two electrical connectors below it. Then, remove the fuel line by sliding the outer portion back, pressing the two buttons, and working it off the end.
Once the fuel line is disconnected, you can remove the fuel pump assembly from the tank. There is a float for the fuel gauge attached, so turn the assembly carefully to remove it.
With the fuel pump assembly removed, you can access the fuel filter. It is located inside the assembly and may be "'clip-locked' into place.
When reassembling, be sure to keep the plugs in the same spots and use a small flat screwdriver to depress the locking tab and release the connector.
Fuel Filter Location Guide for 2001 Cavalier
You may want to see also
Explore related products
It's part of the fuel pump/filter assembly
The fuel filter on a Gen 2 FZ1 Yamaha motorcycle is part of the fuel pump/filter assembly. This assembly is located inside the fuel tank.
To access the fuel filter, you must first remove the gas tank and disconnect the electrical connectors below it. Then, remove the fuel line by sliding the outer portion back, pressing the two buttons, and working it off the end. With the tank propped up against a wall, you can then pull out the rubber pressure relief hose and remove the bolts from the aluminum retaining ring.
The fuel pump assembly can then be carefully pulled out of the tank. It is important to note that there is a float for the fuel gauge attached, so it will not come out straight away. Once the assembly is removed, you can disconnect the connectors and separate the base from the body by pulling back the outer white plastic clips.
The fuel pump can then be disconnected from the body by releasing the blue plastic clips. After sliding out the pump, you will have access to the fuel filter.
Fuel Filter Lifespan: How Long Before a Replacement?
You may want to see also
Explore related products
You need to remove the gas tank to access it
To access the fuel filter on a Gen 2 Yamaha FZ1, you need to remove the gas tank. First, remove the two electrical connectors below the tank. Then, remove the fuel line by sliding the outer portion back, pressing the two buttons, and working it off the end. If your gas tank is full, you should siphon or dump out as much fuel as possible to prevent a mess. Next, pull the breather tube out or disconnect it. Finally, remove the long Allen bolt from the rear of the tank.
With the tank removed, you can now access the fuel pump/filter assembly. Prop the tank up against a wall with a towel to prevent damage to the paint. Pull the rubber pressure relief hose out of the way, then remove the Allen head bolts from the aluminium retaining ring. Now, carefully pull the fuel pump assembly out of the tank. There is a float for the fuel gauge attached, so it won't come straight out, but with a slight turn, it will come out easily.
Once the assembly is removed, carefully disconnect the connectors. Now you can separate the base from the body by pulling back the outer white plastic clips. Then, disconnect the pump from the body by releasing the blue plastic clips. Slide the pump out, then remove the plug from the top of the pump. Now you have access to the fuel filter.
After cleaning or replacing the fuel filter, simply reassemble everything in the reverse order of disassembly.
Locating the Fuel Filter in a 2004 Ford Ranger
You may want to see also
Explore related products
Disconnect the electrical connectors
To disconnect the electrical connectors on a 2009 Yamaha FZ1, you will need to remove the gas tank. Prop it up and remove the two electrical connectors below the tank. You will then need to remove the fuel line by sliding the outer portion back, pressing the two buttons, and working it off the end.
Now, with the tank vertical (leaned up against a wall with a towel to prevent damage to the paint), pull the rubber pressure relief hose out of the way, and remove the Allen-head bolts from the aluminium retaining ring. Carefully pull the fuel pump assembly out of the tank. There is a float for the fuel gauge attached, so it won't come straight out, but turning it the right way will allow it to be removed easily.
Once the assembly is removed, carefully disconnect the #1 and #2 connectors. You can use a small flat screwdriver to depress the locking tab and release the connector.
Be sure to keep the plugs in the same spots while reconnecting, as they will fit in either spot.
Fuel Filter Bypass: Is It Possible?
You may want to see also
Explore related products
It's a bag-styled filter in the pump assembly
The fuel filter on the Yamaha FZ1 is located within the fuel pump assembly, which is housed inside the fuel tank. To access the fuel pump and filter, you must first remove the gas tank. This involves propping up the tank and removing the electrical connectors below it. The fuel line can then be removed by sliding the outer portion back, pressing the two buttons, and working it off the end.
With the tank removed, you can access the fuel pump assembly. Be sure to place the tank against a wall with a towel to prevent damage to the paint. Pull the rubber pressure relief hose out of the way, and then remove the Allen-head bolts from the aluminium retaining ring. The fuel pump assembly can now be carefully pulled out of the tank. It's important to note that there is a float for the fuel gauge attached, so turning it the right way will make it easier to remove.
Once the assembly is out, carefully disconnect the connectors. To access the fuel filter itself, you need to separate what some call the "base" from the "body" by pulling back the outer white plastic clips. Then, disconnect the pump from the body by releasing the blue plastic clips. Slide the pump out and remove the plug from the top.
The fuel filter is a bag-style filter located within the pump assembly. It is secured with clips and can be removed for cleaning or replacement. It is recommended to clean the fuel filter periodically to maintain optimal performance and avoid issues like coughing and spluttering, also known as "fuel starve" symptoms.
Checking Fuel Filter on Chevy Silverado: Step-by-Step Guide
You may want to see also
Frequently asked questions
The fuel filter is inside the fuel tank, incorporated with the fuel pump.
First, remove the gas tank and disconnect the electrical connectors below it. Then, remove the fuel line by sliding the outer portion back and pressing the two buttons. Finally, carefully pull the fuel pump assembly out of the tank.
Once you have accessed the fuel filter, you can clean it by swirling it in a bowl of seafoam and wiping it with a clean rag.
There is no recommended replacement or cleaning time provided by Yamaha. However, some users suggest cleaning the fuel filter periodically to maintain optimal performance.
Yes, the fuel filter can be replaced. You can find replacement fuel filters available for purchase online.
