The fuel tank of an aircraft is typically located in its wings, as is the case with the Boeing 747, which has fuel tanks that take up the entire wingspan of the plane. This design improves overall structural efficiency by counter-balancing the wing's lift and the fuselage's weight, and enhances safety by placing the fuel away from the passenger compartment.
| Characteristics | Values |
|---|---|
| Location of fuel tanks | Commonly located in the wings instead of the main body or fuselage of the aircraft |
| Reason for location in wings | Improves overall structural efficiency, counter-balancing the wing's lift and the fuselage's weight, reduces aircraft fuel system complexity, and improves passenger safety by locating fuel away from the passenger compartment |
| Reason for phasing out fuselage fuel tanks | Increased engineering complexity, weight complexity, and safety concerns |
| Aircraft with fuselage fuel tanks | Boeing 747 and Concorde |
| Fuel tank size | Large enough to hold fuel that is burnt at a rate of approximately 4L (0.9 gallons) per second while in flight |
| Temporary fuel tanks | Installed in the space where seats normally are to enable short-haul jets to travel longer distances |
Explore related products
What You'll Learn
Fuel tanks in the wings improve structural efficiency
Fuel tanks in the wings of a Boeing aircraft, such as the Boeing 747, offer several advantages that improve the plane's structural efficiency, performance, stability, and safety. Firstly, the wings are among the strongest parts of an aircraft, designed to withstand significant forces during flight, including turbulence and high-speed airflow. By placing the fuel tanks in the wings, the weight of the fuel is distributed to the strongest structural components of the plane, reducing the structural load on other parts of the aircraft. This weight distribution also improves the overall balance of the aircraft, ensuring a stable center of gravity, which is crucial for maintaining stable flight and reducing the chances of imbalance during flight.
Additionally, the wings are naturally streamlined, and by placing the fuel tanks within them, the aircraft's overall design remains more aerodynamic. This improved aerodynamics reduces drag, allowing the plane to fly more smoothly and efficiently, saving fuel and optimising the flight's operational excellence. The weight of the fuel in the wings also counterbalances the weight of the engines and other fuselage components, further enhancing the aircraft's aerodynamics and performance.
The use of wing fuel tanks also eliminates the need for bulky fuel tanks elsewhere in the aircraft, freeing up space in the fuselage for seating and storage. This makes the plane lighter and more fuel-efficient, as there is no need for additional structural reinforcements inside the fuselage. Furthermore, filling the wing fuel tanks first and using them last is critical for ensuring safety, efficiency, and performance during flight. This strategic use of fuel from the wings influences the aircraft's overall weight distribution, fuel efficiency, and performance, reducing the risk of wing flutter induced by fuel weight.
In conclusion, placing fuel tanks in the wings of a Boeing aircraft provides numerous benefits that improve the structural efficiency of the plane. The wings' strength, natural aerodynamics, and weight distribution capabilities make them ideal for housing fuel tanks, resulting in enhanced performance, stability, and safety during flight.
