The Space Shuttle Atlantis exhibit is a sprawling tourist attraction at the Kennedy Space Center Visitor Complex in Florida. The exhibit features a full-scale model of the Atlantis, which is raised off the ground and tilted. The boosters and fuel tanks for the Atlantis were solid rocket boosters (SRBs) and an external tank (ET). The ET was the largest and heaviest element of the Space Shuttle, providing structural support and supplying fuel and oxidizer to the RS-25 main engines during lift-off and ascent. The SRBs burned a large amount of solid fuel to accelerate the shuttle before being jettisoned and recovered for future missions.
| Characteristics | Values |
|---|---|
| Location of the boosters and fuel tanks for Atlantis | Kennedy Space Center, Florida |
| Type of boosters | Solid Rocket Boosters (SRBs) |
| Fuel tank | External Tank (ET) |
| Fuel type | Liquid hydrogen fuel and liquid oxygen oxidizer |
| First launch | April 12, 1981 |
| Exhibit building location | Kennedy Space Center Visitor Complex, Florida |
| Exhibit building cost | $100 million |
| Exhibit building size | 90,000 square feet |
Explore related products
What You'll Learn
- The Space Shuttle Atlantis exhibit features replicas of boosters and fuel tanks
- The boosters and tanks for Atlantis were designed by Custom fabricator Penwal Industries
- The boosters and tanks are housed in the Vehicle Assembly Building at NASA's Kennedy Space Center
- The boosters and tanks were raised to a vertical position before stacking with Atlantis
- The boosters and tanks were connected to the orbiter at three attachment points
The Space Shuttle Atlantis exhibit features replicas of boosters and fuel tanks
The boosters and fuel tanks played a crucial role in the space shuttle program, providing the fuel and thrust necessary to propel the orbiters into space. The solid rocket boosters (SRBs) burned through more than two million pounds of solid fuel, accelerating the shuttle to 3,500 miles per hour (5633 kilometers per hour) within the first two minutes of liftoff. After burning out, the SRBs were jettisoned over the ocean and later recovered for reuse in future missions.
The external fuel tank (ET), on the other hand, was the largest and heaviest component of the Space Shuttle. It contained liquid hydrogen fuel and liquid oxygen oxidizer, supplying them under pressure to the orbiter's main engines during lift-off and ascent. The ET also provided structural support for the attachment of the solid rocket boosters and the orbiter. Despite proposals to reuse the external tanks, such as in a lunar habitat or as an orbital station, they were ultimately not recovered and broke up before impact in the Indian Ocean or the Pacific Ocean.
The replicas of the boosters and fuel tanks in the Atlantis exhibit were designed and manufactured by Custom Fabricator Penwal Industries of California. These replicas stand at an impressive height, with the boosters reaching 149 feet (45 meters) tall and serving as a dramatic gateway to the exhibit. The Space Shuttle Atlantis exhibit offers visitors a glimpse into the engineering and technology behind the space shuttle program, showcasing the crucial components that enabled the shuttle's journey into space.
