The fuel tank indicator arrow is a small arrow on the dashboard of a car that points to the side of the vehicle where the fuel filler cap is located. While some sources claim that the arrow was invented by Ford designer Jim Moylan in 1986 and introduced in select Ford models in 1989, others suggest that it first appeared earlier, in 1976, on the dash cluster of the Mercedes-Benz W123. Regardless of its exact origin, the fuel tank indicator arrow has become a ubiquitous feature in modern vehicles, helping drivers quickly and conveniently locate the fuel filler cap.
| Characteristics | Values |
|---|---|
| Year of introduction | 1989 |
| Inventor | Jim Moylan |
| Company | Ford |
| Models | Ford Escort and Mercury Tracer |
| Other names | Moylan Arrow |
| Previous symbols | Right or Left |
| Purpose | Indicates the side of the vehicle the fuel fill door is located |
Explore related products
What You'll Learn
- The arrow symbol was introduced to show the side of the vehicle where the fuel filler cap is located
- The symbol was invented by Ford designer Jim Moylan in 1986
- The first cars to feature the arrow were the 1989 Ford Escort and Mercury Tracer
- Moylan chose not to patent the design, leading to its proliferation
- Before the arrow, symbols like 'left' or 'right' were used to indicate the fuel filler cap side
The arrow symbol was introduced to show the side of the vehicle where the fuel filler cap is located
The arrow symbol on the fuel indicator was introduced to show the side of the vehicle where the fuel filler cap is located. It is a simple yet brilliant bit of human-machine interface design. The arrow was first introduced in 1989 in select Ford models, including the Ford Escort and Mercury Tracer. However, some sources suggest that earlier versions of the arrow symbol may have existed, such as on the dash cluster of the 1976 Mercedes-Benz W123.
The story behind the invention of the arrow symbol is quite interesting. It is credited to a Ford designer named Jim Moylan, who, in April 1986, had a frustrating experience of getting soaked while filling up a Ford company car in the rain because he picked the wrong side. Moylan proposed the idea of an indicator in a memo to his bosses, and they recognised its value, especially given its low implementation cost.
Before the introduction of the arrow symbol, car manufacturers used symbols like "right" or "left" to indicate the presence of a fuel filler cap. The arrow symbol was a much simpler and more intuitive solution. It is now a ubiquitous feature in modern vehicles, although some cars still use alternative methods, such as the picture of a fuel pump on the side where the tank is located.
The arrow symbol is beneficial for drivers, especially when renting or borrowing a car, as it saves time and embarrassment by clearly indicating the position of the fuel filling cap. It is a small but helpful detail that enhances the driving experience and showcases the evolution of car design and its focus on user convenience.
