The fuel injection system in a car is a mechanism that introduces fuel into an internal combustion engine. All compression-ignition engines (e.g. diesel engines) and many spark-ignition engines (i.e. petrol engines) use fuel injection. The system has become increasingly common since the 1950s, and now all cars sold in the United States have fuel injection systems. The primary difference between carburetion and fuel injection is that fuel injection atomizes the fuel through a small nozzle under high pressure, while carburetion relies on suction created by intake air accelerated through a Venturi tube to draw fuel into the airstream. The term fuel injection is vague and comprises various distinct systems with fundamentally different functional principles. These include external or internal air-fuel mixture formation, the number of injection points (nozzles), and direct or indirect injection (whether the fuel goes straight to the combustion chamber or not).
Explore related products
$11.12 $12.38
What You'll Learn
How fuel injection works
Fuel injection is a modern engineering amenity that has been around since the 1950s and is now used in all cars sold in the United States. It is one of the biggest reasons why modern cars are so good at everything. Fuel injection systems are designed to get gasoline into the engine cylinder so it can combust and make the car drive.
The fundamental difference between fuel injection and carburetors is that fuel injection atomizes the fuel through a small nozzle under high pressure, while carburetors rely on suction created by intake air accelerated through a Venturi tube to draw fuel into the airstream. Carburetors were replaced with throttle body fuel injection systems (also known as single-point or central fuel injection systems) that incorporated electrically controlled fuel-injector valves into the throttle body. Gradually, as new engines were designed, throttle body fuel injection was replaced by multi-port fuel injection (also known as port, multi-point, or sequential fuel injection). These systems have a fuel injector for each cylinder, usually located so that they spray right at the intake valve. These systems provide more accurate fuel metering and quicker response.
There are two types of fuel injectors: mechanical and electronic. Mechanical fuel injectors pump high-pressure fuel from the fuel tank. Once the fuel pumps from the fuel tank, it enters the accumulator, a buffer for temporary fuel storage. The metering control unit then distributes this fuel to the vehicle’s cylinders. A fuel injector is an electronically controlled valve. It is supplied with pressurized fuel by the fuel pump in your car, and it is capable of opening and closing many times per second. When the injector is energized, an electromagnet moves a plunger that opens the valve, allowing the pressurized fuel to squirt out through a tiny nozzle. The nozzle is designed to atomize the fuel — to make as fine a mist as possible so that it can burn easily. The amount of fuel supplied to the engine is determined by the amount of time the fuel injector stays open. This is called the pulse width, and it is controlled by the ECU. The fuel injectors are mounted in the intake manifold so that they spray fuel directly at the intake valves. A pipe called the fuel rail supplies pressurized fuel to all of the injectors.
The biggest advantage of electronic fuel injection (EFI), the most common form of injection, is that it can operate in a closed loop. This means that the EFI can actively tune itself depending on conditions, always optimizing fuel mixture based on readings from either the mass air flow sensor or manifold pressure sensor, or oxygen sensor. This means that the car can start effortlessly in below-freezing temperatures at 14,000 ft and then immediately do the same thing at 110 degrees Fahrenheit at sea level.
The Fuel Behind F1 Cars: What's in the Tank?
You may want to see also
Explore related products
The history of fuel injection
Fuel injection systems were developed early in the history of the internal combustion engine, but they did not enter the automotive market until the 1950s. During World War I, fuel-injected plane designs were used in combat, and the technology continued to be used in aircraft design thereafter.
In almost every country that implemented fuel injection in military airplane production, the technology was adapted for the automotive industry. One notable exception was the USSR, where carburetted VAZ cars were produced into the early 2000s.
During World War II, Germany began equipping its fighter aircraft with direct fuel injection to prevent engine stall-out during high-speed aerial maneuvers. This technology was also used in the famous German Messerschmitt Bf 109s, which outperformed British fighters such as the Supermarine Spitfire and the Hawker Hurricane.
In the 1970s, automakers struggled to design carburettor technology that could keep up with clean air demands. The designs became complex and unwieldy, and it was simpler and more efficient to switch to electronic fuel injection. Early EFI units typically burned out before 100,000 miles, but the increased computing power and smaller size of EFI modules in the 1980s allowed for better control and more consistent performance.
By the 1990s, fuel injection had largely replaced carburettors. The primary difference between the two systems is that fuel injection atomizes the fuel through a small nozzle under high pressure, while carburettors rely on suction created by intake air accelerated through a Venturi tube to draw fuel into the airstream.
Today, all cars sold in the United States have fuel injection systems, and direct injection in petrol engines has become increasingly common in the 21st century.
Cars: Fuel Consumption While Stationary, Explained
You may want to see also
Explore related products
Different types of fuel injection systems
Fuel injection systems are a combination of mechanical and electronic circuits that supply fuel to a car's combustion engine. The right type of fuel injection system can improve mileage, ride quality, and engine life.
The two main functional principles of mixture formation systems for internal combustion engines are internal and external. A fuel injection system that uses external mixture formation is called a manifold injection system. There are two types of manifold injection systems: multi-point (or port) and single-point (or throttle body) injection.
Single-point injection, also known as throttle body injection (TBI), is the oldest and simplest form of the fuel injection system. It uses one or two fuel injector nozzles in the throttle body. The fuel is sprayed in all cylinders at the same time. However, as it uses a single injector, it can cause a rough ride quality at high RPMs as the required fuel supply is not fulfilled.
Multi-point injection, also known as port injection, injects fuel into the intake ports just upstream of each cylinder's intake valve. Multi-point injected systems typically use multiple fuel injectors, but some systems use tubes with poppet valves fed by a central injector instead of multiple injectors.
Internal mixture formation systems can be separated into several different varieties of direct and indirect injection. The most common is the common-rail injection, a variety of direct injection. In a common-rail system, fuel from the fuel tank is supplied to a common header (called the accumulator), and then sent through tubing to the injectors, which inject it into the combustion chambers.
Direct injection is one of the most advanced fuel injection systems. More commonly seen on diesel engines, this technology is now also being used in petrol engines. In a direct injection system, the fuel is injected directly into the combustion chamber, i.e., the cylinder. The advantage of this system is that there is no wastage of fuel or any carbon deposit at the intake valve.
The sequential fuel injection system is the most widely used fuel injection system today. In this system, the fuel injectors function with respect to the cylinders they are connected to. Every injector injects the fuel only when the intake valve of the cylinder opens. It remains idle for the rest of the steps.
Other types of fuel injection systems include the Lucas PI system, which is a timed system, and the Bosch K-Jetronic system, a continuous injection system.
Electric Fuel Pumps: Are They Worth the Hype?
You may want to see also
Explore related products
Benefits of fuel injection over carburettors
Fuel injection systems are a relatively modern development in the automotive world, superseding the carburettor, which was the most common fuel delivery method until the 1980s and 90s. While carburettors are purely mechanical, fuel injection systems are comprised of a complex set of electronics and sensors.
One of the primary benefits of fuel injection systems is their ability to precisely control the air-to-fuel ratio, resulting in more efficient fuel use, reduced fuel consumption, and lower emissions. This is achieved through an ECU (electronic control unit), which constantly makes complex calculations to deliver the best air-fuel mixture possible, based on parameters such as engine speed, throttle position, engine temperature, and load. This dynamic adjustment of parameters ensures that the engine will start in any weather, hot or cold. In contrast, carburettors are sensitive to changes in weather conditions and are difficult to start at colder temperatures and higher altitudes without adjustment.
Fuel injection systems also offer higher power and torque than carburetted engines. The accuracy of fuel injection and modern electronic controls allow for fuel delivery that matches driver demand, providing more precision than a carburettor. Additionally, fuel injection systems do not require periodic tuning or adjustment, as the electronic system can constantly tweak the balance depending on the engine's needs, resulting in less maintenance.
While carburettors are cheaper to buy and repair, fuel injection systems provide superior performance, fuel economy, and lower emissions, making them a clear winner for modern drivers.
What Flex Fuel Cars Can and Can't Handle
You may want to see also
Explore related products
How to maintain a fuel injection system
Fuel injection systems in cars are designed to deliver precise bursts of fuel to the engine, ensuring a well-mixed air-fuel combination before it enters the combustion chamber. This system enhances engine efficiency, power, and economy while reducing poisonous emissions. To maintain the fuel injection system, it is essential to keep the injectors clean and prevent clogging. Here are some detailed instructions to help you achieve this:
Use Top-Tier Gasoline:
Opt for gasoline brands that are rated as Top Tier. These fuels contain higher levels of detergents, which are crucial for keeping your injectors clean. Top Tier gasoline has two to three times more detergent than federally required, ensuring your injectors remain in good condition.
Add Fuel-Injector Cleaner:
If you don't always use Top-Tier gasoline, consider adding a fuel-injector cleaning additive to your tank. These additives are available for around $5 to $15 per bottle. Pour the cleaner into your tank before filling it with gasoline, allowing the two to mix thoroughly. However, be sure to read the instructions, as usage recommendations may vary among products. Additionally, some manufacturers advise against using any gasoline additives, so refer to your owner's manual for specific guidance.
Clean the Injectors:
Regularly clean the fuel injectors to prevent clogging and maintain optimal engine performance. You can do this by using a suitable cleaner compatible with your vehicle. Pour the cleaner into the engine's fuel-injector rail, shut off the fuel pump, and run the engine for several minutes to force the cleaner through the injectors. You can also consult a mechanic, who may use pressurized cleaning methods or remove the injectors for more effective cleaning.
Maintain the Fuel Filter:
Clogged injectors often result from dirty air and gummed-up fuel filters. Therefore, it is essential to regularly check and maintain the fuel filter's condition. A well-maintained fuel filter will help prevent the injectors from becoming clogged and ensure a steady flow of clean fuel to the engine.
Consider the Vehicle Type and Fuel Type:
The frequency of cleaning and maintenance may vary depending on the type of vehicle and the fuel type used. For example, high-performance vehicles using ethanol-based fuel may require more frequent injector servicing due to the risk of clogging and corrosion. As a general guideline, aim to clean the fuel injectors once every few months to prevent build-up.
By following these steps, you can effectively maintain your car's fuel injection system, ensuring optimal engine performance, fuel efficiency, and longevity.
Why Won't My Car Start? Low Fuel Issues
You may want to see also
Frequently asked questions
A fuel injection system is a mechanism that introduces fuel into an internal combustion engine. It is more controllable than an old-fashioned carburettor, making modern engines more efficient, clean, economical, and powerful.
Fuel injection systems work by injecting a precisely calibrated fuel spray into or close to the engine's combustion chambers, exactly when it's needed. The amount of fuel supplied to the engine is determined by the amount of time the fuel injector stays open, which is called the pulse width.
There are two main functional principles of mixture formation systems for internal combustion engines: internal and external. External mixture formation systems are called manifold injection systems, which can be multi-point or single-point. Internal mixture formation systems can be direct or indirect injection, with common-rail injection being the most common variety.
Fuel injection systems are more reliable, effective, and eco-friendly than carburettors. They are more controllable, help save fuel, provide more power at lower engine speeds, and increase overall stability. They also help meet stricter emissions requirements.
