Troubleshooting A Faulty Fuel Pressure Gauge: No Reading

A fuel pressure gauge reading can be affected by a number of factors. The most common reason for a faulty fuel gauge is a bad fuel level sending unit. This can cause the gauge to read incorrectly, such as showing a full tank when the tank is empty, or vice versa. Other potential issues include faulty wirings between the gauge and fuel sender, a blown fuse to the fuel gauge, or a faulty fuel gauge itself.

Sender failure

One of the most common reasons for a fuel pressure gauge to have no reading is a defective sender unit. The sender unit is responsible for relaying the amount of fuel in the tank to the gauge. When the sender unit is defective, the gauge may behave erratically, get stuck on empty, or remain on full.

The sender unit is located inside the fuel tank and is made up of a float, a metal rod/arm, and a variable resistor. The float, made of buoyant composite or foam, sits on top of the fuel in the tank. The float is connected to the variable resistor by a thin metal rod/arm. As the float moves up and down according to the fuel level, the metal rod pivots, causing the wiper inside the variable resistor to move. This movement changes the strength of the electric current sent to the fuel gauge, resulting in the displayed fuel level.

Over time, constant use can cause wear and tear on the sender unit, leading to faulty readings. One common issue is the float separating from the arm, causing the gauge to get stuck on empty. Corrosion or damage to the wires can also lead to voltage issues and inaccurate readings. Additionally, a faulty resistor can send the wrong signal to the cluster, resulting in the gauge getting stuck on full or empty.

To diagnose a faulty sender unit, you can perform a few tests. First, check the fuses and replace any blown fuses. Then, consult your vehicle's service manual to perform a self-test on the instrument cluster. If the fuel gauge doesn't move during the self-test, there is likely an issue with the sender unit. You can also use a multimeter to test the voltage and resistance at the sender unit and compare it with the values in the service manual. If the readings are incorrect, the sender unit may need to be replaced.

Circuit issues

There are several potential issues with the circuit that could cause a fuel pressure gauge malfunction. These include:

• Voltage problems in the fuel sender, resulting in the gauge receiving no voltage response.
• Interruption in the ground for either the gauge or the fuel sender.
• Corrosion or loose connections at the fuel pump module, which is often exposed to the elements.
• Corroded wires, especially in the case of a fuel sending unit located on the fuel pump.
• A blown fuse to the fuel gauge.

To diagnose circuit issues, you can perform the following tests:

• Instrument cluster self-test: Refer to your owner's manual to determine the correct procedure, as it varies by vehicle make and model. This test will check the digital lights and readouts and swipe the gauges through their ranges.
• Fuel sender test: Ensure the tank is lower than half to prevent fuel splashing. Check for voltage on the pins, which should be 5V or 12V on one pin.
• Gas gauge test: Repeat the voltage test from the sending unit. The voltage must be the same as in the fuel sender test.

Gas gauge failure

A fuel gauge is an essential component of a vehicle, indicating the amount of fuel in the tank and warning the driver when it's time to refuel. However, fuel gauge failure can occur and result in inaccurate readings or a complete lack of reading. Here are some detailed reasons for gas gauge failure:

Sending Unit Failure

The sending unit is the most common source of fuel gauge issues. It comprises a float attached to a metal rod or arm, which is connected to a variable resistor. As the float moves up and down according to the fuel level, the metal rod pivots, causing a wiper inside the variable resistor to slide along a strip of resistive material. This wiper sends an electric current to the fuel gauge, which then displays the fuel level. Constant friction between the sending unit components can cause wear and tear, leading to their failure. Additionally, the float may separate from the arm, causing the fuel gauge to get stuck on empty.

Circuit Problems

The circuit is responsible for connecting the car battery, sending unit, gauge, and ground. Issues with the circuit can lead to voltage problems in the fuel sender, resulting in no voltage response to the gauge. Corroded or loose connections, especially at the fuel pump module, can interrupt the ground for either the gauge or the fuel sender.

Although less common, the gas gauge itself may experience failure due to a defective internal circuit. This can cause the gauge to get stuck at the full or empty mark, or fluctuate between the two. A faulty gas gauge can lead to erratic readings, leaving drivers unsure of the actual fuel level.

Instrument Cluster Malfunction

In modern vehicles, the instrument cluster is an integrated piece of equipment. If it fails, the gas gauge may also malfunction. This is one of the most expensive issues to repair, as the entire unit needs to be replaced.

Other Factors

Other factors that can contribute to gas gauge failure include extreme temperatures, which can affect the accuracy of the gauge, and fuel type. For example, the dynamic additions of alcohol in car gasoline fuel can increase the failure rate due to accelerated corrosion.

Instrument cluster failure

A malfunctioning instrument cluster is one of the potential reasons for a fuel pressure gauge to display no reading. This issue is commonly observed in newer cars, where the instrument cluster is an integrated piece of equipment, with all the circuits intertwined. If the instrument cluster fails, other gauges, such as the fuel pressure gauge, may also malfunction.

The instrument cluster problem is usually characterised by erratic behaviour of the gauge needles, which may become stuck, sticky, or jumpy. In some cases, the needle may "peg out" to the fully counter-clockwise or clockwise position, or it may move smoothly but display noticeably higher or lower readings. This issue typically starts with one gauge but eventually affects all the analog gauges.

The root cause of individual gauge problems within the instrument cluster is often traced back to failing gauge motors, specifically stepper motors. These stepper motors exhibit a short service life due to an internal material/design flaw. Over time, as the stepper motors degrade, the circuits may remain open, leading to incorrect voltage feedback and inaccurate gauge readings.

To rectify the issue, replacement of the faulty stepper motors is necessary. However, this process requires specialised skills in electronics de-soldering and soldering, as the motors are soldered directly onto the circuit board. Therefore, it is recommended to seek the services of an experienced technician or a gauge repair specialist to perform the necessary repairs or replacements.

Corrosion

The fuel gauge system consists of three main components: the gauge, the circuit, and the sender. Corrosion can affect the wiring and connections within this system, particularly at the fuel pump module due to its consistent exposure to the elements. Corroded wires can interrupt the voltage supply to the fuel gauge, resulting in a loss of functionality.

In addition to disrupting voltage supply, corrosion can also cause loose connections. Loose connections can lead to inaccurate readings or complete gauge failure. It is important to regularly inspect the wiring and connections for any signs of corrosion. If corrosion is detected, cleaning or replacing the affected parts may be necessary to restore proper functionality.

To prevent corrosion-related issues, it is essential to use the appropriate corrosion-resistant materials for the gauge and its components. Regular maintenance and inspections can also help identify corrosion early on, allowing for timely interventions to mitigate potential issues.
