Wiring two fuel gauges to one tank is a complex process that requires careful consideration of various factors. Some sources suggest that it is possible to wire two fuel gauges to one tank using a DPDT switch, SPDT switch, or a solenoid-operated tank select valve with a double-pole switch. However, it is important to ensure that both gauges are compatible with the sender type and that all cable connections, power, negatives, and sender wires are secure. Additionally, it is crucial to verify each gauge independently to avoid inaccurate readings. In some cases, a dual station sender may be required to achieve correct readings on both gauges. Proper calibration and testing of the sending units are also essential to ensure accurate fuel level measurements.
Explore related products
What You'll Learn
Using a DPDT switch
Wiring two fuel gauges to one tank can be done using a DPDT switch. This method allows you to switch between the two tanks and get accurate fuel level readings. Here is a step-by-step guide on how to wire two fuel gauges to one tank using a DPDT switch:
Firstly, ensure that both fuel gauges are compatible with the sender type and that all cable connections, power, negatives, and sender wires are secure and functional. Verify each gauge independently with the sender to ensure they are working correctly.
Next, you will need to connect the DPDT switch to the fuel sender units. The DPDT switch will have two poles, each with three connections. One side of the switch will act as SPDT. Connect the sender wire from the gauge to the centre connection on the switch. Then, connect a wire from each sending unit to the side connections on the switch. Ensure that only the "hot" wires from the senders are switched, while the grounds remain constant.
Now, you can connect the DPDT switch to the fuel gauges. Since the DPDT switch provides two separate connections for the fuel sender (ground and signal wire), you can expect consistent readings from both senders. Ensure that the ground wire from the DPDT switch is connected to the ground terminal on the fuel gauge.
Finally, test the setup by filling one tank and observing the readings on the gauges. Flip the DPDT switch to select the corresponding tank and ensure that the gauge accurately reflects the fuel level.
It is important to note that you should label the DPDT switch to indicate which tank is being monitored. This will prevent confusion and ensure you are aware of the fuel levels in the correct tank.
By following these steps, you can successfully wire two fuel gauges to one tank using a DPDT switch, allowing you to monitor the fuel levels in two tanks with a single gauge setup.
