Testing a fuel tank selector valve is an important step in ensuring the proper functioning of a vehicle's fuel system. This process involves inspecting the valve, which is responsible for directing fuel flow between the tanks and the engine. By following a series of steps, such as applying voltage to specific terminals and using test equipment like ohmmeters, one can determine whether the valve is functioning correctly. This procedure helps identify issues with the valve, preventing potential problems on the road and ensuring a smooth driving experience.
Testing a Fuel Tank Selector Valve
| Characteristics | Values |
|---|---|
| Selector Valve Appearance | Left side assembled from the tanks, right side assembled to the engine at the bottom with an O-ring in the cup |
| Testing Process | Disconnect the top part of the valve to reveal the diaphragm, which works as an up or down force |
| Locate the two valves under the plate, directing fuel to and from the tanks | |
| Check the position of the containers and the corresponding valve openings | |
| Apply 12V power to specific terminals and connect a self-powered test lamp or ohmmeter to test the front and rear tank circuits | |
| A good switch will indicate a closed or open circuit, depending on the circuit being tested | |
| Check if the source and return valves can transfer between front and rear positions by listening for a zip sound | |
| Troubleshooting | Check for power to the selector valve, blown fuses, and proper wiring |
| Verify fuel lines and connections, ensure no damage to the reservoir | |
| Replacement Cost | $160.00 to $200.00 on eBay |
Explore related products
What You'll Learn
Understand the function and structure of the fuel tank selector valve
The function of a fuel tank selector valve is to allow the pilot or driver to choose which tank is feeding fuel to the engine. Selector valves can also be used to shut off the fuel flow, for crossfeed, and for fuel transfer. In aircraft, the fuel system delivers a steady flow of fuel from the tanks to the engine, and this can be done either through gravity or the use of fuel pumps.
In aircraft, the fuel tank selector valve is usually located near the filler neck and cap, which are found in a recessed well to prevent overflowing fuel from entering the wing or fuselage structure. The location of the valve can vary depending on the make and model of the aircraft or vehicle. For example, in some Ford trucks, the valve is located under the driver's seat, while in others, it is found below the driver's feet.
The structure of a fuel tank selector valve can vary depending on the type of installation and the number of tanks present. A single-engine aircraft with two fuel tanks and a reserve fuel supply, for instance, would require a valve with four ports: three inlets from the tanks and one common outlet. The valve must be able to handle the full flow capacity of the fuel line, be leak-proof, and operate freely with a definite "feel" or "click" when in the correct position.
There are three main types of selector valves: poppet, cone, and disk. The cone-type selector valve has a metal or cork-faced aluminium housing, with a cone that fits inside and rotates via a cockpit control. The disk-type selector valve has a rotor that fits into a cylindrical hole in the valve body, with one open port and several sealing disks. To select a tank, the rotor or cone is rotated until the open port aligns with the desired port, allowing fuel to flow from the selected tank through the engine feed port.
It is important to regularly inspect fuel selector valves for any damage, cracks, or corrosion, especially in aircraft where safety is paramount. Overhaul and repair of these valves should be done by qualified professionals to ensure the continued safe operation of the aircraft or vehicle.
Flushing Out Fuel Tanks: A Step-by-Step Guide
You may want to see also
Explore related products
Check the front tank circuit
To test the front tank circuit, follow these steps:
Firstly, briefly apply 12V power to the terminals 786 (R) (+) and 789 (BR/W) (-). Then, connect a self-powered test lamp or ohmmeter to the terminals 29 (Y/W) and 675 (Y/LB). If the switch is good, this action will indicate an open circuit.
Next, connect the self-powered test lamp or ohmmeter to the terminals 29 (Y/W) and 673 (DB/Y). A good switch will indicate a closed circuit.
Finally, check that the source and return valve can transfer between the front and rear positions. You should be able to hear a zip sound when this transfer is happening.
The Weight of a Full Tank: How Much?
You may want to see also
Explore related products
Check the rear tank circuit
To test the rear tank circuit of a fuel tank selector valve, follow these steps:
Firstly, briefly apply 12V power to terminals 789 (BR/W) (+) and 786 (R) (-). Then, connect a self-powered test lamp or ohmmeter to terminals 29 (Y/W) and 675 (Y/LB). If the switch is good, this action will indicate a closed circuit.
Next, connect the self-powered test lamp or ohmmeter to terminals 29 (Y/W) and 673 (DB/Y). A good switch will indicate an open circuit.
Finally, check that the source and return valves can transfer between the front and rear positions. You should hear a zip sound when the valves transfer.
It is important to understand the components of your vehicle and how to test them before driving. This will help prevent breakdowns and other issues on the road.
Effective Use of Liqui Moly Diesel Purge
You may want to see also
Explore related products
Test the valve's ability to transfer between front and rear positions
To test the valve's ability to transfer between front and rear positions, you should first check if the source and return valve can transfer between the front and rear positions.
You can test the rear tank circuit by briefly applying 12V power to terminals 789 (BR/W) (+) and 786 (R) (-). Then, connect a self-powered test lamp or ohmmeter to terminals 29 (Y/W) and 675 (Y/LB). A good switch will indicate a closed circuit. Next, connect the self-powered test lamp or ohmmeter to terminals 29 (Y/W) and 673 (DB/Y). A good switch will indicate an open circuit.
To test the front tank circuit, briefly apply 12V power to terminals 786 (R) (+) and 789 (BR/W) (-). Then, connect the self-powered test lamp or ohmmeter to terminals 29 (Y/W) and 675 (Y/LB). A good switch will indicate an open circuit. Finally, connect the self-powered test lamp or ohmmeter to terminals 29 (Y/W) and 673 (DB/Y). A good switch will indicate a closed circuit.
You may also be able to hear a "zip" sound when the valve transfers between the front and rear positions.
Repairing a Leaking Aluminum Fuel Tank: A Step-by-Step Guide
You may want to see also
Explore related products
Inspect the fuel lines and fittings
Inspecting the fuel lines and fittings is an important step in testing a fuel tank selector valve. This process can help identify any issues with the fuel delivery system and ensure that the valve is functioning correctly. Here is a step-by-step guide to inspecting the fuel lines and fittings:
Firstly, it is crucial to understand the basic components of the fuel tank selector switch. The left side of the switch is connected to the tanks, while the right side is assembled to the engine at the bottom. The bottom of the switch resembles an O-ring inside a cup. Removing the top part of the switch will reveal a rubber diaphragm, which works as an upforce or downforce on the plate beneath it. Two valves are located under the plate, directing fuel to or from the tanks depending on their position.
Next, it is important to inspect the fuel lines themselves. Begin by locating the fuel lines connected to the selector valve. Ensure that the lines are securely attached and free from any damage, such as cracks, leaks, or blockages. Visually inspect the lines for any signs of deterioration or debris that may obstruct fuel flow. If there are any concerns, it may be necessary to replace the fuel lines to maintain the integrity of the fuel delivery system.
After inspecting the fuel lines, focus on the fittings and connections. Ensure that all fittings are tight and secure, preventing any fuel leaks or vapour escapes. Check for any signs of corrosion or damage on the fittings, as this can lead to fuel leaks and impact the engine's performance. It is also essential to verify that the correct fittings are used, matching the fuel line size and type. Improper fittings can cause leaks, restrict fuel flow, or damage the fuel lines.
Additionally, it is recommended to test the fuel lines for leaks. This can be done by applying pressure to the fuel lines and observing for any drops or signs of leakage. A leak can indicate a faulty fuel line, faulty fittings, or an issue with the selector valve itself. If a leak is detected, it is important to address the issue promptly to prevent fuel loss and potential safety hazards.
Finally, it is crucial to test the fuel flow through the lines. This can be done by jumping the fuel pump test relay port, as described in the testing procedures. By performing this test, you can ensure that fuel is flowing through the lines correctly and that the selector valve is functioning as intended. A steady stream of fuel during this test indicates proper fuel line and valve operation.
By following these steps, you can thoroughly inspect the fuel lines and fittings during the testing process of a fuel tank selector valve. This inspection helps ensure the proper functioning of the fuel delivery system, maintaining the vehicle's performance and safety.
Removing Water from Fuel Tank: Quick and Easy Guide
You may want to see also
Frequently asked questions
There are a few ways to test your fuel tank selector valve. One way is to jump the fuel pump test relay port at the diagnostic link and see if you have 5-6 oz. of fuel for a 5-second test with the key in the run position. Another way is to pull the fuel line off going into the valve from the front tank and jump the fuel pump, then do the same with the rear tank. If you get fuel from one tank but not the other, it is likely that the valve is bad.
If your fuel tank selector valve is faulty, your truck may not start even when switching between the front and rear tanks. You may also notice that your fuel pressure is low or that there is no fuel flow to the high-pressure pump.
If your fuel tank selector valve is stuck, you can try replacing the front or rear fuel pump to see if that resolves the issue. If not, you may need to replace the selector valve itself. It is also recommended to check for any leaks, as an internal leak in the selector valve can cause issues with fuel pressure.
