If you're experiencing jolts while accelerating your 1989 Ford Escort, or if your engine won't start, a fuel pump replacement may be necessary. The fuel pump is located inside the fuel tank, which must be removed to access the pump. You can refer to online repair manuals for a detailed step-by-step guide on the replacement process, which includes removing the rear seat, taking out the screws holding the metal cover, and using a brass punch and hammer to remove the locking ring.
Explore related products
$45.34 $50.77
What You'll Learn
Removing the fuel tank
To remove the fuel tank from a 1989 Ford Escort, you will first need to remove the rear seat. Once the rear seat is removed, you will see four screws holding a metal cover in place. Remove these screws and take off the cover to expose the top of the fuel tank.
The next step is to remove the fuel pump module, which is held in place by a locking ring. Place a brass punch and hammer against the ring and gently tap it counter-clockwise to loosen it. Be careful not to use excessive force, as this may damage the ring, especially if it is rusted. If the ring is damaged during this process, it will need to be replaced with a new one from Ford or an authorised dealer.
Once the locking ring is removed, carefully pull out the fuel pump module. You will then need to remove the small screws from the top of the module to access the fuel pump itself. After removing these screws, you can pull off the top of the basket and gain access to the fuel pump.
At this point, you can proceed to replace the fuel pump and strainers, following the appropriate safety precautions and referring to a repair manual if needed.
Replacing Fuel Injectors in a '94 S10: Step-by-Step Guide
You may want to see also
Explore related products
Knocking the ring on the tank loose
To knock the ring on the tank loose, you will need a brass-only punch and a hammer. Once the fuel tank has been removed, carefully knock the retaining ring in an anti-clockwise direction to disconnect it from its retaining teeth. This will allow you to remove the pump and the sending unit.
It is important to use a brass-only punch to avoid creating sparks, which could be dangerous when working with fuel. When knocking the ring loose, be careful not to damage the float assembly on the fuel gauge sender unit.
Before knocking the ring loose, it is advisable to clean the top of the fuel tank to prevent any foreign particles from entering the tank when the assembly is removed. Additionally, ensure that the fuel level in the tank is as low as possible before removing the tank, as it can be excessively heavy when full.
Corvette Fuel Sensor Replacement: A Step-by-Step Guide
You may want to see also
Explore related products
Pulling out the pump and sending unit
To pull out the pump and sending unit of a 1989 Ford Escort, you must first remove the fuel tank. Once the tank is removed, use a brass-only punch and a hammer to knock the ring on the tank loose by hitting it counter-clockwise. Then, simply pull out the pump and sending unit.
It is important to note that only brass tools should be used in this process to avoid creating sparks, which could be dangerous when working with fuel.
For more detailed instructions, you can refer to the free online repair manual available at autozone.com. The website provides a full guide with everything you need to know about replacing the fuel pump and sending unit in your 1989 Ford Escort.
Replacing Fuel Injectors in Nissan Frontier: Step-by-Step Guide
You may want to see also
Explore related products
Removing the rear seat
To remove the rear seat of a 1993 Ford Escort, first, check to see if there are two bolts between the bottom front of the seat and the floor—one on each side. If there are, remove them, then lift the front part of the seat straight up and pull forward.
If your 1989 Ford Escort has a similar interior to the 1993 model, this is the first step to removing the rear seat. However, if your model does not have the two bolts, it is a different method.
Get in the back seat with your back against the front seat. Push backward and downward at the same time against the front edge of the rear seat (about where the passenger sits) until you feel it release, then lift straight up. Then, go to the other side and repeat the procedure. Note that it takes a bit of strength to push the seat out of its retainer.
What is happening here, to give you an idea of how it works: there is a fixed retainer on the floor on both sides. There is a notch in the retainer, so you have to push down to release it from the notch (catch). Once you have pushed it down out of its notch, you then must push backward so it slides along the retainer until it is free from it. It's only a couple of inches and it releases. Follow these steps, one side at a time, and your seat will come right out.
Best Marine Fuel Lines: Which Brand Replaces Better?
You may want to see also
Explore related products
Removing the screws holding the metal cover
To remove the screws holding the metal cover, you will first need to remove the rear seat of your 1989 Ford Escort. Once the rear seat has been removed, you will be able to access the four screws that are holding the metal cover in place. Using the appropriate screwdriver, carefully remove these screws, taking care not to strip the heads or damage the surrounding area. It is recommended to use a screwdriver that fits securely into the screw head to avoid slippage and potential damage to the surrounding trim or bodywork.
Once all four screws have been removed, you can gently lift the metal cover to access the top of the fuel tank and the pump module. Be cautious when removing the cover, as there may be wiring or other components attached that need to be carefully disconnected or moved out of the way. Ensure you have unlatched or loosened any clips or fasteners holding the cover in place before attempting to lift it off.
At this point, you should be able to see the locking ring that secures the pump module in place. This ring can be removed using a brass punch and a hammer, gently tapping it counter-clockwise to loosen and remove it. If the ring is rusted, take extra care during this process as it may be more fragile and prone to breaking. A broken or damaged locking ring will need to be replaced with a new one from Ford or an authorised dealer.
With the locking ring removed, you can now access the fuel pump module for replacement. Remember to handle the module carefully and avoid any sharp edges that could cause injury. Refer to a repair manual or a trusted mechanic if you are unsure about any steps or procedures during this process.
Replacing the Fuel Lever Sensor in Your 2004 Chevy Malibu
You may want to see also
Frequently asked questions
The fuel pump in a Ford Escort is located inside the fuel tank. To replace it, you will need to remove the rear seat, take out the screws holding the metal cover, and remove the fuel tank. Once the tank is out, use a brass punch and a hammer to knock the ring on the tank loose in a counter-clockwise direction. Pull out the old pump and install the new one.
A faulty fuel pump can cause jolts when accelerating, a drop in performance and fuel economy, flooding of the engine with fuel, and failure of the engine to start.
Yes, it is important to ensure that you are working in a well-ventilated area as fuel vapors can be dangerous. Also, since you will be working with fuel, avoid any open flames or sparks that could cause an explosion.
Yes, it is recommended to replace the fuel pump strainers when installing a new fuel pump. Additionally, if the locking ring is rusted, it may get damaged during removal and will need to be replaced with a new one from Ford.
