Replacing Husqvarna 455 Rancher Fuel Line: Step-By-Step Guide

If you need to replace the fuel line on your Husqvarna 455 Rancher, you're not alone. Many people have sought advice on how to do this, and there are some tips and tricks out there to help you get the job done. It can be a bit confusing with the three lines, but there are videos and diagrams available online that explain the process well. You'll need to know which line goes where, and some people have found that feeding the line through from the carburettor end is easier. It's also recommended to use a sharp tool to make a long taper on the hose so you can use it as a needle to get it through the tank wall.

Removing the fuel line from the tank

To remove the fuel line from the tank of your Husqvarna 455 Rancher, you will first need to remove the strainer from the suction hose. The hoses are held in place by the size of the hose against the tank bushings, so there is no additional fastening.

To release the hose, use a sharp tool to create a long taper at the end of the hose. This will allow you to use the hose as a needle to guide it through the tank wall. Then, use a pair of needle-nose pliers or forceps to gently pull the hose through.

Alternatively, you can try the following method:

> I ran a string through my old one before I pulled it out to have the routing then fed the new line in far enough to grab it and remove the string, then install a new filter. This was on an old 61 Rancher. I prefer to run it in to the tank from the carb end and then pull it through, it's much easier that way. I stick a thin wire from the top into the tank. Fish the end out through the cap, and push it through the end of the fuel line. Bend the wire, pull it carefully so it's started through the hole, grab it with pliers, PROFIT.

Routing the fuel line from the tank

To route the fuel line from the tank of your Husqvarna 455 Rancher, start by removing the strainer off the suction hose. The hoses are held in place by the size of the hose against the tank bushings, so there is nothing else holding them in place.

To install the new line, use a sharp tool to create a long taper on the hose. This will allow you to use the hose like a needle to get it through the tank wall. Then, use needle-nose pliers or forceps to pull the hose through.

One user recommends running the line in from the carb end and pulling it through, as it is much easier this way. They suggest sticking a thin wire from the top into the tank, fishing the wire out through the cap, and pushing it through the end of the fuel line. Then, bend the wire, carefully pull it through, grab it with pliers, and pull it through.

Attaching the fuel line to the fitting

To attach the fuel line to the fitting of your Husqvarna 455 Rancher, you will need to first ensure you have the correct fuel line and filter.

Begin by removing the old fuel line. You will need to remove the strainer from the suction hose. The hoses are held in place by the size of the hose against the tank bushings, so there is no additional fastening. Once the old line is removed, you can prepare the new fuel line by making a long taper on the end of the hose with a sharp tool. This will allow you to guide the new hose through the tank wall with ease. Use a thin wire to guide the hose through, feeding it from the top of the tank and out through the cap. You can then pull the wire carefully through, grabbing the end with pliers and pulling it through.

Once the new fuel line is in place, you can attach the fuel filter.

Using a sharp tool to make a long taper on the hose

To replace the fuel line on a Husqvarna 455 Rancher, you will need to know the correct routing of the fuel line from the gas tank to the carburettor. The correct routing is from the carb end into the tank, then pull it through.

Now, to make a long taper on the hose using a sharp tool, you can follow these steps:

Firstly, you will need to ensure you have the correct size of the fuel line for your Husqvarna 455 Rancher. The diameter of the fuel line is important to ensure a snug fit. You can purchase a fuel line kit that includes multiple sizes, or you can measure the old fuel line and source a replacement of the same dimensions.

Once you have the correct size of the fuel line, you can begin creating the taper. Using a sharp tool, such as a knife or a pair of scissors, start by cutting the fuel line at a slight angle. This will create the initial taper. It is important to cut the fuel line slowly and carefully to avoid any mistakes.

Next, you will need to create a long, smooth taper. To do this, continue cutting the fuel line at a slight angle, gradually increasing the angle as you cut. This will create a taper that is wider at one end than the other. Take your time and cut the fuel line in small increments to ensure a straight and even taper.

After you have created the taper, you can finish the fuel line by smoothing out any rough edges. You can use sandpaper or a file to carefully remove any burrs or sharp edges.

Finally, test the fuel line to ensure it fits correctly. It should fit snugly into the grommets and onto the barbs without being too tight or too loose. If the fit is not correct, you may need to adjust the taper by cutting it again or using a different size of the fuel line.

Creating a long taper on the hose using a sharp tool requires precision and patience. Take your time and work slowly to ensure an accurate and safe fuel line for your Husqvarna 455 Rancher.

Using a string or wire to guide the new line through

To replace the fuel line on a Husqvarna 455 Rancher, you can use a string or wire to guide the new line through. Here's a step-by-step guide:

Step 1: Prepare the String or Wire

Before removing the old fuel line, feed a string or thin wire through it. This will help guide the new fuel line into place. Make sure the string or wire is long enough to reach from one end of the fuel line to the other, with some extra length for ease of handling.

Step 2: Remove the Old Fuel Line

Disconnect the old fuel line from the fuel tank and carburetor. Pull out the old fuel line, using the string or wire to guide it through the routing. Be careful not to damage any surrounding components. Once removed, take note of the routing path for the new fuel line.

Step 3: Feed the New Fuel Line

Attach the new fuel line to the string or wire. Start feeding the new fuel line from the carburetor end, pulling the string or wire through until you can access it from the fuel tank end. This will ensure that the new fuel line follows the correct path.

Step 4: Secure the New Fuel Line

Once the new fuel line is in place, carefully detach the string or wire. Secure the new fuel line at both ends, connecting it to the fuel tank and carburetor according to the manufacturer's instructions. Ensure all connections are tight to prevent leaks.

Step 5: Final Checks

Before starting the chainsaw, perform a final inspection to ensure the new fuel line is securely connected and routed correctly. Check for any signs of damage or leaks. Refer to the Husqvarna 455 Rancher manual for specific safety warnings and guidelines.

Using a string or wire to guide the new fuel line simplifies the replacement process and helps ensure the correct routing. Always exercise caution when performing maintenance on power equipment, and refer to the manufacturer's instructions for the Husqvarna 455 Rancher for more detailed guidance on fuel line replacement.
