Replacing Fuel Injectors In A '84 Mercury Cougar 6-Cylinder

Fuel injectors are fuel metering devices that spray atomized fuel droplets into the engine's intake manifold or combustion chamber. They are usually connected to a fuel rail on top of the engine, which is supplied with fuel from the fuel pump in the fuel tank. Over time, fuel injectors can become clogged or fail, leading to reduced engine power and misfires. While it is possible to replace fuel injectors yourself, it is not recommended due to the risk of fire and the complexity of the process. The average cost of replacing fuel injectors in a 1984 Mercury Cougar 6-cylinder ranges from $1841.04 to $2812.49, with parts costing between $470 and $6010.81 and labor between $95 and $1993.11. The process involves relieving the pressure in the fuel rail, removing the upper plenum and any components restricting access, disconnecting the supply and return lines, and carefully removing and replacing the fuel injector.

Disconnect the fuel rail and remove the upper intake manifold

Disconnecting the fuel rail and removing the upper intake manifold on your 1984 Mercury Cougar 6 cylinder is a complex process and should only be performed by a professional. However, if you wish to do it yourself, here is a detailed guide:

Firstly, relieve the pressure within the fuel rail by briefly running the engine with the fuel pump fuse removed. This will ensure that the fuel tank is not under pressure, reducing the risk of fuel leaks and potential fire hazards. Make sure you are working in a well-ventilated area and disconnect the battery to prevent any accidental sparks.

Next, remove the upper plenum on the intake manifold, along with any cables, hoses, or wiring that may restrict access to the fuel rail and injectors. Be sure to label or make note of where each part is connected to make reassembly easier.

Now, you can remove the supply and return lines from the fuel rail. You will also need to disconnect the electrical connectors to each fuel injector. These electrical connectors should be unlocked and carefully set aside.

At this point, you can unbolt and remove the fuel rail from the intake manifold. This will expose the fuel injectors. Be careful not to let any debris enter the exposed openings as this could cause issues when reassembling.

To remove the upper intake manifold, you will need to refer to a repair manual specific to your vehicle. The process will likely involve draining the coolant and oil, removing various engine components, and replacing the intake manifold gasket. It is crucial to keep track of all the bolts and hardware removed during this process to ensure proper reassembly.

Once the upper intake manifold is removed, you will have access to the fuel injectors for replacement. Remember to use high-quality, OEM parts for the best results and even power distribution across the engine.

Finally, reverse the disassembly process to reinstall the new fuel injectors, fuel rail, and upper intake manifold. Reattach all cables, hoses, and wiring. Before starting the engine, ensure that all connections are secure and there are no fuel leaks.

Remove the fuel injectors from the fuel rail

To remove the fuel injectors from the fuel rail of your 1984 Mercury Cougar 6-cylinder, you'll need to follow these steps:

Begin by relieving the pressure within the fuel rail. Do this by briefly running the engine with the fuel pump fuse removed. This will release any built-up pressure, ensuring a safer working environment.

Next, remove the upper plenum on the intake manifold, along with any cables, hoses, or wiring that may restrict access to the fuel rail and injectors. It's important to have unobstructed access to the area.

Once you have clear access, disconnect the supply and return lines from the fuel rail. You can do this by using a quick-disconnect tool or by relieving the fuel pressure through the Schrader valve. If you choose the latter method, be cautious as fuel may spray when the pressure is released.

Now, you can proceed to unbolt the fuel rail and remove it from the intake manifold. With the fuel rail removed, pay close attention to the exposed openings as you carefully take out the fuel injectors. Typically, an O-ring seal holds each injector firmly in place within the fuel rail.

At this point, you can choose to service the existing injectors or replace them with new ones. If you're reusing the old injectors, ensure they are thoroughly cleaned and tested before reinstallation.

If you're installing new or serviced injectors, apply engine oil to a new O-ring and carefully insert the injector into the fuel rail. Ensure the O-ring is not damaged during this process, as these seals are designed to fit very tightly to prevent fuel leaks.

Now, you can reinstall the fuel rail, reconnect the supply and return lines, and reattach the plenum, cables, hoses, and wiring.

Finally, start the engine and carefully check for any leaks. Once you've confirmed that there are no leaks, take the car for a road test to ensure everything is functioning correctly.

Remember, working with fuel can be dangerous, so always disconnect the battery and take the necessary precautions to prevent fires.

Install the new fuel injectors

To install the new fuel injectors, follow these steps:

First, relieve the pressure within the fuel rail by briefly running the engine with the fuel pump fuse removed. Then, remove the upper plenum on the intake manifold, along with any cables, hoses, or wiring that may restrict access. Disconnect the supply and return lines from the fuel rail, and unlock and remove the electrical connectors to each fuel injector.

Next, unbolt and remove the fuel rail from the intake manifold. Take out the old injector(s) requiring replacement from the fuel rail, being careful not to let any debris enter the exposed openings. The injector is usually held very firmly in place by an O-ring seal.

Now, insert the new injector(s) into the fuel rail, using a new O-ring and engine oil on the O-ring to prevent damage. Ensure that the O-ring is fitted very tightly to prevent fuel leaks. Reinstall the fuel rail, reconnect the supply and return lines, and remount the plenum along with all cables, hoses, or wiring.

Finally, run the engine, carefully checking for leaks, and perform a road test.

Re-attach the fuel rail and intake manifold

To re-attach the fuel rail and intake manifold, follow these steps:

First, re-attach the fuel rail by reconnecting the supply and return lines to the fuel rail. Ensure that the O-ring seals are properly seated and intact. Tighten any bolts or fittings securely, but be careful not to over-tighten and damage the seals or threads.

Next, re-install the upper plenum on the intake manifold, along with any cables, hoses, or wiring that were previously removed to access the fuel injectors. Ensure that all connections are secure and that nothing is pinching or restricting any hoses, cables, or wiring.

Once everything is re-attached and secure, briefly run the engine to check for any leaks. Observe the fuel injectors, fuel rail, and all connections for any signs of fuel leaks. Also, listen for any unusual sounds that could indicate a leak or improper installation.

If no leaks are detected, proceed to road test the vehicle. During the road test, pay close attention to the engine's performance and any unusual sounds or behaviours. Make sure to vary the driving conditions, including speed, load, and terrain, to adequately test the engine and fuel system.

After the road test, perform a final inspection of the fuel system, including the fuel injectors, fuel rail, and intake manifold. Ensure that all components are secure and that there are no signs of leaks or damage.

By following these steps, you can confidently re-attach the fuel rail and intake manifold, ensuring a safe and proper installation.

Test the vehicle

Once you have replaced the fuel injectors in your 1984 Mercury Cougar, you will need to test the vehicle to ensure that the new fuel injectors are working correctly. Here are some detailed instructions on how to do this:

Listen to the Fuel Injectors

With the vehicle running, locate the fuel injectors. Place the tip of a long screwdriver on top of each fuel injector and place your ear on the handle of the screwdriver. You should hear a regular clicking sound as the injector cycles on and off. Compare the sound of each injector and note any differences. If one of the injectors sounds different, it may be dirty or malfunctioning.

Take a Resistance Reading

Turn off the vehicle and disconnect the electrical connector for the fuel injector. Use a multimeter to take a resistance reading. Check your vehicle's service manual or look online to find the correct resistance value (most fuel injectors should read between 10 and 18 ohms). Reconnect the injector and repeat this process for each injector. All readings should be within the range specified by the manufacturer and should be consistent across all injectors. If any resistance readings are off, the injector may need to be repaired or replaced.

Check for External Leaks

Before starting the vehicle, check for any external leaks around the fuel injectors. Fuel injectors should not leak fuel into the intake manifold when the car is off. If you notice any fuel odour or visible signs of leakage, do not start the vehicle as this could pose a fire hazard.

Road Test the Vehicle

If the injectors are functioning correctly and there are no signs of leakage, start the engine and carefully check for any internal leaks. Then, take the vehicle for a road test. Pay attention to how the vehicle performs, including engine idle, power, and fuel efficiency. If the fuel injectors have been installed correctly, you should notice improved performance and fuel economy.

Check Engine Light

After the road test, turn off the vehicle and check the dashboard for any warning lights. If the fuel injectors or any other components of the fuel injection system are malfunctioning, this may cause a trouble code to be set in the PCM (powertrain control module), which will illuminate the check engine light. If the check engine light comes on, you will need to have the vehicle diagnosed by a mechanic to identify the specific issue.
