Removing the fuel tank from a 2010 Streetglide motorcycle involves several steps and requires caution. Firstly, it is recommended to have minimal fuel in the tank to reduce weight and avoid spillage. The fuel pump fuse can be removed, and the bike idled until it stalls, to release pressure from the fuel line. Next, the seat should be removed, followed by unscrewing bolts at the rear and front of the tank. After detaching the quick connect from the fuel line, the tank can be carefully lifted off. It is important to be cautious when handling the fuel line and to avoid turning on the power beforehand to prevent pressure buildup. Additionally, enlisting help to support the tank's weight can make the process safer and more manageable.
Explore related products
What You'll Learn
Disconnect the fuel pump power lead and turn the bike over to release pressure
Disconnecting the fuel pump power lead and turning the bike over to release pressure is an important step when removing the fuel tank of a 2010 Street Glide. This step is necessary to avoid the fuel line being under pressure, which can be dangerous.
To begin, locate the fuel pump wiring, which is usually found at the top of the tank by the filler. Disconnect the fuel pump power lead by simply unplugging it. This will cut off the power supply to the fuel pump, preventing it from running and building up pressure.
Next, turn the bike over several times. This action will help release any remaining pressure in the fuel system and ensure that there is no fuel or pressure before proceeding with the next steps. It is important to perform this step carefully and avoid turning on the power before removing the tank to prevent any potential hazards.
Additionally, it is recommended to drain the fuel tank before removal. While some individuals choose to lift the tank off with fuel still in it, draining the tank reduces the weight and makes the process safer and more manageable. To drain the tank, use a manual siphon pump or a similar tool to remove most of the fuel without damaging any internal components.
By following these steps, you can safely disconnect the fuel pump power lead and release pressure from the fuel system of your 2010 Street Glide. Remember to refer to the service manual or seek guidance from Harley-Davidson experts if you have any questions or concerns during the process.
Easy Guide: Installing Huskava Fuel Tank Grommet Kit
You may want to see also
Explore related products
Remove the bolts at the rear of the tank and the front bolts
Removing the fuel tank from a 2010 Streetglide requires some care and attention, but it is not an overly complex task. Before beginning, it is important to relieve the pressure in the fuel line. This can be done by removing the fuel pump fuse and letting the bike idle until it stalls, then pressing the start button and holding it for three seconds. Alternatively, you can disconnect the fuel pump power lead and turn the bike over a few times to relieve the pressure. It is also a good idea to remove as much fuel as possible from the tank to reduce the risk of spillage and to lighten the load.
Now, to the bolts. With the seat removed, you will see two bolts at the rear of the tank, where it meets the seat. These need to be removed. You will also need to remove the bolts at the front of the tank. There are two bolts at the front, usually covered with rubber grommets. These are located on each side of the tank.
Before removing the bolts, it is important to take note of the routing of the rubber fuel line so that it can be correctly reattached later. Once the bolts at the rear and front of the tank have been removed, along with the fuel line disconnected, the tank should lift off easily. Be sure to have something to support the tank as you remove it, to avoid putting the weight on the fuel pipe.
It is also important to note that the fuel line should be handled with care. When removing and reattaching the fuel line, be cautious to avoid damage. The fuel line connects with a quick-connect fitting. Move the collar ring, give it a slight twist and tug, and it should come off easily.
Alcohol in Fuel: Passing Emissions with a Twist
You may want to see also
Explore related products
Disconnect the main fuel line
Disconnecting the main fuel line on a 2010 Streetglide is a relatively straightforward process, but it requires careful attention to safety and detail. Here is a step-by-step guide on how to do it:
First, it is important to reduce the pressure in the fuel line. This can be done by removing the fuel pump fuse and letting the bike idle until it stalls. Then, press the start button and hold it for about three seconds. Alternatively, you can disconnect the fuel pump power lead and turn the bike over several times to release pressure. Ensure you have something to support the tank so that you are not putting the weight on the fuel pipe. It is also advisable to have a rag and safety glasses to prevent any fuel spray when disconnecting the line.
Once the pressure is released, you can proceed to disconnect the fuel line. Start by removing the seat to access the tank. There will be bolts at the rear of the tank where it meets the seat, and also bolts at the front of the tank, usually covered with rubber grommets. Remove these bolts. At the front of the dash, near the fairing, there is an Allen head screw that also needs to be removed.
Now, open the gas door and take off the gas cap. You may want to put the gas cap back on after this step to prevent fuel leakage. Next, you will need to unroute the vent tubes from the clips on the bottom of the dash and remove the vent tubes and fuel pump wiring from the top of the tank by the filler. Be careful when handling the fuel line and putting it back into the petcock to avoid any damage.
Finally, to disconnect the main fuel line, locate the quick-connect fitting on the bottom of the tank. Move the collar ring, give it a slight twist and tug, and the fuel line should come off easily. Be mindful of any rubber lines on the right side and make a note of their routing to prevent incorrect reinstallation, which could cause them to melt on the exhaust.
By carefully following these steps, you can safely and effectively disconnect the main fuel line on your 2010 Streetglide fuel tank.
Purging Your 2003 Malibu Boat Fuel Tank: A Step-by-Step Guide
You may want to see also
Explore related products
Remove the fuel cap and centre bolt
To remove the fuel cap and centre bolt of a 2010 Streetglide fuel tank, start by removing the seat of the bike. Where the tank and seat meet, there is a single bolt for the "Dash"; remove this bolt. At the front of the dash, close to the fairing, you will find an Allen head screw, which you should also remove.
Now, open the gas door and take off the gas cap. The "Dash" should now come up, and you must unroute the vent tubes from the clips on the bottom. Put the gas cap back on, and then remove the vent tubes and the fuel pump wiring from the top of the tank by the filler. Simply unplug the wiring.
At this point, you should detach the quick connect from the fuel line. There are two bolts on the rear of the tank where it meets the seat, and two bolts on the front of the tank, usually covered with rubber grommets. Once these bolts are removed, the tank should lift off easily.
Before removing the tank, it is recommended to get rid of the pressure in the fuel line. You can do this by removing the fuel pump fuse and letting the bike idle until it stalls. Then, press the start button and hold it for about three seconds. Another tip is to ensure there is very little gas in the tank before beginning the process, as it may be heavy with a full 6 gallons of gas.
Guide to Installing an Auxiliary Diesel Fuel Tank
You may want to see also
Explore related products
Lift the tank off
Lifting the tank off is the final step of the fuel tank removal process. Before you get to this stage, there are a few things you should do to prepare. Firstly, it is recommended that you remove the fuel pump fuse and let the bike idle until it stalls. Then, press the start button and hold it for around three seconds. This will help to get rid of any pressure in the fuel line.
Next, take off the seat and remove the bolts at the rear of the tank, where it meets the seat. There are usually two bolts here. You should also remove the bolts at the front of the tank, which are usually covered with rubber grommets. There are two bolts here, one on each side. Once these bolts are removed, you can then lift the tank off.
It is important to note that the fuel tank may be heavy, especially if it is full. Consider draining some fuel or enlisting the help of another person to lift the tank. Make sure you have something to support the tank so that you are not putting the weight on the fuel pipe. You should also put on safety glasses and grab a rag to avoid getting fuel spray when you push up on the quick-connect fuel line.
Finally, before lifting the tank off, remember to put the fuel cap on to avoid losing fuel.
A Guide to Installing a Fuel Tank Vent
You may want to see also
Frequently asked questions
Here is a step-by-step guide to help you remove the fuel tank from your 2010 Streetglide:
- Remove the seat.
- Detach the quick connect from the fuel line.
- Remove the bolts at the rear and front of the tank.
- Lift the tank off.
It is not necessary to drain the fuel tank before removing it, but it might be heavy with 6 gallons of gas in it. You can drain some gas out to lighten it up, but make sure you have something to support the tank so you are not putting the weight on the fuel pipe.
Yes, before removing the fuel tank, you should relieve the pressure in the fuel line. You can do this by removing the fuel pump fuse and letting the bike idle until it stalls, then pressing the start button and holding it for three seconds. You should also put on safety glasses and grab a rag so that fuel does not spray on you when you detach the quick connect from the fuel line.
Move the collar ring and give a slight twist and tug, and it should come off easily.
In addition to removing the seat, you may need to remove the dash piece, the fuel pump, and the sending unit assembly. You will also need to remove the gas cap and disconnect the fuel pump wiring from the top of the tank by the filler.
