Replacing The Fuel Pump In Your 1997 Infiniti Qx4

If you need to replace the fuel pump in your 1997 Infiniti QX4, you'll first need to relieve the fuel pressure. You can do this by removing the 15-amp fuse located on the interior fuse panel, which is on the bottom left side of the steering wheel. Next, start the car and wait for it to die, then crank the engine a few times to release any remaining pressure in the lines. The fuel pump is located in the fuel tank, which can be accessed through an inspection hole underneath the driver's side rear seat. Once you've removed the inspection hole cover, you'll need to disconnect the two electric connections and the fuel hoses from the pump assembly. Be careful, as some fuel may spill during this process. Finally, remove the old fuel pump and install the new one, making sure to line up the hoses and electrical connections correctly.

Remove rear seat cushion to access fuel pump

To access the fuel pump of a 1997 Infiniti QX4, you will need to remove the rear seat cushion. Here is a step-by-step guide on how to do this:

First, locate the rear seat cushion on the driver's side. The fuel pump access port is usually underneath this seat cushion. Move any necessary carpet or objects out of the way, as fuel is likely to spill during this process.

Next, remove the rear seat cushion. This will involve lifting the cushion and locating the bolts or screws that secure it in place. You may need to use a screwdriver or socket wrench to remove these fasteners. Be careful not to lose any small screws during this process. Once the fasteners are removed, carefully lift the seat cushion and set it aside.

With the seat cushion removed, you should now have access to the fuel pump assembly. Before proceeding, it is important to relieve the fuel pressure. This can be done by removing the 15-amp fuse located on the interior fuse panel, which is typically on the bottom left side of the steering wheel. Attempt to start the car and let it die. Repeat this process to ensure the fuel system is depressurized.

Now you can proceed with removing the fuel pump assembly. This will involve disconnecting electrical connections, fuel hoses, and removing screws or bolts securing the assembly in place. Refer to a repair manual or seek guidance from a qualified mechanic if you are unsure about any steps. Always exercise caution when working with fuel systems and electrical components.

Once the fuel pump assembly is removed, you will be able to access and replace the fuel pump as needed. Remember to re-pressurize the fuel system and carefully reinstall the rear seat cushion after completing the necessary repairs.

Disconnect fuel lines and electrical connections

To disconnect the fuel lines and electrical connections of your 1997 Infiniti QX4, follow these steps:

First, relieve the fuel pressure. This can be done by removing the 15-amp fuse located on the interior fuse panel. You can find it on the bottom left side of the steering wheel, behind the coin tray. Start the car and wait for it to die, then crank the engine a few times to release any remaining pressure in the lines.

Next, locate the access hole under the driver's side rear seat, near where the jack and tie rod are stored. Move the carpet out of the way as fuel is likely to spill. Remove the cover by taking out the four bolts with a 10mm socket or a Phillips screwdriver. Push the rubber grommet in the centre of the cover out of the way to better access the electrical connections.

Disconnect the two electrical connections. Gently push in the connector clip with a flat-head screwdriver while gently tugging upwards on the connection until it comes loose. Loosen the hose clamps and remove both hoses from the pump assembly. Take note of which hose goes where.

Finally, disconnect the pump electrical connection. Pay attention to the placement of the connections so you can reconnect them properly when installing the new pump.

Loosen hose clamps and remove hoses from pump assembly

To loosen the hose clamps and remove the hoses from the pump assembly of your 1997 Infiniti QX4, you'll need to follow these steps:

First, make sure you have the necessary tools, such as hose clamp pliers, a flat-head screwdriver, or a socket wrench. These tools will help you loosen the hose clamps.

Locate the hose clamps—they should be on the pump assembly, securing the hoses in place. If you're having trouble finding them, refer to your Infiniti QX4's manual or seek guidance from a mechanic or automotive forum.

Once you've located the hose clamps, use your chosen tool to loosen them. If you're using hose clamp pliers, open the jaws of the pliers and hook the teeth into the slots on the protruding arms of the hose clamps. Then, squeeze the pliers to pinch and loosen the clamps. If you're using a screwdriver or socket wrench, insert the tool into the slot or bolt head of the hose clamp and turn counterclockwise to loosen it.

After loosening the hose clamps, you can proceed to remove the hoses from the pump assembly. Gently pull on the hoses, twisting them back and forth if necessary, to detach them from the assembly. Be careful not to use excessive force, as the hoses may be delicate and prone to tearing.

Once the hoses are removed, set them aside and proceed with the next steps of your fuel pump replacement. Remember to refer to a reliable guide or seek advice from a qualified mechanic if you're unsure about any part of the process.

Remove screws holding down assembly ring

To remove the screws holding down the assembly ring, you will need a Phillips screwdriver. There are six screws in total, and they are very short and easy to lose, so be careful when removing them. Once the screws have been removed, you can lift the assembly out of the tank. It won't come all the way out yet, as you will first need to disconnect the hoses.

Lift assembly out of tank and disconnect hoses

To lift the assembly out of the tank, you will need to be careful as there will be some gas that spills. You will need to disconnect the hoses by pushing in the top tabs with your fingers. Do not be rough and do not use pliers as they can easily break these tabs. Push in with your fingers while pulling downwards and twisting to disconnect the hoses.

Now, carefully lift the assembly out of the tank. It will not come all the way out yet as the hoses are still connected. Be careful not to force anything. Once the assembly is out, you can disconnect the hoses by pushing in the tabs and pulling downwards while twisting.

Now, you can fully remove the assembly from the tank. Pay attention to the hose connections and make notes, if necessary, to ensure that you reconnect them correctly.
