Changing Fuel Filters: Mahindra 2535 Guide

Changing the fuel filters on a Mahindra 2535 tractor can be a challenging task due to limited service access and the potential for fuel spillage. However, with careful preparation and the correct tools, it can be accomplished successfully. The process involves removing the left side engine access panel, loosening bolts, and carefully draining the fuel. It is important to have the correct part numbers, as the operator's manual may provide erroneous information. Additionally, proper safety precautions should be taken to avoid any accidents.

The Mahindra has two fuel filters, a pre-filter and a main filter

To change the filters, start by lifting the hood and removing the left side engine access panel. Loosen the 13mm (1/2") drive bolt in the centre of the top of the pre-filter to remove the filter can. Be cautious as this will drain the fuel in the tank. You can either use a drain pan to collect the fuel or remove and plug the fuel input line from the tank to the filter. Once the filter bowl is off, swap out the paper filter element and reassemble the filter.

Now, for the main filter. Remove the left-side splash guard by unscrewing two 12mm drive bolts. Then, remove the wiring looms by taking out the reusable zip ties. Next, remove the electrical plug on the water sensor at the bottom of the filter. Push the release latch and pull the connector down to disconnect it from the sensor. Leave the water sensor screwed to the bottom of the filter to avoid spilling fuel all over the starter and solenoid. Use a plumbing-type strap wrench to loosen the filter. Work the old filter out of the confined space and dump the fuel into your drain pan. Unscrew the water sensor from the bottom of the filter, being careful not to lose the O-ring seal. Put the new filter in place, ensuring you lube the gasket with some clean fuel first, and snug it down. Screw the water sensor back into the bottom of the filter and reconnect the electrical connector.

Finally, bleed the air out of the new filter and prime the filter with fuel. Open the bleed screw (10mm drive) at the top and rear of the filter adapter. Use paper towels or rags to catch the fuel and push the primer cap down several times until fuel comes out instead of air. Snug down the bleed screw, check for leaks, and try starting the tractor. The engine may start and stop due to trapped air, so you may need to prime it again.

The pre-filter is a paper insert type with a removable bowl

To change the fuel filter on a Mahindra 2535, you'll need to start by relieving the pressure in the fuel system. This can be done by locating and removing the fuse for the fuel pump, then starting the engine and allowing it to run for a minute or two until it dies. Once the pressure is relieved, you can replace the fuse and disconnect the battery.

The next step is to locate the fuel filter. In most modern vehicles, it is located along the fuel line on the bottom of the car, just past the fuel pump. Place a bowl or bucket beneath the fuel filter to catch any fuel that may spill, then remove the clips holding the fuel filter in place. Typically, these are plastic clips that can be removed with a flat-head screwdriver. With the clips removed, carefully slide the fuel lines away from the filter and catch any spilled fuel.

Now, you can remove the old fuel filter. It is likely held in place by a metal bracket that wraps around its outer housing. Simply slide the fuel filter out of the bracket, being careful not to spill any remaining fuel. Before installing the new fuel filter, compare it to the old one to ensure they are the same size and will fit properly.

Slide the new fuel filter into the bracket, ensuring it is seated properly. Then, reconnect the fuel lines to the new filter and secure them with the plastic clips. Finally, lower the vehicle off the jack stands and reconnect the battery.

The pre-filter on a Mahindra 2535 is a paper insert type with a removable bowl. To change it, start by loosening the 13mm bolt in the centre of the top of the filter with a gear or ratchet wrench. Be cautious, as when you loosen this filter, you will drain the fuel in the tank. There is a 10mm filter drain plug at the bottom of the filter, which can be used to slowly drain the fuel into a fuel can. Alternatively, you can remove and plug the fuel input line from the tank to the filter. Once the bowl is off, swap out the paper filter element and reassemble the filter. You should also consider changing the O-ring filter gasket if it looks worn out.

The main filter is different from the pre-filter

The Mahindra 1538 gear tractor has two fuel filters: a pre-filter and a main filter. They are different and require different processes to change them. The pre-filter is a paper insert type with a removable bowl. To remove it, you simply need to loosen the 13mm (1/2") drive bolt in the centre of the top of the filter with a gear or ratchet wrench. This will cause the fuel in the tank to drain, so be prepared.

The main filter, on the other hand, is a spin-on filter. It is located in a tight space, so it is best to remove the left-side splash guard to give you more room to work. You will need to remove the electrical plug on the water sensor at the bottom of the filter and then use a plumbing-type strap wrench to loosen the filter.

The pre-filter is located before the main filter in the fuel system, allowing it to catch large particles before they reach the main filter. The main filter, as its name suggests, is the primary means of filtering the fuel. It is designed to catch smaller particles and requires more frequent changes than the pre-filter.

Loosen the 13mm bolt in the centre of the pre-filter to remove it

To loosen the 13mm bolt in the centre of the pre-filter, you will need to use a gear or ratchet wrench. A socket wrench won't fit due to limited access, and an open-ended or box wrench will take a lot of time.

Loosening this bolt will drain the fuel from the tank, so be prepared for this. The manual does not mention this, but you can either let the fuel drain into a pan or remove and plug the fuel input line from the tank to the filter. If you want to save the fuel, you can slowly drain it into a fuel can using the 10mm filter drain plug at the bottom of the filter.

Once you have loosened the bolt and dealt with the fuel, you can remove the pre-filter.

The main filter is a spin-on filter

At this point, you can leave the water sensor screwed to the bottom of the filter to avoid pouring fuel all over the starter and solenoid. Use a plumbing-type strap wrench to loosen the filter. Work the old filter out of the confined space and then dump the fuel into your drain pan. Now, you can unscrew the water sensor from the bottom of the filter. Be careful not to lose the O-ring seal.

Work the new filter into place and spin it on, making sure to lube the gasket with some clean fuel first. Snug it down—you don't need to overtighten it, as is typical for spin-on filters. Now, screw the water sensor to the bottom of the filter and reconnect the electrical connector. Next, you need to bleed the air out of the new filter and prime the filter with fuel. To do this, first open the bleed screw (it's a 10mm drive). You'll find it on the top and to the rear of the filter adapter. Use a 10mm gear wrench to loosen it—don't remove it, just back it out enough so air can escape.

To prevent pouring fuel all over the starter, stuff some paper towels or rags into the space behind the filter. Now, push the primer cap down several times until fuel instead of air comes out of the bleeder and the primer stiffens up. Snug down the bleed screw. Check for leaks and try starting the tractor. The engine may start and run for a bit and then stop due to trapped air. If this happens, try priming it again. If you trip the Check Engine light, don't worry—keep trying until the tractor starts and runs for a while until the fuel system is fully primed with fuel. After a few starts, the CE light will go out by itself.
