Changing Fuel Filter On Exmark Lazer Z: Step-By-Step Guide

The Exmark Lazer Z is a zero-turn riding lawnmower. The fuel filter's job is to prevent foreign objects such as dirt, debris, and water from entering the combustion chamber. If the filter gets clogged, you will encounter issues with your mower. To change the fuel filter, you will need gloves and pliers. First, park your mower on a flat, level surface, turn off the engine, and allow it to cool. Then, remove the ignition key and disconnect the spark plug ignition wire. Shut off the in-line fuel valve, and use pliers to move both fan clamps off of the fuel filter. Put a rag underneath the filter to soak up any spilled fuel. Twist the clamps to break the fuel lines free. Dispose of the old fuel filter and install a new one, ensuring that the arrow on the side of the new filter, indicating the direction of the flow, is pointing towards the engine. Reinstall the fan clamps around the new fuel filter, turn the fuel valve back on, and start your mower.

Park the mower on a flat surface and disconnect the spark plug ignition wire

To change the fuel filter on your Exmark Lazer Z, it is important to first park your mower on a flat, level surface. This ensures stability and prevents accidental movement during the maintenance process. Once you've found a suitable location, turn off the engine and let it cool down. This step is crucial for safety reasons, as working on a hot engine can lead to severe burns.

After turning off the engine, the next step is to remove the ignition key. This simple action provides an additional layer of safety by preventing accidental starting. With the key removed, you can now safely disconnect the spark plug ignition wire. This step further reduces the risk of unintended ignition, allowing you to work on the mower without worrying about accidental startups.

Before proceeding with any maintenance or repair work, it is always a good idea to engage the parking brake. This adds an extra layer of security, ensuring that the mower remains stationary throughout the process. It is also worth noting that, while not mandatory, wearing gloves during this process is recommended by some experts for added safety and protection.

Now that you have securely parked the mower on a flat surface, turned off and cooled down the engine, removed the ignition key, and disconnected the spark plug ignition wire, you can proceed with the next steps of changing the fuel filter on your Exmark Lazer Z. Remember to refer to your owner's manual for specific maintenance instructions and safety information, as they may vary slightly depending on your lawn mower model.

Shut off the in-line fuel valve

Shutting off the in-line fuel valve is an important first step when changing the fuel filter on an Exmark Lazer Z. This is a safety measure to prevent accidental starting of the mower.

To shut off the in-line fuel valve, simply turn it a quarter turn. The valve is clearly marked, so you just need to line up the arrow on the valve handle with the "OFF" marking on the valve body. This will stop the flow of fuel and allow you to safely work on the fuel system.

It is important to note that shutting off the fuel valve is not enough to ensure safety. You should also take other precautions, such as removing the ignition key and disconnecting the spark plug ignition wire. These steps will help prevent any accidental starting of the engine, which could be dangerous while you are working on the mower.

Additionally, always be cautious when working with gasoline. Make sure there are no open flames or sparks in the area, and ensure the battery is disconnected and the key is removed from the mower. Refer to your owner's manual for further safety instructions specific to your model of Exmark Lazer Z.

Remove fan clamps and fuel lines

To remove the fan clamps and fuel lines, you will need a pair of pliers. It is recommended that you put a rag underneath the filter to soak up any fuel that may spill.

Using the pliers, move both fan clamps off the fuel filter. Once the clamps have been moved out of the way, give them a twist to break the fuel lines free.

You can then properly dispose of your fuel filter. When installing a new fuel filter, look on the side of the filter to see an arrow that says "flow". The flow side should go towards the engine. Reinstall the new fuel filter in the fuel line and then reinstall the fan clamps around the fuel filter.

Dispose of the old fuel filter

To dispose of the old fuel filter, it is important to follow safety precautions. Fuel filters contain gasoline, which is extremely flammable and highly explosive. A fire or explosion from gasoline can burn you, others, and cause property damage. Therefore, it is crucial to take the necessary steps to dispose of the old fuel filter properly.

Firstly, wear protective gear, such as gloves, to shield your hands from any gasoline residue on the filter. Place the old fuel filter in a suitable container, such as an approved gasoline storage container or a sealable bag. Make sure there is no excess fuel dripping from the filter. If there is, use a rag to wipe it off and absorb any spills.

Next, clearly label the container as hazardous waste. You can use a permanent marker to write "Used Fuel Filter" and "Flammable" on the container. This will help identify the contents and warn others of the potential danger.

Finally, take the container with the old fuel filter to a designated hazardous waste disposal facility or recycling center. Do not dispose of it with regular trash. These facilities are equipped to handle and recycle hazardous waste properly, ensuring that it does not harm the environment or pose a risk to others. Check with your local waste management authority or search online for the nearest hazardous waste disposal site.

Remember to always follow local regulations and guidelines for hazardous waste disposal. Improper disposal of fuel filters can have serious consequences for the environment and public safety. By taking the necessary precautions and disposing of the old fuel filter responsibly, you help protect yourself, others, and the planet.

Reinstall the new fuel filter with the flow side towards the engine

To reinstall the new fuel filter, locate the arrow on the side of the filter that says "flow". This side should be facing towards the engine. Insert the new fuel filter into the fuel line, ensuring that the flow side is correctly oriented towards the engine. Once the filter is in the correct position, reinstall the fan clamps around the fuel filter to secure it in place.

It is important to note that before performing any maintenance on your Exmark Lazer Z, you should refer to the owner's manual for specific maintenance instructions and safety information. The maintenance procedures may vary slightly depending on the model of your lawn mower. Always exercise caution when working with gasoline, ensuring there are no open flames or sparks, and make sure the battery is disconnected and the key is removed from the machine.

Additionally, when working with fuel, it is recommended to use gloves and place a rag underneath the filter to catch any fuel drips or spills. This will help prevent fuel from running onto other parts of the machine and will make cleanup easier.

By following these steps and referring to your owner's manual, you can safely and effectively reinstall the new fuel filter on your Exmark Lazer Z, ensuring the flow side is oriented correctly towards the engine.
