The amount of fuel delivered by a fuel pump is known as the flow rate, and it is measured in gallons per hour (gph) or litres per hour (lph). The required fuel pressure and flow rate depend on the vehicle's engine and fuel system. Carbureted engines may require as little as 28 kPa (4 PSI), while modern multipoint fuel injected high-performance engines can require up to 414 kPa (60 PSI). The horsepower of the engine also determines the fuel flow requirement. A good estimator of volume to power is approximately 10 hp per gallon or 2.64 hp per liter. For example, a pump flowing at 50 gph should be able to support a 500 hp engine. The voltage supplied to the fuel pump also affects the flow rate. As voltage increases, the speed of the fuel pump increases, which will increase the flow of a pump at any given pressure.
Characteristics and Values of a Fuel Pump
| Characteristics | Values |
|---|---|
| Fuel flow rate | 78 gph at 0 psi, 62 gph at 60 psi, 90 gph, 130 gph, 415 LPH at 43 psi, 450 LPH, 525 LPH, 190 LPH, 140 LPH, 255 LPH |
| Fuel pressure | 4-7 psi for carbureted engines, 58 psi for GM LS engines, 6 psi, 10 psi, 49 psi, 60 psi, 700 kPa (100 psi), 28 kPa (4 psi), 414 kPa (60 psi) |
| Horsepower | 500 hp, 600 hp, 550 hp, 650 hp, 1,200 hp |
| Voltage | 13.5 volts, 12 volts |
Explore related products
What You'll Learn
Fuel pump type
Fuel pumps are critical components in various industries, including automotive, manufacturing, agriculture, transportation, and power generation. They are designed to handle the transfer, delivery, and management of fuels such as diesel, gasoline, kerosene, and other petroleum-based products.
There are three main types of fuel pumps for gasoline engines: mechanical, electric, and high-pressure fuel pumps. Mechanical fuel pumps use engine camshafts to drive diaphragms that push fuel through the pump, and they are often found in internal combustion engines. They are simple and effective, using a rubber diaphragm in the middle of the housing and a metal lever to make contact. Mechanical pumps can be further divided into diaphragm-type and plunger-type fuel pumps. Diaphragm pumps use the expansion and compression of a diaphragm to suction fuel, while plunger-type pumps use the reciprocating action of the plunger to suck and distribute fuel.
Electrical fuel pumps, on the other hand, use electric motors located inside or inline with the fuel tank to draw and pressurize fuel for modern fuel injection systems. They are more commonly found in contemporary automobiles due to the switch from carburetors to fuel injection systems. Electrical fuel pumps can be further categorized into in-tank and inline subtypes. Turbo pumps, such as centrifugal and axial turbo pumps, can also be used to increase fuel pressure for high-performance engines.
High-pressure fuel pumps are designed to deliver fuel at high pressures, making them suitable for fuel injection systems. They can handle viscous fuels and provide precise fuel delivery.
Other types of fuel pumps include gear pumps, piston pumps, and vane pumps, each with its own unique design and applications.
When selecting a fuel pump, it is important to consider factors such as horsepower, fuel pressure, voltage, and flow rate. The amount of horsepower an engine has will determine the volume of fuel required to support it, with a good estimator being approximately 10 hp per gallon or 2.64 hp per liter. As horsepower increases, the volume of fuel required also increases. Fuel pressure and voltage also play a significant role in the performance of a fuel pump, as higher pressure and voltage typically result in increased flow rates.
Jet Fuel Combustion: CO2 Emissions and Environmental Impact
You may want to see also
Explore related products
Flow rate
The flow rate of a fuel pump is the amount of fuel delivered by the pump, typically measured in gallons per hour (gph) or litres per hour (lph). The flow rate of a fuel pump is important because it determines the amount of fuel supplied to the engine to meet horsepower goals.
The flow rate of a fuel pump varies depending on the pressure and voltage applied to the pump. As pressure increases, the flow rate decreases. Most fuel pumps are rated at their "free flow" state, which means they are flowing at 0 psi, and this is the pump's highest flowing state. For example, a pump with a free-flow rate of 78 gph at 60 psi will have a flow rate of 62 gph.
Fuel pump manufacturers typically provide charts that show the flow rate of a pump at different pressures. These charts can be used to determine the flow rate of a pump at a specific pressure. For instance, a pump rated at 415 LPH @ 43 psi will have a lower flow rate than a pump rated at 525 LPH @ 0 psi.
The horsepower of an engine also affects the required flow rate of a fuel pump. As horsepower increases, the volume of fuel required to support that power also increases. A good estimator of volume to power is approximately 10 hp per gallon or 2.64 hp per liter. For example, a pump with a flow rate of 50 gph should be able to support a 500 hp engine.
It is important to note that the fuel pump does not create fuel pressure but provides fuel flow within the system. The fuel system, which provides flow restriction, helps to create measurable fuel system pressure. Therefore, the flow rate of a fuel pump should be considered in conjunction with the fuel system components to achieve the desired fuel system pressure and engine performance.
The KC-135's Fuel Capacity: A Strategic Advantage
You may want to see also
Explore related products
Fuel pressure
The fuel pump itself does not create the fuel pressure; instead, it provides the fuel flow within the system. The fuel system, which provides flow restriction, helps to create the measurable fuel system pressure. Therefore, the fuel pump's flow rate and the restrictiveness of the fuel system components collectively determine the fuel pressure.
When choosing a fuel pump, it is essential to consider the horsepower requirements of your engine. As horsepower increases, the volume of fuel required to support the engine also increases. A common rule of thumb is that you need 10 gallons per hour (gph) of fuel flow to ensure sufficient fuel supply for 100 horsepower. Additionally, the voltage supplied to the fuel pump can impact its performance, with higher voltages resulting in increased fuel pump speed and flow rate.
It is worth noting that simply increasing fuel pressure may not lead to the desired performance enhancement. Other factors, such as the fuel system components and their compatibility with the fuel pump, play a crucial role in achieving optimal performance. While most fuel systems can handle upwards of 100 psi, excessively high fuel system pressure can lead to distortion or damage. Therefore, it is recommended to consult fuel pump curve charts that illustrate the relationship between flow rate and pressure at a given voltage to make an informed decision when selecting a fuel pump.
Avgas Fuel Weight: How Much Does a Gallon Weigh?
You may want to see also
Explore related products
Voltage
The voltage needed to run a fuel pump depends on the system. A 12.5-volt or 14.5-volt system needs to have the correct voltage supplied to it to make the right amount of fuel enter the engine with a particular pulse width on the injectors.
Most things for cars work on a nominal 12 volts, which can realistically mean anywhere from 10 to 15 volts. However, a higher voltage does not always mean better. For instance, if you were charging at 14+ volts and are only getting 12 volts at the pump, you may have poor electrical connections or diodes in line.
If you want to maximise pump speed and fuel flow, you need the highest possible voltage at the pump. A fuel pump current draw test should be performed any time there is a performance complaint caused by a lack of fuel delivery.
Apache Helicopter Fuel Efficiency: How Much Does It Consume?
You may want to see also
Explore related products
Horsepower
The amount of horsepower produced by an engine determines how much fuel flow is required to support it. As horsepower increases, so does the volume of fuel required to support that power. A good estimator of volume to power is approximately 10 hp per gallon or 2.64 hp per liter. For instance, if your pump flows at 50 gph, it should be able to support a 500 hp engine (50 x 10 = 500).
To determine the fuel requirements of your vehicle, you can use the following equations:
- Optimal lbs./hr = (Max. HP x BSFC)
- Optimal GPH = (Max. HP x BSFC) / 6
- Optimal LPH = (Max. HP x BSFC) / 1.585
For example, if you have a stock engine that makes 350 horsepower, the equation would look like this:
350 x 0.5 / 6 = 29 GPH
So, you would need a fuel pump that delivers 29 GPH of fuel.
It's important to note that fuel pressure and volume have an inverse relationship. As pressure increases, the volume will decrease, and vice versa. Therefore, when selecting a fuel pump, it is recommended to estimate conservatively and figure your horsepower on the high side to ensure a sufficient fuel supply.
Additionally, voltage plays a crucial role in the performance of electric fuel pumps. As voltage increases, the speed of the fuel pump increases, resulting in a higher flow rate at a given pressure. Most cars with a charging system will supply around 13.5 volts to the pump. However, it is good practice to verify the voltage at the pump and consider flow ratings at 12 volts for conservative planning.
Fossil Fuels: Global Usage and Impact
You may want to see also
Frequently asked questions
The amount of fuel flow required to support an engine is directly proportional to the engine's horsepower. A good estimator of volume to power is approximately 10 hp per gallon or 2.64 hp per liter.
The amount of fuel delivered by a fuel pump, known as the flow rate, depends on the fuel pump's voltage and the pressure within the fuel system. As voltage and pressure increase, the flow rate decreases.
The required fuel pressure depends on the vehicle's engine and fuel system. Carbureted engines may require as little as 28 kPa (4 PSI), while modern multipoint fuel injected high-performance engines can require up to 414 kPa (60 PSI). It is important to consider the horsepower requirements and consult fuel pump charts to select the suitable pump for your vehicle.
