The fuel pump relay is an essential component of a combustion engine, responsible for supplying power to the fuel pump when the ignition is turned on. A faulty fuel pump relay can cause significant issues, such as engine stalls or a complete refusal to start. The average fuel pump replacement cost ranges from $300 to $700, and the price of a fuel pump relay switch falls within this range. For example, a UT Ultima Technologies 40 Amp 5 Terminal Starter Relay with a 12-volt voltage and a limited lifetime warranty costs around this price.
| Characteristics | Values |
|---|---|
| Average fuel pump replacement cost | $300 to $700 |
| Relay coil pins | #85 and #86 |
| Relay | 4-prong with at least 14-gauge wiring |
| Terminal type | Blade, Bullet |
| Connector gender | Male, Female |
| Connector shape | Rectangle, Square |
| Voltage | 12 Volt |
| Number of terminals | 3, 4, 5, 21 |
| Amperage | 10 Amp, 40 Amp |
Explore related products
What You'll Learn
Rewiring a fuel pump relay
The cost of a fuel pump relay switch varies depending on the make and model of your vehicle. It is recommended to purchase a vehicle-specific fuel pump relay switch from a reputable auto parts store or dealership to ensure compatibility and proper functionality.
Now, here is a step-by-step guide on how to rewire a fuel pump relay:
First, locate the fuel pump's wiring. You will need to access the wiring harness and find the 12V supply wire that connects the ECU (engine control unit) to the fuel pump. This wire provides power to the fuel pump, and by cutting it, you will be able to reroute the power through the new relay.
Once you have identified the correct wire, cut it carefully. This will leave you with two sections of wire: one running to the fuel pump and the other to the factory ECU. At this point, you should also make sure that you have the correct relay. The relay should be a four-pronged or four-pinned relay with at least 14-gauge wiring. The four pins on the relay are typically labeled as 30, 85, 86, and 87.
Now, take the relay and connect it to the wiring. Start by wiring pin 85 of the relay to the 12V supply wire coming from the factory ECU. This will energize the relay, ensuring that it turns on when the ECU provides power.
Next, run a dedicated wire from your car battery to pin 30 on the relay. This connection will provide a direct and clean voltage supply to the relay.
After that, you need to connect pin 87 of the relay to the cut wire that originally ran to the fuel pump. This will complete the circuit, allowing power to flow from the battery, through the relay, and to the fuel pump when the relay is activated.
Finally, test your work. Start the car and observe whether the fuel pump is receiving power. Ensure that the relay is functioning correctly and that the fuel pump turns on and off as expected.
It is important to note that this is a general guide, and the specific steps may vary depending on your vehicle's make and model. Always refer to a repair manual or seek advice from a qualified mechanic if you are unsure about any part of the process. Additionally, exercise caution when working with automotive electrical systems to avoid any potential hazards.
