The McDonnell Douglas DC-9 is a short-to-medium-range airliner that was produced from 1965 to 1982. It was designed for frequent short-range flights and featured rear fuselage-mounted engines, a T-tail configuration, moderately swept wings, and a capacity of up to 90 passengers. The DC-9 has a fuel capacity ranging from 3,679 to 3,693 US gallons, depending on the series. The aircraft's range can vary from 600 to 1,450 nautical miles, depending on payload and fuel load. With a full fuel load, the DC-9 can achieve a maximum range of 1,450 nautical miles.
| Characteristics | Values |
|---|---|
| Aircraft Type | McDonnell Douglas DC-9 |
| Aircraft Family | DC-9 |
| First Generation | Series 10, Series 20, Series 30, Series 40, Series 50 |
| Second Generation | MD-80 Series (Series 80, Series 81, Series 82, Series 83, Series 87, Series 88) |
| Third Generation | MD-90 Series (Series 90, Series 95) |
| Total Units Produced | 2,441 |
| First Generation Units | 976 |
| Second Generation Units | 1,191 |
| Third Generation Units | 271 |
| Fuel Efficiency | Studies aimed at improving it did not show significant benefits |
| Fuel System | Two spring and ball poppet check valves in fuel lines |
| Normal Range | 1,200 nm |
| Max Range | 1,635 nm |
| Maximum Takeoff Weight (MTOW) | 108,000 lbs |
| Engine Manufacturer | Pratt & Whitney |
| Engine Model | JT8D-7, -9, -11, -15 or -17 |
Explore related products
What You'll Learn
- The DC-9 series was manufactured from 1965 to 1982
- The DC-9 was designed for short-range flights
- The DC-9 has a fuel capacity of 3,679 US gallons
- The DC-9 has two spring and ball poppet check valves in its fuel lines
- The DC-9 was the last aircraft fully designed and produced by the Douglas Aircraft Corporation
The DC-9 series was manufactured from 1965 to 1982
The McDonnell Douglas DC-9 is an American single-aisle aircraft designed by the Douglas Aircraft Company. The DC-9 was produced to complement the Douglas DC-8, which was a narrow-body aircraft with a longer range and higher capacity. The DC-9 was designed as a short to medium-range narrow-body aircraft. It was first introduced in 1965 and was produced until 1982, with 976 aircraft manufactured during this period.
The DC-9 was initially produced as the Douglas DC-9 before August 1967, after which the company merged with McDonnell Aircraft to become McDonnell Douglas. The DC-9 was powered by two rear-mounted Pratt & Whitney JT8D low-bypass turbofan engines. It had a two-person flight deck and could seat up to 139 passengers. The DC-9 Series 20, which was certified in 1968, had an overall length of 104.4 feet and a wingspan of 93.3 feet.
The DC-9 was followed by the second generation of the DC-9 family, the MD-80 series, which was introduced in 1980. The MD-80 was a lengthened version of the DC-9 with higher passenger and fuel capacity. The MD-80 series was further developed into the third generation, the MD-90 series, in the early 1990s. The MD-90 was an updated version of the MD-88 with a new electronic flight instrument system and improved engines.
The DC-9 has had a long history in aircraft development and fleet history, especially among US airlines. While the original DC-9 is becoming rarer, some are still in service, and later variants like the MD-80, MD-90, and Boeing 717 remain in operation. The DC-9 family was produced in a total of 2441 units across all generations, with the first generation (DC-9) accounting for 976 of those units.
British Airways Fuel Surcharge: How Much Does It Cost?
You may want to see also
Explore related products
The DC-9 was designed for short-range flights
The McDonnell Douglas DC-9 was designed for short-haul flights, with its first flight taking place in 1965. The DC-9 was designed for short to medium-haul routes, often serving smaller airports with shorter runways and less ground infrastructure than larger airports. The DC-9's takeoff weight was limited to 80,000 lb (36,300 kg) for a two-person flight crew by Federal Aviation Agency regulations. The aircraft has a five-abreast layout for economy seating, accommodating 80 to 135 passengers depending on the version and seating arrangement.
The DC-9 Series 20, for example, has an overall length of 104.4 feet (31.82 m) and a wingspan of 93.3 feet (28.44 m). It is powered by a 15,000 lbf (67 kN) thrust JT8D-11 engine. The Series 20 was designed to improve short-field performance with more powerful engines and improved wings. The DC-9 Series 10, on the other hand, was designed for short takeoff and landing distances without the use of leading-edge high-lift devices. It has a slightly lower basic fuel capacity than the Series 20.
The DC-9 was an all-new design, differing from its competitor, the larger Boeing 727 trijet. It was produced on the final assembly line in Long Beach, California, beginning in 1965. The DC-9 family includes the MD-80, MD-90, and Boeing 717, with the last member of the family, the Boeing 717, produced until 2006. The DC-9 was designed to perform a maximum of 40,000 landings and had built-in airstairs, including one in the tail, which shortened boarding and deplaning times.
The DC-9 was a popular aircraft, with 726 aircraft delivered by May 1976, more than double its nearest competitor. Its design features, such as the tail-mounted engine, simplified design, and low takeoff and approach speeds, made it well-suited for short-range flights.
The Weight of 300 Gallons of Fuel: How Much?
You may want to see also
Explore related products
The DC-9 has a fuel capacity of 3,679 US gallons
The DC-9 is a short-to-medium-range airliner designed and produced by the Douglas Aircraft Corporation. The DC-9 family is one of the longest-lasting aircraft in production and operation, with 2,441 units produced from 1965 to 2006. The DC-9 was an all-new design, featuring rear fuselage-mounted engines, a T-tail, moderately swept wings, and a capacity of up to 90 passengers.
The DC-9 Series 20, which first flew in September 1968, has a basic fuel capacity of 3,679 US gallons. This is slightly lower than the Series 10's fuel capacity. The Series 14 has an even higher fuel capacity of 3,693 US gallons (including the 907 US gal centre section fuel). The DC-9 Series 20's typical range with maximum payload is 1,000 nautical miles, increasing to 1,450 nautical miles with maximum fuel.
The DC-9's fuel system includes two spring and ball poppet check valves installed in the fuel lines between the center tank pumps and the fuel manifolds. These valves are set to open at 1.5 psi, preventing the engine-driven fuel pumps from sucking air from an empty tank. The DC-9's engines put out a total of 30 psi.
Over time, McDonnell Douglas, which acquired the Douglas Aircraft Corporation, studied ways to improve the DC-9's fuel efficiency through retrofitted wingtips. However, these studies did not show significant benefits. With severe increases in fuel prices in 2008, airlines began retiring their DC-9s in favour of more fuel-efficient aircraft, such as the Airbus A319.
How Much Seafoam is Too Much?
You may want to see also
Explore related products
The DC-9 has two spring and ball poppet check valves in its fuel lines
The McDonnell Douglas DC-9 is one of the longest-lasting aircraft in production and operation, with 2,441 units produced from 1965 to 2006. The DC-9 has a fuel capacity of 3,693 US gallons (with the 907 US gal centre section fuel). The aircraft has a typical range of 950 nautical miles with 50 passengers and baggage, increasing to 1,278 nautical miles at long-range cruise.
Poppet check valves are a type of one-way valve with two ports. Fluid enters the valve through one port and exits through the second port, moving in the same direction. These valves are often used for fluid mixing and are highly versatile, being used across industries such as chemical dispensing and agriculture. They feature a movable element, typically a disk or cone-shaped component, which is referred to as a poppet. This poppet is held in place by a spring or other mechanism, allowing it to move away from the seat when fluid flows and return to the closed position when there is backflow.
The spring in a poppet check valve helps to close the valve prior to fluid flow reversal, eliminating hydraulic shock or "water hammer". Water hammer occurs when there is a sudden stoppage of fluid flow in a fluid process system. Poppet check valves can be used in a variety of applications, including fluid transfer systems such as chemical or laundry dousing systems, where accurate regulation of fluid flow is necessary.
Fuel Consumption of Wheel Loaders: Burning Per Hour
You may want to see also
Explore related products
The DC-9 was the last aircraft fully designed and produced by the Douglas Aircraft Corporation
The McDonnell Douglas DC-9 is an American short to medium-range airliner. It was the last aircraft to be fully designed and produced by the Douglas Aircraft Corporation. The DC-9 was initially produced as the Douglas DC-9 before August 1967, after which the company became McDonnell Douglas following a merger with McDonnell Aircraft.
The DC-9 was designed to fill a gap in the market for a short to medium-range airliner. In the 1950s, Douglas had the DC-8, which served medium to long-range and intercontinental markets. However, they needed an aircraft that could serve smaller and more remote locations. The design process took several years and involved investigating various options, including a scaled-down four-engine version and European competitors' offerings.
The DC-9 was an all-new design, unlike its competitor, the slightly larger Boeing 727, which used existing components. The DC-9 features two rear fuselage-mounted Pratt & Whitney JT8D turbofan engines, small and efficient wings, and a T-tail. It has a two-person flight deck and built-in airstairs, making it well-suited for smaller airports. The first DC-9, a production model, flew on February 25, 1965, and by July of that year, four more had been produced. The DC-9 family was a commercial success, with a total of 2,441 units produced across three generations.
The DC-9 has been the subject of studies aimed at improving its fuel efficiency, such as retrofitting wingtips of various types. However, these modifications have not demonstrated significant benefits, and the unique wing design makes retrofitting challenging. The DC-9 has been replaced by more fuel-efficient aircraft, such as the Airbus A319, due to increasing fuel prices.
The True Cost of DEF Fuel
You may want to see also
Frequently asked questions
The amount of fuel required depends on the variant of the DC-9 aircraft. The Series 14 has a fuel capacity of 3,693 US gallons, while the Series 20 has a slightly lower basic fuel capacity of 3,679 US gallons.
The DC-9 is a short to medium-range airliner. The Series 14 has a range of 1,450 nautical miles with full fuel, while the Series 20 can fly up to 1,670 nautical miles with maximum fuel.
The DC-9-32 has a fuel capacity of 3,679 gallons and a maximum range of 1,635 nautical miles.
The DC-9 family of aircraft includes the MD-80 and MD-90 series, which have higher fuel capacities. However, the DC-9 was designed for frequent short-range flights and has a lower fuel capacity compared to other aircraft such as the Airbus A320 and Boeing 737.
Yes, the fuel efficiency of a DC-9 can be affected by various factors such as payload weight, cruise speed, and external factors like weather conditions. Additionally, retrofitted wingtips have been studied as a potential way to improve the fuel efficiency of the DC-9, but these have not shown significant benefits.
